- Page 1 ILLUSION AUDIO WWW.ILLUSIONAU DIO -AM ER IC A. C OM PRODUCT MANUAL CARBON & LUCCENT COAXIALS...
-
Page 2: Thank You
Through innovation, design, testing and listening, Illusion Audio speakers represent the passion that the entire staff at Illusion Audio has; That passion for GREAT SOUNDING MUSIC! BOX CONTENTS... - Page 3 INSTALLATION OPTIONS SINGLE AMPLIFIER SYSTEMS The objective behind a single amplifier system is simplicity. By choosing this route the installer can run minimum components and achieve excellent sound quality. A single two channel amplifier will drive both the mid bass and tweeters; eliminating the need for an additional amplifier and installation time, thus reducing the cost.
- Page 4 Illusion Audio manufactures a variety of high quality subwoofers specifically designed to integrate seamlessly in application with Illusion Audio speakers. The Carbon and Luccent Lines feature four and two respectively high quality Subwoofers that will perfectly complement your Carbon or Luccent Components and Coaxials.
- Page 5 STANDARD TWEETER SETTINGS ON CROSSOVER 0 dB Attenuation -1 dB Attenuation -2 dB Attenuation -3 dB Attenuation -1 dB -1 dB -1 dB -1 dB ON OFF TWEETER LOUDNESS ADJUSTMENT -2 dB -2 dB -2 dB -2 dB CROSSOVER JUMPER SETTINGS ON OFF -3 dB -3 dB...
- Page 6 SPEAKER INSTALLATION MOUNTING SUGGESTIONS To achieve the best possible performance from your speakers, please follow these recommendations: 1. Mount the speakers as far forward as possible. This allows for correct staging to take place. 2. Locate the speakers as far apart as possible, (left & right). This applies to speakers being installed in the rear of the vehicle as well.
- Page 7 The authorized dealer will then work with Illusion Audio / Orca Design & Manufacturing to obtain service, if necessary. If found to be a defect due to manufacturing, the item will be repaired or replaced with a refurbished product.
