Summary of Contents for EVOC JEC-1503C

  • Page 1 特种计算机 Industrial Computer 产品说明书 User Manual JEC-1503C 15〞上翻盖便携式计算机 15″ Portable PC with Up Flip Version:C01...
  • Page 2: Legal Information

    Please pay attention to the following instructions: Warning EVOC product can only be used according to the descriptions within the manual, including the contents and the relevant technical documents. If the products or components from other companies are required, please get the recommendation and grant from EVOC first.
  • Page 3 Trademarks EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. Other product names mentioned herein are used for identification purposes only and may be trademark and/or registered trademarks of their respective companies.
  • Page 4: About This Manual

    About this manual Scope of the Manual The manual is appropriate for EVOC JEC-1503C. Convention The term “the Board” or “the Product” within the manual stands for EVOC JEC-1503C. Instructions Safety instructions To avoid property losses or individual injury, please pay attention to the safety instructions within the manual.
  • Page 5: Table Of Contents

    Contents 1. Product Introduction ....................1  1.1 Overview .......................1  1.2 Product Specifications ...................2  2. Application Scheme ....................4  2.1 Transportation....................4  2.2 Storage......................4  2.3 Opening the Box and Initial Examination............4  3. Device Connection....................6  3.1 Notices before Connection ................6  3.2 Product Grounding ..................6  3.3 Connecting the Device to Power ..............7  4.
  • Page 6 5.6.1 Installing the Fan..................19  5.6.2 Removing the Fan ................19  5.7 Assembly and Maintenance of Dust-proof Net..........20  5.7.1 Installing the Dust-proof Net ...............20  5.7.2 Removing the Dust-proof Net ..............20  5.8 Installation of PCI/PCI-E Expansion Card ..........21  6. Installing the Drivers ....................22  7.
  • Page 7: Product Introduction

    1. Product Introduction 1.1 Overview JEC-1503C is a portable rugged PC with 15″ LCD screen and up-flip. The product adopts modular design and is constituted by three modules, including host, LCD display and keyboard, which adopt shock absorption, rugged installation, IP protection and EMC design respectively.
  • Page 8: Product Specifications

    Un-buffered and NON-ECC function; the maximum memory capacity supported by a single memory slot is up to 4GB. EVOC EPE 1.0 bus, supporting PCIe and PCI bus expansion, which is expandable to two PCI cards and one PCIe x16 by carrier, EPE-6104E1-JEC;...
  • Page 9 Three axes, 30 minutes per direction.  Anti-shock: 20g acceleration, 11ms duration.  Input voltage/frequency: 100-240VAC 50/60HHz;  Power consumption of the PC: 29.4W (standby); power Power Feature consumption of the PC: 72.8W (100% operates MaxPower). JEC-1503C - 3 -...
  • Page 10: Application Scheme

    2.3 Opening the Box and Initial Examination Opening the Box Please pay attention to the following issues when opening the box: - 4 - JEC-1503C...
  • Page 11 ● Please check whether the delivery contains the intact device and all of the independently ordered accessories. Please contact the customer service when any unconformity or transportation damages occur. JEC-1503C - 5 -...
  • Page 12: Device Connection

    PC is powered off. 3.2 Product Grounding Low impedance ground connection is more helpful to release the interference produced by the external cables, the signal cables or the cables connecting the IO module to the grounding system. - 6 - JEC-1503C...
  • Page 13: Connecting The Device To Power

    Steps to connect the device to power: Please connect the power cord with connector 2. Please make sure whether the input voltage is in accord with the instructed voltage on the silkscreen of the power socket before installation. JEC-1503C - 7 -...
  • Page 14: Instructions

    Instructions 4. Instructions 4.1 Product Outline - 8 - JEC-1503C...
  • Page 15: Product Appearance And Installation Dimensions

    Instructions 4.2 Product Appearance and Installation Dimensions Unit: mm JEC-1503C - 9 -...
  • Page 16: External Structure

    Front View of the Device Item Description Handle Touchpad Keyboard HDD LED indicator PWR LED indicator Power switch LCD screen Rear View of the Device Item Description MS/KB COM 1/2 LAN 1/2 USB1/2/3/4 AC220V power input - 10 - JEC-1503C...
  • Page 17: Operation Control

    Power switch The button is used to power on or power off the device. 4.5 Status Indicator Display Meaning Description Power off POWER Indicates PC status Green PC is operating No access Indicates HDD access Yellow Accessing JEC-1503C - 11 -...
  • Page 18: Com Setting

    RS-232 Port NO. Setting RS-422 RS-485 (Default) 1-3, 2-4 3-5, 4-6 3-5, 4-6 COM1 1-3, 2-4 3-5, 4-6 3-5, 4-6 JP1 ~ JP6 1-3, 2-4 3-5, 4-6 3-5, 4-6 COM2 1-3, 2-4 3-5, 4-6 3-5, 4-6 - 12 - JEC-1503C...
  • Page 19: Assembly And Maintenance

    Assembly and Maintenance 5. Assembly and Maintenance 5.1 Overall Assembly Drawing Item Description Item Description Screen assembly Keyboard assembly Motherboard assembly Chassis assembly HDD assembly Power supply JEC-1503C - 13 -...
  • Page 20: Removing The Cover

    2. Host cover the figure shown by the arrow after the first out, and then flipped up. 5.3 Removal/Installation of Motherboard 5.3.1 Installing the Motherboard 1. Locate the carrier at the corresponding position on the carrier bracket and fix with screws as shown in the above figure; - 14 - JEC-1503C...
  • Page 21 4. Place the assembly properly into the chassis, and fasten it with screws and nuts; 5. Install the IO plate by the direction shown in the picture, and insert the cables connecting with motherboard and carrier baord. JEC-1503C - 15 -...
  • Page 22: Removing The Motherboard

    4. Turn the spanner by the direction shown in the picture above, and pull out the motherboard assembly from the slot; 5. Take out the screws fixing the motherboard as per the picture above, and remove the motherboard from the bracket. - 16 - JEC-1503C...
  • Page 23: Removal/Installation Of Driver

    5.4.2 Removing the Hard Disk 1. Remove the screws fixing the hard disk bracket to take out the hard disk assembly; 2. Remove the screws fixing the hard disk and then draw out the hard disk. JEC-1503C - 17 -...
  • Page 24: Removal/Installation Of Power Supply

    1. Remove the nuts and take off the power supply cover; 2. Unplug the cables; 3. Remove the screws fixing the power supply and then take out the power supply. - 18 - JEC-1503C...
  • Page 25: Assembly And Maintenance Of Fan

    2. Remove the screws and then take off the fan assembly from the side wall of the chassis; 3. Remove the screws and then take off fan 1 from the fan bracket. Note: Because the fan speed is relatively fast, please do not touch the fan before it stops. JEC-1503C - 19 -...
  • Page 26: Assembly And Maintenance Of Dust-Proof Net

    1. Remove the screws and then pull out the dust-proof net cover from the slot on the side wall; 2. Take out the dust-proof net from the corresponding slot on the side wall of the chassis. - 20 - JEC-1503C...
  • Page 27: Installation Of Pci/Pci-E Expansion Card

    2. Insert the PCI or PCI-E card into the corresponding slot on carrier and fix the slot cover with screws; 3. Put on the expansion door cover and tighten the screws. JEC-1503C - 21 -...
  • Page 28: Installing The Drivers

    Installing the Drivers 6. Installing the Drivers Regarding the installation of the driver program and the detailed information of the motherboard, please refer to the enclosed CD of the PC. - 22 - JEC-1503C...
  • Page 29: Appendix

    Follow the power-on prompt and Incorrect time or press the key to enter the BIOS Incorrect BIOS setting date on PC Setup; adjust the time and date in BIOS Setup. JEC-1503C - 23 -...
  • Page 30 IO Poor contact of the slot card, unstable fixing or improper card can be used dust-proof measures; please when used again remove and install the card for a few times or use another slot. - 24 - JEC-1503C...
