Summary of Contents for ShenZhen V-sys Technology X1S
- Page 1 User Manual Model : X1S Key Operating ： USB Power Supply /GPS TF Card 1 MENU /OK Down Camera 1...
- Page 2 Microphone Camera 2 Camera 3 TF Card 2 LCD Screen Menu main interface and setting How to Video recording and Menu setting Video recording Power on the Camera , long Press “Menu “ button enter Menu main interface ,Press Up/Down button to , Press “...
- Page 3 640*480 2. Side Camera 640*480 1280*720 3. Time Stamp No display date and time Date Only Only display date Date and Time Display date and Time 4. Loop Recording 1Min Video file 1 minute When the Card full will delete front file 3Min Video file 3 minute When the Card full will delete front file 5Min...
- Page 4 5. Date Input 1）Press “Up”/Down button to setting number 2）Press “OK ” button jump next setting 3）Press “OK ” button confirm and Exit set 6. Time Input 1）Press “Up/Down ”button to setting number 2）Press “OK ” button jump next setting 3）Press “OK ”...
- Page 5 In the Video recording Mode ,long Press “Menu “ button enter Menu main interface ,Press Up/Down button to select Playback icon Card 1 or Card 2 1. Press Up/Down button to select previous/next video file 2. Press “OK” Play/Stop 3. long Press “Menu” button Exit playback mode GPS Function Connect the GPS module to the GPS slot , then start to recording ,Camera start Search GPS Signal the GPS icon flashing after received GPS Signal the GPS icon light up and the date time will auto update...
- Page 6 select GPS file then Click “Play” button to playing as follow button to Click Camera Change 1) Front Camera In the other mode ,Press “ Up “ button Can be change the Front Camera to Side Camera 2) Side Camera In the other mode ,Press “ Down “ button Can be change to Camera 2 or Camera 3 Parking Mode When the Car in the Park status, After 3 minute the Camera will auto change to parking mode, the LCD display”...
- Page 7 Technical Specifications LCD screen 3.0 TFT Language English/ French/ German /Italian/Spanish/Portuguese / T-Chinese/ S-Chinese/ Russian/ Turkish/Japan Video format AVI (H.264) Video Resolution Front Camera 1080P, Back Camera VGA Memory card TF Card 1 Up to 128GB TF Card 2 Up to 128GB Microphone Built–in GPS Tracks...
