- Page 1 Interactive Flat Panel INSTRUCTION MANUAL LTE55-003V+ LTE65-003V+ LTE70-003V+ LTE75-003V+ LTE84-003V+ Before connecting, operating or adjusting this product, please read the manual completely. Please keep this manual for future reference.
-
Page 2: Table Of Contents
Contents Important Information Important Safety Precautions Important Notice Identification of Controls Remote Control Setting Up Connections Basic Operations System Settings Network Settings Menu List Using USB Multi Media Player Troubleshooting Specifications... -
Page 3: Important Information
IMPORTANT INFORMATION If the IFP is not positioned in a stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: ! Use cabinets or stands recommended by the manufacturer of the IFP . ! Only use furniture that can safely support the IFP . -
Page 4: Important Safety Precautions
Important Safety Precautions Electricity may cause personal injuries and property damage if improperly handled. The IFP has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRIC SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. - Page 5 Important Safety Precautions (Continued) 15. Stand---Use only with the trolley stand or wall mount specified by the manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley stand or wall mount. Placing the product on an unstable base can cause the product to fall, resulting in possible serious injuries as well as damage to the product.
-
Page 6: Important Notice
Important Notice About Location/ Do not use in hot and cold rooms (locations) ! When the unit is used in rooms (locations) with low temperature, the picture may Environment leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal. -
Page 7: Identification Of Controls
Identification of Controls 1. : USB standard interface of the IFP,enable connection to USB2.0 standard devices. : USB standard interface of the OPS,enable connection to USB2.0 standard devices. Note: If no OPS, the USB port has no function. :Switch the IFP power on or standby. : Press the button to display input source menu or exit the menu screen. -
Page 8: Remote Control
Remote Control POWER Switch the IFP power on or Standby Switch to AV mode Switch to VGA mode HDMI Switch to TV mode Switch to HDMI mode Note: If no RF, this button has no function. SLEEP ZO OM INFO Display or exit the current Set up the sleep timer program information... -
Page 9: Setting Up
Setting Up Selecting a location You should select a location for the IFP: Where direct light does not reflect on the screen. · That has indirect and soft lighting. · Where the IFP has access to a power outlet. · Note: Watching IFP in total darkness or with a reflection on the screen may cause eyestrain. -
Page 10: Connections
Connections Cautions Before Connecting When connecting an external device to the IFP , make sure that the IFP and the device are turned off. Check the plugs at the ends of cables to make sure that they are the correct type before you try plugging them into jacks on the IFP . Make sure that all plugs are securely inserted into the jacks. - Page 11 Connections DVI to HDMI cable HDMI 1 Game console HDMI 2 Camcorder Set top box HDMI 3 Satellite signal receiver DVI devices Use a DVI to HDMI adapter cable to cnnect to the HDMI terminal. Connect the USB 3.0 audio cable to the PC IN1 AUDIO jack. Audio cable AUDIO VGA cable...
-
Page 12: Basic Operations
Basic Operations Turning the IFP on or off Plug the power cord into an AC power outlet. Press Power Switch on the IFP . Now the IFP is in standby mode. Wait a moment until the power indicator lights up, then press POWER to turn on the IFP . - Page 13 Basic Operations Touch once outside the MENU, the MENU will be show , you can press and drag Touch the bottom of the screen and drag upward to any place of the screen, then touch once to to make the MENU display the MENU.
-
Page 14: System Settings
System Settings Wallpaper Setting Press OK to access its edit menu. Force this application to stop Uninstall this application Clear data of this application Display information Display current network status. Network Setting (p.13) Display system information or restore to factory default. Internal routing setting If the internal AP doesn’t work, Input the default UserName:... -
Page 15: Network Settings
Network Settings Wired Network Setting Select Setup Wizard Next Select Gateway Next Next Next There are five methods to connect with Next network, choose your preferred one. Static IP If all Internet IP information is provided by your ISP , then choose Static IP . - Page 16 Network Settings(Continued) Wireless Network Setting Select Setup Wizard Next Select Wireless ISP Next Next Next Passward Setting Format Next WiFi Password of Internal Router in IFP . Next Next Finished Select Successfully Wireless, connected, return then Site Survey to Site contents. Confirm Site Survey Select your desired Input...
-
Page 17: Menu List
Menu List Select your favourite picture mode for each input [Dynamic] Picture Mode [Standard] / [Soft] / [User]. Adjust the contrast. Contrast Brightness Adjust the brightness. Adjust the image hue. (Only for NTSC system) Tint Sharpness Adjust the sharpness. Adjust the color saturation. Saturation Backlight Set up the overall brilliance of the screen. - Page 18 Menu List Date Set current date manually. Set current time manually. Current Time Off Time Set Off timer to switch the IFP to standby at a specified time. On Time Set On timer to turn on the IFP automatically to source at a certain time.
-
Page 19: Using Usb Multi Media Player
Using USB Multi Media Player Using USB multi media player You can connect a USB storage device to your IFP to view compatible photo, movie on the large screen of the IFP or play compatible music so that the sound can be output from the IFP’s speaker. Home To use USB multi media player, please go to USB source by pressing USB button. - Page 20 Using USB Multi Media Player Playing Photo With the photo viewer, you can view compatible photos (in JPG, BMP or PNG format). Also you can zoom, rotate photo, etc. Note: The photo viewer supports JPG, BMP , PNG format images, but not all JPG, BMP , or PNG files are compatible with the IFP due to technical update.
- Page 21 Using USB Multi Media Player Playing Movie With the USB movie player, you can play compatible movie (in AVI, MPG, MPEG, DAT, MP4, TS, RM/RMVB, or MKV/MOV format). Note: The USB movie player supports AVI, MPG, MPEG, DAT, MP4, TS, RM/RMVB, MKV/MOV format video files, but not all AVI, MPG, MPEG, DAT, MP4, TS, RM/RMVB, MKV/MOV files are compatible with the IFP due to technical update.
-
Page 22: Troubleshooting
Troubleshooting If, after reading these operating instructions, you have additional questions related to the use of your IFP , please call the services center in your local area. Before calling service, please check the symptoms and follow suggested solutions. Remote Control Problem Possible Solutions The batteries could be weak. -
Page 23: Specifications
Specifications Model No. LTE55-003V+ LTE65-003V+ LTE70-003V+ LTE75-003V+ LTE84-003V+ AC 100-240 V, 50 / 60 Hz Power Source Current Max. 2.2 A 2.6 A 2.9 A 5.0 A 6.2 A Standby condition* < 0.5 W < 0.5 W < 0.5 W <... - Page 24 PRINTED ON RECYCLED PAPER...
