U-Tech U 851 Instruction Manual

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

S/N:
INDUSTRIAL PNEUMATIC NAILERS, STAPLERS

INSTRUCTION MANUAL

U 851 STAPLERS
READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THE TOOL!
IMPROPER USE OF THIS TOOL WILL RESULT IN DEATH OR SERIOUS
INJURY!
KEEP THIS MANUAL WITH THE TOOL FOR FUTURE REFERENCE.
2004/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U 851 and is the answer not in the manual?

Questions and answers

Summary of Contents for U-Tech U 851

  • Page 1: Instruction Manual

    S/N: INDUSTRIAL PNEUMATIC NAILERS, STAPLERS INSTRUCTION MANUAL U 851 STAPLERS READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THE TOOL! IMPROPER USE OF THIS TOOL WILL RESULT IN DEATH OR SERIOUS INJURY! KEEP THIS MANUAL WITH THE TOOL FOR FUTURE REFERENCE.

  • Page 2: Technical Data

    TECHNICAL DATA SAFETY INSTRUCTIONS Subflooring, Sheathing, Crating, Furniture Frames, Wall Applications……………………. Sheathing Features………………………... Heavy Duty Stapler, Top Loading Magazine ● READ ALL INSTRUCTIONS. Do not attempt to operate Dimensions (H×L×W)…………. the tool until you read and understand all safety Weight………………………….. precautions and manual instructions.

  • Page 3: Visual Inspection

    SAFETY INSTRUCTIONS TOOL MAINTENANCE VISUAL INSPECTION ● 1. Smooth safety and trigger movement. 2. All screws are tightened. ● Do not use the tool when changing one driving location to 3. Never use damaged or incomplete tool. another, involves the use of stairs, ladders or scaffolding. ●...

  • Page 4: Tool Operation

    TOOL OPERATION TOOL LOADING – SIDE LOAD DESIGN 1. Disconnect air supply. 1. Protect your eyes and ears. Wear Z87.1 safety glasses with side shields. Wear 2. Unlatch and slide rearward the magazine hearing protection. Employers and users are responsible for ensuring the user or anyone near the tool wears this safety protection.

  • Page 5: Troubleshooting

    TOOL LOADING – BOTTOM LOAD DESIGN TROUBLESHOOTING 1. Disconnect air supply. 2. Unlatch and slide rearward the magazine Stop using the tool immediately if any of the following problems occurs. Serious personal injury could occur. Necessary repair or replacement must be carried out by a qualified and trained technician of an authorized service location.
  • Page 6 TROUBLESHOOTING FASTENERS LU-1580F 38-64mm (1 1/2”~2 Stop using the tool immediately if any of the following problems occurs. Serious 1/2”) personal injury could occur. Necessary repair or replacement must be carried out by 11.2mm (7/16”) a qualified and trained technician of an authorized service location. 1.7mm (.067”) PROBLEM CAUSE...
  • Page 7 FASTENERS LU-851KGF 25-50mm (1”~2”) 10.9mm (7/16”) 1.4mm (.055”) 1.6mm (.063”) LU-864KGF 38-64mm (1 1/2”~2 1/2”) 10.9mm (7/16”) 1.6mm (.063”) 1.4mm (.055”) LU-951F 25-50mm (1”~2”) 12.25mm (1/2”) 1.4mm (.055”) 1.6mm (.063”) LU-964F 38-64mm (1 1/2”~2 1/2”) 12.25mm (1/2”) 1.4mm (.055”) 1.6mm (.063”)
