Summary of Contents for Dirty Hand Tools 101088
- Page 1 3000psi Pressure Washer 7HP/196cc Engine MODEL # 101088 Operation Manual is safety alert symbol identi es important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Part # 101377 Rev A...
- Page 2 For Service or Questions Call 1-877-487-8275 720-287-5182 www.dirtyhandtools.com Dirty Hand Tools® is a brand of 1100 W 120th Ave, Suite 600 Westminster, CO 80234 • 720-287-5182...
-
Page 3: Table Of Contents
Table of Contents Important Safety Information .............4 Unpacking and Setup ..............7 Setup and Assembly ...............9 Operation Precautions ..............9 Hose Connection .................11 Filling with Gasoline and Oil ............12 Operation Precautions ..............13 Operation ..................14 Maintenance .................16 Troubleshooting ................19 Storage ..................21 Warranty and Specifications .......... Back Cover... -
Page 4: Important Safety Information
Important Safety Information WARNING WARNING: Read and thoroughly understand all instructions and safety information before operating this pressure washer. Failure to do so may cause serious injury or death. Do not allow anyone to operate this pressure washer who has not read this manual. -
Page 5: General Safety
Important Safety Information General Safety Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. DANGER READ THE OPERATION MANUAL BEFORE OPERATION. • Do not permit children to operate this equipment at any time. Do not permit others that have not read and understood the complete Operation Manual to operate this equipment. -
Page 6: Safety Decals
Make sure all safety warning decals are attached and in readable condition. Replace missing or defaced decals. Contact Dirty Hand Tools at 1-877-487-8275 for replacement decals. DANGER To prevent serious injury: U S I N G A N E N G I N E I N D O O R S... -
Page 7: Unpacking And Setup
Unpacking and Setup Your pressure washer is shipped with the handle bar unattached, the spray nozzles, the high pressure hose, spray lance and spray gun in separate packaging. Save the packing materials and box for future use as a storage container. Carefully follow the assembly instructions to attach the handlebar, high pressure hose, spray lance and spray gun. - Page 8 If you are missing any items, please call Dirty Hand Tools Customer Service at 1-720-287-5182. 2. Fill out and send in enclosed registration card. Write the model number, serial number & date of purchase to ensure warranty registration and keep a copy for your records.
-
Page 9: Setup And Assembly
Setup and Assembly Attaching the spray wand to the spray gun. 1. Carefully thread the spray wand on to the spray gun and tighten by hand only. Never tighten with pliers or wrench as extra pressure may cause the fittings to crack or break. Attaching the high pressure hose to the spray gun. - Page 10 Setup and Assembly Attaching the Spray Nozzle to the Wand e quick–connect on the nozzle wand allows you to switch between different nozzles. Nozzles can be changed while power washer is running once spray gun trigger is locked in the safety position. e nozzles vary the pressure and spray pattern as shown on page 8.
-
Page 11: Hose Connection
Hose Connection Attaching the Hoses 1. Run water through a 3/4 inch garden hose for 30 seconds to clean out any debris. 2. Before connecting the garden hose to the water inlet, inspect and clean screen if it contains debris or replace if damaged. 3. -
Page 12: Filling With Gasoline And Oil
Filling with Gasoline and Oil WARNING FUEL IS HIGHLY FLAMMABLE AND POISONOUS ALWAYS FILL THE TANK WITH ENGINE OFF AND COOL. To prevent serious injury and fire: ALWAYS CHECK THE FUEL LEVEL 1. Do not add fuel while the engine is hot or running. -
Page 13: Operation Precautions
Operation Precautions DANGER CARBON MONOXIDE HAZARD USING AN ENGINE INDOORS CAN KILL YOU IN MINUTES. Engine exhaust contains carbon monoxide. is is a poison you cannot see or smell. DANGER U S I N G A N E N G I N E I N D O O R S C A N K I L L Y O U I N M I N U TE S E x haust c ontains c arb on monox ide whic h is a poison... -
Page 14: Operation
Operation CAUTION THROTTLE ALWAYS CHECK ALL CONNECTIONS AND OIL /FUEL LEVELS BEFORE STARTING THE ENGINE. Do not run the engine without engine oil, or with low engine oil, which will permanently damage the engine. DO NOT OPERATE without the water supply connected and turned on. - Page 15 Operation CAUTION Running the engine on the power washer for 3-5 minutes without pressing the trigger on the spray gun, can cause water to reach temperatures above 125°F. Carefully discharge warm water onto the ground. DANGER Spray gun traps high water pressure, even when engine is stopped and water is disconnected, which can cause injury.
-
Page 16: Maintenance
Maintenance WARNING BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE 5 MINUTES TO ALLOW ALL PARTS TO COOL. Turn the engine switch to the OFF position. Regular maintenance is the way to ensure the best performance and long life of your machine. Please refer to this manual and the engine manufacturer’s owner’s manual for maintenance procedures. - Page 17 Maintenance WARNING To prevent serious injury from accidental starting turn the power switch on the engine to its “OFF” position. To eliminate pressure discharge the spray gun by pressing the trigger then moving it into the locked position. Wait for the engine to cool before performing any maintenance procedure.
- Page 18 Maintenance Spark Plug Maintenance: 1. Disconnect spark plug wire from the end of plug. Clean out debris from around the spark plug. 2. Using a spark plug wrench, remove the spark plug. If the spark plug is oily, clean it with a dry rag. If the electrode has deposits on it, polish it using emery paper.
-
Page 19: Troubleshooting
Engine Troubleshooting WARNING BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE 5 MINUTES TO ALLOW ALL PARTS TO COOL. Disconnect the spark plug wire, keeping it away from the spark plug. PROBLEM SOLUTION e engine will not start. •... - Page 20 Pressure Washer Troubleshooting PROBLEM SOLUTION No pressure, low or inconsistent pressure. • Replace low pressure nozzle with high pressure nozzle. • Clear water inlet. • Provide adequate water flow. • Check for kinking, straighten inlet hose, repair any leak. • Check and clean inlet hose screen. •...
-
Page 21: Storage
Storage WARNING Drain the fuel tank in a well-ventilated area AIR FILTER MUFFLER COVER away from ignition sources. If the engine is SPARK hot from use, shut the engine o and wait PLUG for it to cool before draining fuel. WIRE Do not smoke near the fuel tank. - Page 22 Notes...
- Page 23 Notes...
-
Page 24: Speci Cations
Dimensions 21”L x 19”W x 41”H Weight 68.3 Lbs. *As rated by engine manufacturer For Service or Questions Dirty Hand Tools® is a brand of Call 1-877-487-8275 720-287-5182 1100 W 120th Ave., Suite 600 www.dirtyhandtools.com Westminster, CO 80234 • 720-287-5182...
