Installation instructions
Subject
Car2PC-REN adapter for Car PC / laptop integration into car stereo and AUX Interface for MP3
player
Disclaimer
Modifying the radio may void any outstanding warranty it may have.
•
This product is not affiliated with any of the OEM manufactures
•
There are no warranties expressed or implied by purchase of this product
•
While every care has been taken to provide a quality product, we cannot guarantee the
Car2PC-REN adapter to function correctly if installation is not done according to the
instructions in this guide
•
We're not liable for misuse of this product. Misuse includes improper installation,
damage to the board or radio while trying to install, and illegal use of the modified radio
Tools needed:
1. None
Preparation
1. Turn off car engine and remove key from ignition
2. Using the stereo removal tools carefully remove radio from the pocket it sits in
3. Locate the CD Changer cable or socket on a radio. Usually located at the left upper
corner of the radio when looking from the front of the stereo.
4. Unplug CD Changer cable from the radio if necessary
Note: Factory or aftermarket CD Changer will no longer work after you install Car2PC
adapter!
- 1 –
TM
Car2PC
-REN
rev 1.4
Advertisement
Table of Contents
Summary of Contents for Car2pc REN
-
Page 1: Installation Instructions
Car2PC -REN Installation instructions Subject Car2PC-REN adapter for Car PC / laptop integration into car stereo and AUX Interface for MP3 player Disclaimer Modifying the radio may void any outstanding warranty it may have. • This product is not affiliated with any of the OEM manufactures •... -
Page 2: Adapter Installation
Car2PC -REN Adapter installation 5. Securely attach Car2PC connector to the CD Changer port of the car stereo. Make sure the latch is secured and connector does not fall apart. 6. Find a place where you can place Car2PC. Note: Make sure you mount Car2PC in a place with enough room so when you mount the car stereo back you do not break the adapter 7. - Page 3 Car2PC -REN 1. Cut 3 wires from the white harness. White, Black and Green as shown below 2. Get the RCA male jack from the nearest electronic store and extract 2 wires from it as shown below (use longer cable than shown) 3.
- Page 4 In case if you do not have S/PDIF output on your PC, you will need to use GROM-DIG adapter to encode your analog audio into digital form. Support For all technical questions please e-mail to info@car2pc.com. Your question will be answered within 24 hours. - 4 –...
