Finishing Programing - NCE Mini-Panel Instruction

Note that the step number has increased to 2 indicating the last command has been
accepted and the Mini Panel is ready for the next command for this input. We don't
need any more commands for this input so press "PROG/ESC" to return to the main
menu.
Let's review the command that has just been programmed. Press "2" to review.
Type "1" and press "ENTER" to review the command sent by input number 1
The LCD no displays the accessory number (1) that we entered and the turnout
position (Normal). Press "ENTER" to see the next step for this input
The display now indicates that there are no more entries programmed into this string.
At this point you may continue pressing "ENTER" to cycle up through all the commands
programmed if you wish. The Input and step numbers will be displayed as well as a
description of the command for that step. Press "PROG/ESC" to return to the main
menu.
At this point we have programmed and reviewed the command(s) that will be sent
when input number 1 is grounded. The command can be tested by pressing "3".
Press "1" followed by "ENTER" to test input 1. The command string associated with
input number 1 will be sent.
Putting the Mini Panel into test mode will also allow testing of any input by grounding
that input number. Pressing any button on the ProCab will return the Mini Panel to
setup mode.

Finishing programing:

At this point we have programmed, reviewed and tested the command(s) that will be
sent when input number 1 is grounded. In a similar manner we can program the
commands for inputs 2,3 and 4 using the proper accessory or macro commands.
Last revised: 22 July 2008
1=SETUP 2=MACRO
3=TEST OPERATION
1=SETUP 2=REVIEW
REVIEW INPUT:
INP: 01 STEP: 1
ACCY: 001 NORM
INP: 01 STEP: 2
--END--
1=SETUP 2=MACRO
3=TEST OPERATION
TESTING
INPUT NUMBER: 01
1=SETUP 2=MACRO
3=TEST OPERATION
Page 5
