Summary of Contents for Xtreme DX200
- Page 1 Instruction and Assembly Manual Version 1.0 (Jan 2017)
- Page 2 Thank you for purchasing the Xtreme production DX200 . It is a competition racing drone and it is required some knowledge of FPV model building. please read this manual in detail before you start building this drone. Features: Tools Needed (Not Included) : •Weight of frame is 65 gram only.
- Page 3 Before you start, please understand the usage of different sets of screw holes on the side carbon panel: Pink: space for Receiver antenna Blue: For Camera mount White: Holes or fixing wires. Green: For the upper deck Red: For Main electronic Yellow: Yellow: mount deck.
- Page 4 M3x8 Hexagonal column Battery strap (Plastic) Alu.brace Power distribution board 3mm washer (Plastic) 4 IN 1 Speed Control (Not Included) M3X6 screws Main electronic mount deck 30.5mm 20mm M3X8 screws hole to hole size is 20mm to 30.5mm (Plastic)
- Page 5 M3X6 screws Rear Arms Mount Main frame (side carbon panel) M3X6 screws M3X6 screws Installationin: A = 0 Degree Installationin: B = 5 Degree A = 0 Degree C =10 Degree B = 5 Degree D =15 Degree C =10 Degree D =15 Degree Front Arms Mount...
- Page 6 Motor (Shaft size is 5mm ) 2204/2205/2206/2207 (Not Included) Motor screws (Not Included) Motor screws M3X6 screws (Not Included)
- Page 7 Motor (Shaft size is 5mm ) 2204/2205/2206/2207 (Not Included) M3X6 screws Motor screws (Not Included) Motor screws (Not Included)
- Page 8 Speed control (Not Included) M3 nut (Plastic) Flight control board Speed control (Not Included) (Not Included) Speed control (Not Included) Double Sticker Double Sticker...
- Page 9 hole for run cam 12/15/16mm Swift 2 / Swift / Owl Plus cam mount hole for adjustable camera Angle Camera M2 nut (Not Included) M2X12 screws cam mount brace M3X6 screws Main frame (side carbon panel) M3X6 screws M3X6 screws...
- Page 10 Rx and Vtx installation Rx and Vtx installation Method 2: Method 1: Transmission antenna Transmission antenna (Not Included) (Not Included) Video TX (Not Included) Receiver (Not Included) Double Sticker M3X6 screws M3X6 screws Double Sticker M3X6 screws M3X6 screws upper deck Need Conversion wire upper deck...
- Page 11 Rx and Vtx installation Rx and Vtx installation Method 1 Installation is hole Method 2: Method 1: Method 2 Installation is hole M3X6 screws M3X6 screws M3X6 screws M3X6 screws...
- Page 12 Sticker side Sponge Sticker Sponge side Battery (Not Included) Battery strap P.10...
- Page 13 Make sure Motor and propeller spin direction is correct As indicated below Motor 1 (Base setting) Motor Nut (Not Included) propeller Motor 2 (Base setting) Motor 3 (Base setting) Motor 4 (Base setting) P.11...
- Page 14 End of Assembly...
