Summary of Contents for Eldes EWR2
- Page 1 EWR2 WIRELESS SIGNAL REPEATER...
-
Page 2: Main Features
DS18B20 digital temperature sensor connection and allows to add up to 8 temperature sensors for temperature monitoring. In order to start using EWR2, it has to be bound to ELDES alarm system using ELDES Configuration Tool software or by sending a corresponding SMS text message to ELDES alarm system. -
Page 3: Technical Specifications
Maximum supported number of temperature sensors ....8 Range of operating temperatures ............-20...+55ºC Humidity ....................0-90% RH @ 0... +40 °C (non-condensing) Dimensions .....................94x137x25mm Compatible with alarm systems ............ELDES wireless 2.2. Main Unit and LED Indicator Functionality Main unit functionality LED indicator functionality... -
Page 4: Installation
6. Bind the device to the alarm system using ELDES Configuration Tool software. Open Wireless Device Management section, click on EWR2 icon and then click the Add button. Alternatively, you and enter a 8-digit wireless device ID located on the EWR2 enclosure and press Add button. - Page 5 10. Wireless devices communicating directly with ELDES alarm system are indicated by the green stripe above their icons. Wireless devices with a bad wireless signal level, detected by EWR2 are indicated by the blue stripe at the top left corner of their icons.
- Page 6 PCB supervising the front cover in case it is illegally opened (see fig. #1). • the other one located on back of the PCB supervising the back side of the enclosure in case the EWR2 is illegally detached from the wall (see fig. #1).
-
Page 7: Temperature Sensors
– wire up one after another in parallel – until the number of 8 sensors is reached. Once the temperature sensor (-s) is wired, it is necessary to enable it, using ELDES Configuration Tool software (after pairing EWR2 device with the system). This function is valid for: ESIM364 v02.11.00 and up;... - Page 8 • If signal level between a wireless device and ELDES alarm system is above 18%, EWR2 will take no action. • If the signal level between a wireless device and ELDES alarm system is below 18%, EWR2 will connect to the device and start expand- ing it’s signal range by transferring the data from a wireless device to ELDES alarm system and the other way around.
- Page 9 EWR2 Setup Time The time of connection of EWR2 to a wireless device may depend on the device type. In general, it takes approximately 10 minutes for EWR2 to detect and, if necessary, to connect to all wireless devices within it’s range. During the connection time EWR2 measures the signal level of a wireless device.
- Page 10 DEVICE WIRELESS DEVICE EWR2 automatically disconnects from a wire- less device under certain conditions: When the signal level between a wireless de- vice and EWR2 drops to 7% or lower. SIGNAL 51% SIGNAL 18% SIGNAL 7% MOVE CONNECTION OLD CONNECTION...
- Page 11 ELDES Configuration Tool software. EWR2 settings can be found in Peripheral Devices -> Wireless Repeaters section. You can disable or enable the repeating function of certain EWR2 repeaters by ticking or unticking the box near the repeater’s ID number. The ID number can be seen in ELDES Configuration Tool software, Wireless Device Management section.
-
Page 12: Restoring Default Parameters
2. Press and hold the reset button. 3. Connect the external power supply or USB cable to the PC. 4. Wait until the RED LED indicator quickly flashes several times. 5. Release the reset button. 6. Parameters restored to default. EWR2 Wireless Signal Repeater v1.1... -
Page 13: Additional Information
• DO NOT attempt to repair the system yourself - any repairs must be carried out by fully qualified personnel only The EWR2 can be powered by a 9-15V 300mA DC power supply unit, if no additional devices are connected. The device is not meant for outdoor use, i.e. - Page 14 Made in the European Union www.eldes.lt...
