Summary of Contents for RUGGEDGEEK GeekBeats JOLT5
-
Page 1: User Manual
WWW.RUGGEDGEEK.COM USER MANUAL GeekBeats JOLT5 Outdoor IP65 Bluetooth Speaker with Power Bank REV 1.02E... -
Page 2: Table Of Contents
THANK YOU Thank you for becoming part of the Rugged Geek family. The GEEKBEATS JOLT5 is a high quality Bluetooth speaker that also functions as a ™ speakerphone and can charge your USB devices. The JOLT5 is designed with you in mind. It features... -
Page 3: Get To Know Your Awesome Speaker
GET TO KNOW YOUR AWESOME SPEAKER FRONT Indicator lights: 4 red, 1 blue (lights are only visible when lit up) Power Button Play/Pause/ Volume Down/ Volume Up/ Answer Call/ Skip Back Skip Forward End Call RIGHT IN/Charging Port 3.5 mm Audio-in Aux Jack External USB Battery Check... -
Page 4: Charging Your Speaker
CHARGING YOUR SPEAKER Please fully charge the battery in the JOLT5 before using it for the first time. To charge the JOLT5, simply plug the included (or any) micro USB charging cable into the IN/ Charging Port (accessed by lifting the rubber protective cover) on the speaker and the other end into a powered USB port. -
Page 5: Power On & Get Connected
POWER ON & GET CONNECTED POWER ON To POWER ON the JOLT5, press the Power Button for a few seconds. You will see the indicator lights on the front of the speaker turn on and a tone will be emitted to let you know it is on. To POWER OFF the JOLT5, hold the power button down for a few seconds and you will hear a tone indicating it has... -
Page 6: Music & Audio Control
MUSIC & AUDIO CONTROL While playing music and other audio through a compatible Bluetooth connection, you are able to ™ play/pause, skip tracks and adjust the volume from the speaker itself. TO ADJUST THE VOLUME: Each single, quick press on the “+”... -
Page 7: Speakerphone
SPEAKERPHONE Your JOLT5 speaker can also function as a hands free speakerphone when connected to a compatible Bluetooth phone. ™ ANSWERING A CALL If a call comes in, simply press the “play/answer call button” to accept the call. If you answer the call on your phone instead, some phones may send the call through your phone instead and then you would have to manually select the JOLT5 as the audio source for... -
Page 8: Usb Charging
USB CHARGING The JOLT5 is designed to charge USB devices that draw from 0.3A – 1A (Most cell phones. Some tablets and devices requiring 2A may not be able to be charged by your JOLT5 speaker). TO USE USB CHARGING: 1. -
Page 9: Specs
SPECS BATTERY TYPE: Lithium-Ion BATTERY CAPACITY: 5,200 mAh @ 3.7v / 19.2 Wh BATTERY CYCLE LIFE: 1000+ PLAY TIME: ≈ 24 hours (varies by volume level and audio content) DRIVERS: 10W (5W per channel) FREQUENCY RESPONSE: 160Hz-20KHz OPERATING TEMPERATURE: -22°F (-30°C°) — +122°F (+50°C) INPUT (CHARGING) VOLTAGE: 5V / 1A OUTPUT (USB CHARGING): 5V/1A... -
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION My mobile a) Make sure the Speaker device does is in pairing mode and not detect the Bluetooth is turned on on ™ speaker? your device. b) Make sure you are within range of the speaker. c) Check that the device that you are attempting to pair with is Bluetooth compatible. -
Page 11: Warnings & Legal
WARNINGS & LEGAL SAFETY INFORMATION WARNING: PLEASE READ THESE SAFETY WARNINGS AND CAUTIONS CAREFULLY TO ENSURE YOUR PERSONAL SAFETY AND PREVENT PROPERTY DAMAGE. FIRE AND ELECTRIC SHOCK HAZARD Do not expose your JOLT5 to liquid, moisture, humidity, or rain. Do not use the JOLT5 near a bathtub, sink, sauna, pool, or steam room. - Page 12 BATTERY/CHARGER HAZARD Do not dispose of your JOLT5 in a fire. The battery could explode causing injury or death. Only charge the battery in accordance with the user instructions supplied in this manual using an appropriate micro-usb charging cable. Do not attempt to disassemble the JOLT5 charger or force open the built-in battery because this may result in electric shock.
- Page 13 FCC NOTICE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 14: Warranty & Support
WARRANTY & SUPPORT Rugged Geek (“RG”) warrants that it’s JOLT5 (“The Product”) will be free from defects in material and workmanship for a period of twelve (12) months from the date of purchase (the “”Warranty Period””). For defects reported during the Warranty Period, RG will, at its discretion, and subject to RG’s technical support analysis, either repair or replace any Product sold by RG that contains such a defect. - Page 15 2. Cosmetic damage that does not affect functionality. 3. Products where the purchase date is undeterminable. For additional warranty information and to register your product, please visit our website at WWW.RUGGEDGEEK.COM and click on “Support”. You may also email us directly at MAKEMEHAPPY@REGGEDGEEK.COM...
- Page 16 TO CHECK OUT OUR OTHER COOL PRODUCTS OR FOR ADDITIONAL PRODUCT USAGE INFORMATION AND VIDEOS PLEASE VISIT: W W W. R U G G E D G E E K . C O M...
