- Page 1 MASK4C(T) / MASK6C(T) Instruction manual...
- Page 3 Instruction manual MASK4C(T) / MASK6C(T) MASK4C(T) / MASK6C(T) manual...
-
Page 4: Safety Precautions
Design cabinet loudspeaker Safety precautions • Keep this manual for future reference. • Take care of the speaker wires, they should be free of damage. Damaged speaker wires may result in poor sound quality and can damage amplifiers. • No mains power shall be connected to the speakers, doing so will damage the speaker. - Page 5 Instruction manual MASK4C(T) / MASK6C(T) The enduring success story The origin of MASK loudspeakers goes back as far as 2006, when the introduction of MASK4 and MASK6 set an industry standard for numerous professional users all over the world. Reliability, sound performance, an unseen design and a unique ease-of-use Intelli- mount bracket resulted in an instant success in every major market worldwide.
- Page 6 Design cabinet loudspeaker Features • Timeless design • Weather resistant (aluminium grille) • ClickMount: click & connect • Connectors with passthrough and 0.14 – 4 mm² solid or stranded wire capacity • Wall and ceiling mountable • Integrated spirit level •...
- Page 7 Instruction manual MASK4C(T) / MASK6C(T) Downward listening axis 5° 5°...
- Page 8 Design cabinet loudspeaker Mounting & connecting the MASK4C(T) loudspeaker MASK4(T) vertical mounting CEILING speaker wires 80 mm...
-
Page 9: Horizontal Mounting
Instruction manual MASK4C(T) / MASK6C(T) The intelligent ClickMount mounting system helps you to install the MASK4C(T) speaker in a safe and easy way. Please note the minimum distance from the ceiling and wall as shown in the drawings below: MASK4(T) horizontal mounting CEILING speaker... - Page 10 Design cabinet loudspeaker Mounting & connecting the MASK6C(T) loudspeaker MASK6(T) vertical mounting CEILING speaker wires 80 mm...
- Page 11 Instruction manual MASK4C(T) / MASK6C(T) The intelligent ClickMount mounting system helps you to install the MASK6C(T) speaker in a safe and easy way. Please note the minimum distance from the ceiling and wall as shown in the drawings below: MASK6(T) horizontal mounting CEILING speaker...
- Page 12 Design cabinet loudspeaker • Determine the position where the ClickMount will be mounted on the wall. Please allow a minimum distance of 105 mm for MASK6C and 50 mm for MASK4C between the top of the ClickMount and the ceiling is necessary when installing the speaker in the upright position.
- Page 13 Instruction manual MASK4C(T) / MASK6C(T) • The speaker wires must be guided through the ClickMount bracket. • Open the connection terminals.
- Page 14 Design cabinet loudspeaker • Connect the speaker wires taking care of the polarity. Two positive and two negative connectors are supplied to allow speakers to be connected in a daisy chain system. • Click the cover plate in place.
- Page 15 Instruction manual MASK4C(T) / MASK6C(T) • Rotate the ClickMount as required by loosening the quick lock lever • Attach the SAFCAB cable to the rear of the speaker and attach the other end firmly to the wall close to the ClickMount (preferably above the ClickMount).
- Page 16 Design cabinet loudspeaker • MASK(4)(6)CT only: set the power selector in the required position. • Warning: the 16 ohm setting is not compatible with 70 or 100 volt line amplifiers! MASK4CT MASK6CT 16 ohm position: for low impedance amplifiers only! This switch position is not compatible with 70 / 100 volt line amplifiers! MASK4CT MASK6CT...
- Page 17 Instruction manual MASK4C(T) / MASK6C(T) • Fasten the quick lock lever and Click the speaker on the ClickMount until the unit clicks firmly in place. If necessary, adjust the lock tension from the quick lock lever. WARNING: do not push onto the grille. If the ClickMount •...
- Page 18 Design cabinet loudspeaker • The speaker can be mounted on the ClickMount in 4 ways: upright, 90° rotated to the left, 90° rotated to the right or at the ceiling. It is not possible nor allowed to mount the speaker upside down on the ClickMount.
- Page 19 Instruction manual MASK4C(T) / MASK6C(T) Note: All MASK models have a unique 3 stage overload protection, which is activated when the speakers are overloaded for long periods. When too much power is fed into your MASK, first the red led will blink when the music signal hits peak levels. When you neglect this early warning, the overload protection will disconnect the signal going to the loudspeakers and the red led will remain lit.
-
Page 20: Specifications
Design cabinet loudspeaker Specifications model name MASK4C MASK4CT Woofer size 4.25” tweeter size 1” loudspeaker system 2-way nominal impedance 8 ohms 16 ohms power @ 100 volts 2.5W / 5W / 10W / 20W power @ 70 volts 1.25W / 2.5W / 5W / 10W / 20W connector wire capacity 0.14 –... - Page 21 Instruction manual MASK4C(T) / MASK6C(T) model name MASK6T MASK6TC Woofer size 6.5” tweeter size 1” loudspeaker system 2-way nominal impedance 8 ohms 16 ohms power @ 100 volts 6W / 15W / 30W / 60W power @ 70 volts 3W / 7.5W / 15W / 30W / 60W connector wire capacity 0.14 –...
-
Page 22: Warranty Info
Apart Audio. The warranty only concerns the spare parts and not the involved labor, transportation or any other costs. The product must be returned in the original packaging with the proof of purchase by an Apart-Audio authorized reseller. - Page 24 Apart Audio nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart Audio specifications are subject to change without notice.
