Summary of Contents for NexComm Systems N560 series H/W
- Page 1 N560 series H/W Installation Guide N560 series H/W Installation Guide NexComm Systems, Inc. Tel: +82-31-781-1862, Fax: +82-31-781-1863 E-mail: support@nexcomm.co.kr NexComm Systems, Inc. 1 PAGE...
- Page 2 Copyright Copyright © 2007 NexComm Systems, Inc. All Rights Reserved. This document contains information that is the property of NexComm Systems, Inc. All or part of this document may not be copied, reproduced, reduced to any electronic medium or machine readable form, or otherwise duplicated, and information herein may not be used, disseminated or otherwise disclosed, except with the prior written consent of NexComm Systems, Inc.
- Page 3 N560 series H/W Installation Guide Change Histroy Version Date Effective H/W Description Rev 1.0 August 24th, 2010 H/W versions later than 0 Initial version Rev 1.1 May 6th, 2013 H/W version later than 1.9.0 Changes of MAX Rate NexComm Systems, Inc.
-
Page 4: Table Of Contents
N560 series H/W Installation Guide Contents Contents ............................4 Introduction ........................... 6 N560 series is......................6 Rules of Naming Models ..................6 List of the Models of N560 series ................6 N560 series Appearance ................... 7 Front / Rear Panel Features ....................8 Power Connector, Power Status LED and Reset Button ........ - Page 5 Production & Regulatory ..................23 Environment ......................23 A.1 Safety Information Warnings ..................24 A.2 Symbols ........................24 APPENDIX B. Technical Assistance ..................... 25 B.1 NexComm Systems’ Technical Support ..............25 B.2 Repair and Return Address ..................25 NexComm Systems, Inc. 5 PAGE...
-
Page 6: Introduction
N560 series H/W Installation Guide 1 Introduction This document provides the procedures for installing the NexComm Systems’ N560 series. 1.1 N560 series is.. N560 series, 2BASE-TL EFM EDD (Ethernet Demarcation Device) with two 100BASE-FX SFP ports, extends the reach of Ethernet services using bonded copper pairs and fiber optic cables. Designed with... -
Page 7: N560 Series Appearance
N560 series H/W Installation Guide 2 pairs ( p0, p3 ) N562 N56x (unsupported) 4 pairs ( p0, p1, p2, p3 ) N564 < Table 1-1 > Models of N560 series 1.4 N560 series Appearance Figure 1-1 shows exterior views of N560 series. Note that the appearances of N56xF and N56x are identical. -
Page 8: Front / Rear Panel Features
N560 series H/W Installation Guide 2 Front / Rear Panel Features Figure 2-1 shows the front panels of N560 series. In addition, it describes each part’s name. < Figure 2-1 > N560 series Front LEDs and Rear Ports 2.1 Power Connector, Power Status LED and Reset Button 2.1.1 Type of Power Supply... -
Page 9: Console Part
N560 series H/W Installation Guide Operation on Reset button Result Clicking System reset Pressing Until 2BASE-TL Blinks 5 Times System reset as factory default < Table 2 - 2 > Function of Reset Button 2.2 Console Part For connecting to a maintenance terminal (for example, PC), N560 series’ RS-232 interface provides a RJ-45 female connector. -
Page 10: 100Base-Fx Status Leds
N560 series H/W Installation Guide 2.3.2 100BASE-FX Status LEDs For each 100BASE-FX, N56xF has LEDs showing the status of the Port. Table 2-3 describes the LED’s function. LINK STATUS / ACTIVITY Fiber Optic port connected to the media GREEN Fiber Optic port disconnected to the media... -
Page 11: 2Base-Tl Port
N560 series H/W Installation Guide LAN Port (RJ-45) Pin-outs Signal Description RX+ / TX+ Input / Output RX- / TX- Input / Output TX+ / RX+ Input / Output TX- / RX- Input / Output < Figure 2-4 > Pin Assignment for LAN Port Connector 2.5 2BASE-TL Port... -
Page 12: 2Base-Tl Pme Status Leds
N560 series H/W Installation Guide Figure 2-5 lists the pin-outs for the RJ-45 connector. 2BASE-TL Port (RJ-45) Pin-outs Copper pair ( PME ) Pin Assignment Signal Ring Ring Ring Ring < Figure 2-5 > Pin Assignment for Each PMEs of 2BASE-TL Port 2.5.2 2BASE-TL PME Status LEDs... -
Page 13: Installing N560 Series
N560 series H/W Installation Guide LED State Description Data Link Down or Hand Shaking Slow Blinking Training GREEN (0~3) Fast Blinking Synchronizing Data Link Up YELLOW(S0) Blinking S0 (Pair 0~1) binging data is being tranceived YELLOW(S1) Blinking S1 (Pair 2~3) binging data is being tranceived <... -
Page 14: Connecting Power To N560 Series
N560 series H/W Installation Guide < Figure 3-1 > Cables in N560 series’s Package 3.2 Connecting Power to N560 series User should be cautious when connecting powers. AC power, which is plugged into the system directly or into the DC adaptor, has to be in appropriate range (+100 ~ +240V, 50-60 Hz). -
Page 15: Grounding N560 Series
N560 series H/W Installation Guide 3.2.2 Grounding N560 series Touching ports on the front panel or connecting cables may induce static electricity. In the extreme, this can damage the chipsets in the N560 series system. To prevent this effectively, user may wear a grounding wrist strap before installing or dealing with N560 series. -
Page 16: Connecting 100Base-Fx Port
N560 series H/W Installation Guide 3.4 Connecting 100BASE-FX Port < figure 3-4 > 100BASE-FX Port connection ① Insert SFP Module to the port named "100BASE-FX" on the front panel of the N56xF. ② Connect the assembled LC type Fiber Optic connector to SFP Module. -
Page 17: 2Base-Tl Synchronization
N560 series H/W Installation Guide ① To connect Lines to 2BASE-TL port in the equipment, four pairs of regular telephone lines preinstalled for the G.SHDSL.bis connection have to be clipped with a RJ-45 jack. Note that each pair of lines must be plugged in the correct combination of pins of RJ-45 jack (refer to Figure 2-4 ). -
Page 18: Verifying That N560 Series Is Operational
N560 series H/W Installation Guide 4 Verifying that N560 series is Operational The purpose of this section is to verify if the equipment is functioning normally after all installation process is done. User may step the following procedures. If the device turns out to be malfunctioning, user should refer to the troubleshoot section (section 6) in order to fix it. -
Page 19: Configuring N560 Series Through Console Connection
N560 series H/W Installation Guide 5 Configuring N560 series through Console Connection ① As described in section 3.5, user may plug the console cable into both PC and the equipment. ② Configure the communication settings of the PC’s terminal program, as below. -
Page 20: Troubleshooting N560 Series
N560 series H/W Installation Guide Troubleshooting N560 series When you have problems with N560 series, this troubleshooting section can be referred to. If you have difficulty in fixing it or the trouble is beyond this document, you may request a Technical Assistance to our technical support team. - Page 21 N560 series H/W Installation Guide In normal operation, the network LINK LED is on when a link is detected LINK / RX LED between the N560 and a remote device. (GREEN) 1. Verify that the CAT-5 cable is connected properly to a 10/100Mbps port on an operational Ethernet device.
-
Page 22: Specification
N560 series H/W Installation Guide 6 Specification 6.1 Mechanical & Power Requirement Dimension(mm): 238(W) X 182(D) X 47(H) Weight: 0.8 kg DC 5V 3.0A All Rear Access 6.2 Network Interface Four 10/100BASE-T Ports (RJ-45) ... -
Page 23: Vlan Support
N560 series H/W Installation Guide 6.5 VLAN Support Port-bases VLAN Tag-based VLAN (802.1Q) Up to 256 VLANs Double Tagging (Q-in-Q) VLAN Trunk mode 6.6 QoS Support Ingress Rate control Egress Traffic Shaping ... -
Page 24: Safety Information Warnings
N560 series H/W Installation Guide APPENDIX A. Safety Information A.1 Safety Information Warnings Install the equipment only as described in this document. Other manipulations may cause a problem to N560 series. Never install telephone wiring during a lightning storm. -
Page 25: Appendix B. Technical Assistance
E-mail access to the Technical Assistance Center is available at: support@nexcomm.co.kr B.2 Repair and Return Address Before you return a product to NexComm Systems, you must obtain a Returned Materials Authorization (RMA) number from the NexComm Systems Technical Assistance Center. The NexComm Systems repair and return address is:...
