Barron Games BG-FSBCO Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Coin-Operated Foosball
Serial #:
Distributed By:
Sales Person:
Technical Service #: +1-716-866-0054
v. 041917
SKU#: BG-FSBCO
U.S. Patent No. 9,144,733 (issued Sept. 29, 2015)
World Tour
Instruction Manual
Assembly, Operation, and Care Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG-FSBCO and is the answer not in the manual?

Questions and answers

Related Manuals for Barron Games BG-FSBCO

Summary of Contents for Barron Games BG-FSBCO

  • Page 1 SKU#: BG-FSBCO U.S. Patent No. 9,144,733 (issued Sept. 29, 2015) World Tour Coin-Operated Foosball Instruction Manual Assembly, Operation, and Care Instructions Serial #: Distributed By: Sales Person: Technical Service #: +1-716-866-0054 v. 041917...
  • Page 3 World Tour Foosball Table Instruction Manual Inspect Immediately after Transporting the Product After receiving the shipment, inspect the product thoroughly to ensure that it has been shipped with care. Before turning the power on, please check the following: • Check the cabinet for damage or shifting that may have occurred during shipping.

  • Page 4: Safety Instructions

    World Tour Foosball Table Instruction Manual Safety Instructions This equipment may contain hazardous voltage which can cause electrical shock. • Only qualified personnel* should work inside the equipment. *Note: Keep reading for a list of qualified personnel. • To maintain personal safety and the safe operation of this product, read the entire manual before using it.
  • Page 5 World Tour Foosball Table Instruction Manual Definition of Site Maintenance Personnel or Other Qualified Individuals WARNING Servicing and maintenance work of the contents herein stated should be performed by the SERVICEMAN stipulated as per IEC Standard. Those who do not have technical expertise and knowledge other than the SERVICEMAN are not allowed to perform the work herein stated. Executing the aforementioned work by such non-technical personnel can cause serious accidents that may endanger life. Replacing parts, maintenance inspections, and troubleshooting should be carried out by Site Maintenance Personnel or other Qualified Professionals. This manual includes directions for potentially dangerous procedures which should only be performed by professionals with appropriate and specialized knowledge.

  • Page 6: Before Using This Product

    If any label is peeled off, apply it again immediately. Please contact Barron Games Technical Support at 1+716-866-0054 or email service@barrongames.com if you are in need of new stickers or parts.
  • Page 7 World Tour Foosball Table Instruction Manual NSTALLATION AND AINTENANCE AFETY This product is an indoor game machine. Do not install it outside. Even indoors, avoid installing it in the places mentioned below, so as to avoid causing a fire, electric shock, machine malfunction, or even death. Do not install or maintain this product in/on/within/near: •...

  • Page 8: Tools Needed

    World Tour Foosball Table Instruction Manual ASSEMBLY Important Notes Read this Instruction Manual carefully before assembling or playing. Ensure that there is sufficient space to place and shift the product prior to assembly Two strong adults are recommended to assemble the product. Inspect and ensure all parts are securely attached before rotating the table.

  • Page 9: Assembly - Step

    World Tour Foosball Table Instruction Manual Assembly – Step (Prepare the Table) 1. Carefully open the packaging carton. TWO STRONG ADULTS are needed Open table at the hinges (like a chest) to assemble the table legs. and remove all accessories from inside. 2. Disassemble all the air connectors from all In order to assemble the legs, it is easiest to disassemble the wires that connect the upper and lower table so only the bottom half the table needs to be rotated. halves of the table. *Please note: The interior mechanisms of your model table may vary in slightly appearance from the instruction photos. 3. Adult #2 should support the top half of 4. Locate the bolts of the pneumatic lid- closer arm. The bolts are found on the the table while Adult #1 removes any top part of the table, near the track of additional connections. the arm. Page 7 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 10 World Tour Foosball Table Instruction Manual Assembly – Step (Prepare the Table) 5. Adult #2 should continue to hold the top half 6. Next, Adult #1 should remove the bolts on of table while Adult #1 removes the bolts the rightmost hinge to separate the top half from the arm (pneumatic lid-closer arm) at of the table. the top of the table. Only remove the bolts The left and center hinges are detachable, from the TOP HALF of table. you do not need to remove the screws, just slide apart to detach them. ** Be sure to have a safe place to store all the screws and bolts for reassembly. The detachable ones unhinge like this: 7. Ensure that all bolts, hinges, and air 8. Carefully set the top half of the table on a connectors that connect both halves of the piece of cardboard out of the way (glass table are disconnected. Then, lift the top half down). You will reattach the top half after of the table and separate it from the bottom. attaching the legs to the bottom half. Page 8 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 11 World Tour Foosball Table Instruction Manual Assembly – Step (Prepare the Table) 9. Assemble all 4 legs by attaching each foot. 10. Using both adults, turn the bottom of Screw 1 foot into the bottom of each leg. the table onto its side and affix the legs into the table using the (included) carriage bolts. Be sure to place a washer between the bolt head and the cabinet. 11. After ensuring all of the legs are tightly 12. Next, both adults should lift the top half secured, both adults should carefully lift of table up and combine it with the and rotate the table to a standing bottom half of table. position. Page 9 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 12 World Tour Foosball Table Instruction Manual Assembly – Step (Prepare the Table) 13. While Adult #2 holds the top half 14. Finally, reaffix the RIGHTMOST hinge. of the table, Adult #1 should reaffix the 2 detachable hinges together to reconnect the table. 15. Reattach the pneumatic arm at the top of 16. If your table arrived partially the table. assembled, you’re ready to skip to Assembly Step Reconnect all the air connectors that If you need to assemble the foosball link the top and bottom of the unit. players and rods, continue following these assembly instructions. Page 10 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 13 World Tour Foosball Table Instruction Manual Assembly – Step (Assemble the Rods & Players) If your World Tour Foosball table did not come partially assembled with the f oosball players and rods assembled in the table, please follow these additional i nstructions: 1. On the RIGHT SIDE OF THE TABLE, 2. On the RIGHT SIDE OF THE TABLE, remove the bolts from the upper side remove the end cap, corner pieces, and (only from the RIGHT side). metal parts. 4. Reinstall the factory-removed black 3. Carefully remove the tempered glass bearings on all the rod holes using a from the RIGHT SIDE of the table by nut driver and hardware provided. sliding it toward you. 5. Begin to assemble the rods and the players. Sort the foosball player rods by length: Page 11 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 14 World Tour Foosball Table Instruction Manual Assembly – Step (Assemble the Rods & Players) Use this page as a guide for assembling the rods and foosball players. Do not begin assembly until you have read ALL ASSEMBLY I NSTRUCTIONS! Page 12 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 15 World Tour Foosball Table Instruction Manual Use the included lubricating oil to aid in rod and player assembly. Assembly – Step (Assemble the Rods & Players) Part Part Name Part Part Name Plastic Rod Spacer Rod End Cap Foosball Player Rubber Rod Stopper Metal Place Holder *IMPORTANT NOTE* We recommend assembling all the pieces on the playfield f irst (before tightly securing the players to the rods) to make sure all the players are in the right position. Continue to STEP 3 to tightly secure the players once you’re positive everything is placed according to the aerial view. Begin assembling the rods from the left side of the table. Starting with the 1 -player rod (goalie rod/rod style #2/3-holed rod), slide the rod into the table. Next slide on a rubber stopper (F), a plastic rod spacer (E), a metal place holder i f goalie rod (C)* and the foosball player/s (B). The players will line up with small holes in the rod. Make sure the player is facing i n the proper direction.
  • Page 16 World Tour Foosball Table Instruction Manual This is a view from the top of what the rods, spacers, and foosball players should look like once assembled. If you have purchased a Metal Rod Protector Kit, please see the supplemental manual for installation instructions. Page 14 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 17 World Tour Foosball Table Instruction Manual Assembly – Step (Secure the Players to the Rods) Once all of the players and rods have been assembled, secure each player to the rod using a rubber mallet, two blocks of wood, one roll pin for each player, and the roll pin aid provided. To keep the rod from spinning, stabilize the bar using the 2 wooden blocks provided, shown here in blue. Turn the player facedown and adjust the player so that the hole on the player matches the rod hole. Adjust the player so that the hole in the pole lines up with the hole in the player. Insert the roll pin aid (stabilizer) into the hole from below. This will stabilize the player while you insert the roll pin from the top. Insert the roll pin into the top of the player and gently knock the roll pin through the player and rod with a small rubber mallet. Gently hammer the roll pin through the top of the player through the rod with a small rubber mallet. Remove the roll pin stabilizer from the bottom when it has been pushed more than half out. Once you have removed the roll pin stabilizer, use it to tap the roll pin (from the top) until the roll pin is completely flush with the player. Page 15 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 18 World Tour Foosball Table Instruction Manual Assembly – Step (Secure the Players to the Rods) After Assembling the Players 1. After putting the rods inside of the 2. Open the table and put ONE ball in table, reinstall the tempered glass the track. Also, put the PCB COVER carefully and retighten all the bolts. above the PC Board. Then, attach the 4 cup holders with hex bolts to each end (2 per short side). 3. Using the included allen key, secure each cup holder to the short ends of the table. There are 2 cup holders per table end (4 total). 4. Plug in the electrical cord and turn on the power (under the table on the right side) to ensure all lights, motors, and computer functions are operable.

  • Page 19: Internal Hardware

    World Tour Foosball Table Instruction Manual Assembly – Step (Program the PC Board) Internal Hardware Page 17 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 20 World Tour Foosball Table Instruction Manual Assembly – Step (Program the PC Board) Motherboard Controls Page 18 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 21 World Tour Foosball Table Instruction Manual Assembly – Step (Program the PC Board) DIP Switch Adjustments DIP SWITCH 1 Play in Order MUSIC Play Random DIP SWITCH 2 1 coin, 1 game 2 coins, 1 game COIN(S) 3 coins, 1 game 4 coins, 1 game 3 goals OFF OFF...
  • Page 22 World Tour Foosball Table Instruction Manual Assembly – Step Coin Comparator Instructions (U.S. Model Only) Coin Reject Button Coin Machine Key #8153 Lock Mounting Frame How to Set a Constant Coin Continue reading for a visual diagram of these steps. Step 1 Choose the desired coin for use and insert it in the clamp on the side of the coin comparator/coin mechanism.
  • Page 23 World Tour Foosball Table Instruction Manual Coin Comparator Operating Manual Coin Box Description Key for Coin Box #103 Lock Coin Box Frame Coin Box Access Door to Coin Box Size: W 175mm x L 145mm x H 175mm Page 21 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 24 World Tour Foosball Table Instruction Manual Assembly – Step Test the Table 1. Turn the table off and press K1 on the PC Board for audit 2. Press the K1 button on the PC Board 3. At the same time, turn on the power with the other hand Then on the screen of tact switches K1~K4, it’s shown here as 00...

  • Page 25: Troubleshooting

    World Tour Foosball Table Instruction Manual Troubleshooting Having trouble assembling your new table? Call our experts in the Parts and Service Department (1+716-866-0054) or email Service@BarronGames.com and we will be happy to assist you! We also have some great troubleshooting videos for World Tour on our youtube channel. Voltage Issues: Voltage issues may be due to a card swipe system attached to the table which is causing the power supply to be unstable.

  • Page 26: Error Codes

    World Tour Foosball Table Instruction Manual Troubleshooting the PC Board LED screens above the goals will show the errors codes when the table is out of order. When there is an error, press the Troubleshooting Button. Here is a list of error codes: Error Codes 10 Coin comparator 1: coin stuck 11 Coin comparator 2: coin stuck...
  • Page 27 World Tour Foosball Table Instruction Manual Troubleshooting the Elevating Device Grease the Ball Actuator If you are experiencing a malfunction with the elevating device, attempt to add a dab of grease before disassembling the ball actuator: 1. To prevent the mechanism from getting stuck, add some grease to the elevating device. This should help it lift more smoothly. 2. On the mechanism, pull the gate down and also put some grease on the elevating device; ONLY the area that touches the gate needs to be lubricated. 3. DO NOT put grease inside of the track, otherwise, the ball will become oily. CAUTION: PINCH POINT! Do not put fingers near elevating device. The actuator moves fast and will not stop until it has moved completely up or completely down. If you continue to experience malfunctions with the ball actuator / elevating device, continue troubleshooting. Reset the Actuator Motor 1. Loosen the 2 screws above the motor. 2. Loosen the 4 screws at the bottom of the device. Page 25 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 28 World Tour Foosball Table Instruction Manual Troubleshooting the Elevating Device 3. Press the K1 button on the PC board. At 4. The screen should show 00. the same time, turn on the power with your other hand. 5. Press the K2 button of the tact switches 6. Press the K1 button of the tact switches to confirm the several times, until the screen reads 08. action. Then, the motor will start to lift. 7. After attempting this several times, the 8. Re-tighten the 6 screws. lifting will become smoother. Then, press the K1 button of the tact switches to stop the lifting. Page 26 service@barrongames.com For assistance call: +1-716-866-0054...
  • Page 29 World Tour Foosball Table Instruction Manual Troubleshooting the Elevating Device 9. To retest the motor: Press the K2 button of the tact switches for several times, until 08 shown on the screen. Then, press the K1 button of the tact switches to confirm the action. The motor will start to lift. CAUTION: PINCH POINT! Do not put fingers near elevating device. The actuator moves fast and will not stop until it has moved completely up or completely down. 10. If the lifting remains smooth, it's fixed. Press the K1 button of the tact switches to stop the lifting. If not, please re-loosen the 6 screws and repeat the same steps. Troubleshoot the Ball Sensor Be sure to REMOVE THE BALL from inside the table first. No ball should be on the track or inside the actuator when this test is being administered. 1. Press K1 button on the PCB. At the same 2. The screen should show 00. time, turn on power with other hand. 3. Press the K2 button of the tact switches 4. If all sensors are functioning, four zeros will appear on several times, until the screen reads 03. the prompt (0000) indicating no sensors need repair. Page 27 service@barrongames.com For assistance call: +1-716-866-0054...

  • Page 31: Appendix A: Supplemental Manuals

    APPENDIX A: SUPPLEMENTAL MANUALS FOR GAME ACCESSORIES SKU#: FB-008-2 World Tour Foosball Metal Rod Protector Kit Assembly Guide Appendix A - Page 29 service@barrongames.com For assistance call: 1+(716) 866-0054...
  • Page 33 Appendix A – Metal Rod Protector Kit Installation Guide Inspect Immediately after Transporting the Product After receiving the shipment, inspect the product thoroughly to ensure that it has been shipped with care. Before attempting to install the rod protectors, please check the following: •...

  • Page 34: Assembly Notes

    Appendix A – Metal Rod Protector Kit Installation Guide ASSEMBLY NOTES 1. Read this Installation Guide carefully before beginning the installation. 2. Only qualified personnel who have technical expertise should perform the work stated herein to avoid hazardous situations. 3. Ensure that there is sufficient space to shift the product prior to installation. Do not drag the table when moving it, as this could damage the legs, levelers, or glass beyond repair.
  • Page 35 Appendix A – Metal Rod Protector Kit Installation Guide This guide instructs you on how to install metal rod protectors onto a pre-assembled foosball table. A fully-assembled table will look like this from above: Appendix A - Page 33 service@barrongames.com For assistance call: 1+(716) 866-0054...
  • Page 36 Appendix A – Metal Rod Protector Kit Installation Guide How to Install the Metal Rod Protectors Standing in front of the table where the locks Carefully remove the tempered glass from the are located, find the RIGHT SIDE OF THE TABLE. RIGHT SIDE of the table by sliding it toward From the right side, remove the end cap, corner you. Temporarily store the glass in a safe place. pieces, and other metal parts. 3. Beginning with the left side, slide the first rod 4. From the inner side of the table, remove the slightly out so that you can install the protector screws and black bearing from the rod hole. to the side opposite the handle. Note: Do not remove all the bearings. You do not need to remove them all from both sides of the table, only the bearings that will be covered with rod protectors. **Please Note: You may need to remove the foremost foosball player using the pin extractor to slide the rod out with enough room to work. For more information on how to remove a player, consult the World Tour Foosball Coin-Op Table Instruction Manual. Appendix A - Page 34 service@barrongames.com For assistance call: 1+(716) 866-0054...
  • Page 37 Appendix A – Metal Rod Protector Kit Installation Guide How to Install the Metal Rod Protectors If your table came with pre-drilled holes for the Temporarily affix the left and the right sides of the rod protectors, skip to the drilling steps. If you rod protector onto the table with two (2) of the need to drill additional holes: place a wooden panel longer bolts (4.75cm) and nuts. of scrap wood on the outer side of the table. From the inner side of the table, drill out the two (2) pilot holes until they become through holes. 7. Using the drill, make two (2) pilot/blind holes for 8. Unbolt and remove the rod protector. Place a the top and bottom bolts (pilot holes do not go all wooden panel of scrap wood inside the table and the way through the wood). continue to drill the 2 blind holes until they become through holes. Using scrap wood should Take care to drill straight minimize the potential for damage to the laminate into the table, not at an angle! while drilling. Appendix A - Page 35 service@barrongames.com For assistance call: 1+(716) 866-0054...
  • Page 38 Appendix A – Metal Rod Protector Kit Installation Guide How to Install the Metal Rod Protectors 9. Affix the metal rod protector using four (4) 10. The nuts should be snugly tightened from the bolts: 2 short (4.5cm) and 2 long (4.75 cm). inner side of the table. 11. Tighten a second nut on top of every first nut. 12. Repeat all the steps to install the remaining seven (7) metal rod protectors. Each side of the table will have four (4) rod protectors, from left to right: Long Rod Med Rod Short Rod Appendix A - Page 36 service@barrongames.com For assistance call: 1+(716) 866-0054...
  • Page 39 Appendix A – Metal Rod Protector Kit Installation Guide How to Install the Metal Rod Protectors 13. Insert the assembled foosball player rods into Once all the rod protectors have been installed the rod protector for each rod. and the rods have been inserted, reinstall the plate of tempered glass on the RIGHT SIDE. *Please Note: You will need to lubricate the rod as well as the bearings to slide the rods into the protectors with ease. From the right side of the table, reassemble the 16. Ensure all rods move smoothly and end cap, corner pieces, and metal parts. with ease inside the rod protectors. If the rods are sticking or do not move smoothly, apply more lubricant. Plug the table back in, turn on the power, and begin playing! See the full World Tour Foosball Table Instruction Manual for any troubleshooting. Having trouble installing your new Metal Rod Protector Kit? Call our experts in the Parts and Service Department (1+716-866-0054) or email Service@BarronGames.com and we will be...

  • Page 40: Care And Maintenance

    World Tour Foosball Table Instruction Manual After Installing the Game Check the voltage regularly to avoid a short circuit or potential fire. Do not overload the circuit. Keep the power cord out of areas with busy foot traffic to ensure the safety of users and the machine. Keep children away from all power sources.
  • Page 41 World Tour Foosball Table Instruction Manual Parts List: World Tour Coin-Op Foosball SKU# BG-FSBCO Part# Description Part # Description FB-A001 Main cabinet FB-B015 Safety button FB-A002 Tempered glass FB-B016 Coin box with lock FB-A003 Coin comparator FB-B017-1 Detachable hinge FB-A013 Metal frame FB-B017-2 Non-detachable hinge FB-A014-1 Faceplate for coin comparator FB-B018 Arm handle FB-A015...
  • Page 42 World Tour Foosball Table Instruction Manual Online Product Registration Link: http://barrongames.com/support/registration Page 40 service@barrongames.com For assistance call: 1+(716) 866-0054...
  • Page 43 World Tour Foosball Table Instruction Manual TROUBLESHOOTING QUICK LINKS Troubleshooting the PC Board LED screens above the goals will show the errors codes when the table is out of order. When there is an error, press the Troubleshooting Button. Here is a list of error codes: Error Codes 10 Coin comparator 1: coin stuck 11 Coin comparator 2: coin stuck...
  • Page 44 Barron Games International 84 Aero Drive, Suite 5 Buffalo, NY 14225 Phone: +1-716-866-0054 Fax: +1-716-630-0055 www.BarronGames.com For Parts and Service Information, please contact us: Phone: +1-716-866-0054 Email: Service@BarronGames.com...
