ACCESSORIES
A second answering set (handset) with its charging base and plug adapter. Operation
instructions and functioning of the additional handset are similar to the one in the original kit.
Therefore it is important to note that only one handset can answer a call (the fastest to
answer). Communication between two or more handsets is not possible.
Ref. GB Caritel 1010 B (black), 1010 MG (mint green), 1010 DG (dark green), 1010 P (pink),
1010 V (violet).
68 cm antenna, ref. Caritel 1068 (in case of necessity)
wall-mount box
INSTALLATION
of the front panel with the
wall-mount box
(distributed as accessory).
MPC ME CAR 1000 GB
12
GB
OPERATING INSTRUCTIONS
WIRELESS DOORPHONE
CARITEL 1000 B, CARITEL 1000 MG,
CARITEL 1000 DG, CARITEL 1000 P, CARITEL 1000 V
Ed 1.99
Advertisement
Summary of Contents for CARITEL 1000 B
- Page 1 Therefore it is important to note that only one handset can answer a call (the fastest to answer). Communication between two or more handsets is not possible. Ref. GB Caritel 1010 B (black), 1010 MG (mint green), 1010 DG (dark green), 1010 P (pink), 1010 V (violet).
-
Page 2: Installation
Your wireless doorphone CARITEL is composed of two parts : The fixed set (outside part) of your wireless doorphone encloses : The mobile set (handset, charging base and plug adapter ) The fixed set (front panel and electronic box) A front panel (D) with a visor, a call button and a wall box. - Page 3 Electronic box fig.5 Start the installation with it, the following instructions must be : 1 six-core flex and 2 leads come out of the box. The flex which is intended to be connected to the front panel has 6 terminal spades (G), it has to be passed through a hole (so the hole will be done according to the wall or pillar that has to be drilled).
- Page 4 Front panel 1•Gently remove the screw covers using a small screwdriver ( K ) (fig. 8) 2•Undo the Phillips screw ( L ) that is behind the cover ( K ) (fig. 9 & 10) 3•Tip the panel forward (fig. 9) 4•Remove the 2 screws ( N ) which keep the hinge in position (fig.
-
Page 5: Operation
OPERATION MEANING OF THE HANDSET INDICATORS The green light turns on when you press the ‘answer’ key to answer a call. It turns off When at home the antenna is fully extended and as the handset is on the charging base it has when the communication is over. - Page 6 CODING AND FREQUENCY CHANGING fig.12 CODING : All the sets have their code system (Dip-switch). At the factory, both the outdoor and the indoor sets are coded. In case a neighbour has the same device and the same code as you (you receive mistaken calls and communications), you will have to change the code that way : FREQUENCY CODING...
