INSTALLATION INSTRUCTIONS

MSD SYSTEMS

PN 8261
MSD SYSTEMS With an MSD Timing Control.
PN 8261
M S D
• W W W . M S D P E R F O R M A N C E . C O M • ( 9 1 5 ) 8 5 7 - 5 2 0 0 • F A X ( 9 1 5 ) 8 5 7 - 3 3 4 4
Single coil with an MSD Timing Control.
BLACK
ORANGE
COIL 1-
COIL 1+
COIL 2+
COIL 2-
SUPPLIED JUMPER*
SUPPIED JUMPER
HEAVY RED TO
BATTERY POSITIVE
HEAVY BLACK TO
BATTERY NEGATIVE
TO CHASSIS
PN 8261
BLACK
ORANGE
ORANGE
COIL 1-
COIL 1+
COIL 2+
COIL 2-
HEAVY RED TO
BATTERY POSITIVE
HEAVY BLACK TO
BATTERY NEGATIVE
TO CHASSIS
GRAY
BLUE
*NOTE: WHEN USING A SINGLE COIL, BOTH COIL POSITIVE
TERMINALS MUST BE CONNECTED TO THE COIL.
EITHER CONNECT BOTH ORANGE WIRES TO THE COIL,
OR USE THE SUPPLIED JUMPER TO CONNECT THE
COIL POSITIVE TERMIANLS AT THE TERMINAL STRIP.
BLACK
GRAY
BLUE
7
TO SWITCHED
12 VOLTS
TO SWITCHED
12 VOLTS
