WARNING: If the information in
this manual is not followed exactly, a
fire or explosion may result causing
property damage, personal injury or
loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch;
do not use any phone in your build-
ing.
•
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
•
If you cannot reach your gas sup-
plier, call the fire department.
— Installation and service must be per-
formed by a qualified installer, service
agency or the gas supplier.
R-2065
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
AND
VENTED
ROOM HEATER
MODELS
RH-25-5
RH-35-5
EFFECTIVE DATE
JUNE, 2000
WARNING: If not installed, operated
and maintained in accordance with the
manufacturer's instructions, this prod-
uct could expose you to substances in
fuel or from fuel combustion which can
cause death or serious illness.
Page 1
Advertisement
Table of Contents
Related Manuals for Empire RH-25-5
Summary of Contents for Empire RH-25-5
- Page 1 INSTALLATION INSTRUCTIONS OWNER’S MANUAL VENTED ROOM HEATER MODELS RH-25-5 RH-35-5 WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or other...
- Page 2 Warning: Any change to this vented room heater or its controls Heater pad is available from Empire Comfort Systems, Inc., can be dangerous. Any safety screen or guard re- Part No. RH-425. moved for servicing a vented room heater must be Specifications replaced prior to operating the vented room heater.
-
Page 3: Safety Information For Users Of Lp-Gas
SAFETY INFORMATION FOR USERS OF LP-GAS Propane (LP-Gas) is a flammable gas which can cause fires by point with the members of your household. Someday when there may not be a minute to lose, everyone's safety will and explosions. In its natural state, propane is odorless and colorless. - Page 4 Qualified Installing Agency (.3KW/H) of total input. The draft hood must be in the same atmospheric Installation and replacement of gas piping, gas utilization equipment or pressure zone as the combustion air inlet to the appliance. accessories and repair and servicing of equipment shall be performed only Gas Supply by a qualified agency.
- Page 5 Attention! If one of the above procedures results in pressures in excess On a new installation with air in the gas line, it is suggested that a match of 1/2 psig (14" w.c.) (3.5kPa) on the appliance gas valve, it will result in be used.
- Page 6 roper Pilot Flame (Figure 1) The correct flame will be almost horizontal, blue and will extend past the thermocouple 1/4" (6mm). The flame will surround the thermocouple just below the tip. On Propane (LP-gas) slight yellow might occur where the pilot flame and the burner flame meet.
-
Page 7: For Your Safety Read Before Lighting
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. A. This appliance has a pilot which must be lighted by •... - Page 8 AIR INLET BAFFLE 762141 PILOT BURNER WITH ORIFICE P-86-38N MAIN BURNER ORIFICE (RH-35-5 (NAT) NAT) 762247 PILOT BURNER WITH ORIFICE 742155 MAIN BURNER ORIFICE (RH-25-5 (LPG) NAT) RH-817 PILOT TUBING WITH FERRELLS 742260 MAIN BURNER ORIFICE (RH-35-5 732065 ELECTRODE AND WIRE LPG)
- Page 9 Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store. Shipments contingent upon strikes, fires and all causes beyond our control. Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62222-0529 R-2065...
- Page 10 OPTIONAL BLOWER DRB-1 Vented Room Heaters RH-25-(1, 2, 4, 5) and RH-35-(1, 2, 4, 5) Direct Vent Wall Furnaces DV-25-(1, 2)SG and DV-35-(1, 2)SG Installing Optional DRB-1 Blower 1. For RH-25-(1, 2, 4, 5) and RH-35-(1, 2, 4, 5), remove casing front.
-
Page 11: Parts List
Wiring The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70 or Canadian Electrical Code, CSA C22.1, if an external electrical source is utilized.
