- Page 1 Hand Held Post Hole Digger MODEL # 104306 Operation Manual is safety alert symbol identi es important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Part # 104893 Rev A...
- Page 2 For Service or Questions Call 1-877-487-8275 720-287-5182 www.dirtyhandtools.com Dirty Hand Tools® is a brand of 1100 W 120th Ave, Suite 600 Westminster, CO 80234 • 720-287-5182...
-
Page 3: Table Of Contents
Table of Contents Important Safety Information .............4 Intended Use ................4 Personal Protective Equipment ..........4 General Safety ................5 Safety Decals ................7 Auger Assembly ................8 Operation ..................10 Maintenance ................11 Troubleshooting ................11 Warranty & Speci cations ......... Back Cover... -
Page 4: Important Safety Information
Important Safety Information WARNING WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this post hole digger. Failure to do so may cause serious injury or death. Do not allow anyone to operate this post hole digger who has not read this manual. -
Page 5: General Safety
Important Safety Information DANGER GENERAL SAFETY Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. Read the Operation Manual before operation. • Do not permit others that have not read and understood the complete Operation Manual to operate this equipment. - Page 6 Important Safety Information DANGER ALWAYS turn off the post hole digger if a rock or other obstacle is encountered during operation to prevent damage to the equipment or possible operator injury. ONLY PERFORM MAINTENANCE such as lubrication, adjustments and repairs with the engine turned off and the spark plug wire detached.
-
Page 7: Safety Decals
Important Safety Information SAFETY DECALS Make sure all safety warning decals are attached and in readable condition. Replace missing or defaced decals. Contact Dirty Hand Tools at 1-877-487-8275 for replacement decals. CAUTION ! ■ READ MANUAL ■ POISON EXHAUST ■ MOVING PARTS ■... -
Page 8: Auger Assembly
Auger Assembly Attach the auger. Attach the auger to the output shaft on the bottom of the post hole digger, lining up the holes in the auger with the output shaft and securing with 1/2 in. x 2 in. shear pin and cotter pin. - Page 9 Components FUEL MUFFLER TANK ENGINE TRIGGER POWER ON/OFF SAFETY TRIGGER SWITCH CONTROL CAUTION ! FIRE DANGER FUEL WITH COOL ENGINE ! BIT SHOCK ABSORBER 2 CYCLE FUEL MIX: 25:1 GALLON 2.5 FL. OZ. 2-CYCLE SPARK PLUG WIRE CHOKE 8” DIA. LEVER AUGER AIR FILTER...
-
Page 10: Operation
Operation WARNING WARNING: Read and thoroughly understand all instructions FUEL MIX: and safety information before assembling or operating this post 25:1 hole digger. Failure to do so may cause serious injury or death. 2.5 FL. OZ. GALLON 2-CYCLE 1. In a separate container mix gasoline and 2-cycle engine oil in a ration of 25 parts gasoline to one part 2-cycle engine oil (approximately 1 gallon of gas to 2.5 fluid ounces oil). -
Page 11: Maintenance
Maintenance WARNING ALWAYS PERFORM MAINTENANCE OPERATIONS WITH THE ENGINE POWERED OFF, THE SPARK PLUG WIRE DETACHED, AND THE AUGER TIP RESTING ON THE GROUND Replace the cutting blade on the auger when it shows excessive wear or it is unusually difficult to drill holes. To remove the cutting blade from the auger, remove the two 1/2 in. -
Page 12: Warranty & Speci Cations
10 in. auger, part #104884 Shipping Weight 35 lbs Warranty 2 Year Limited Warranty For Service or Questions Dirty Hand Tools® is a brand of Call 1-877-487-8275 720-287-5182 1100 W 120th Ave., Suite 600 www.dirtyhandtools.com Westminster, CO 80234 • 720-287-5182...
