Summary of Contents for Revo 10CX
- Page 1 10CX MARINE COAXIAL / FULL RANGE SPEAKER SYSTEMS OPERATION INSTALLATION MANUAL wetsounds.com...
- Page 2 PLEASE TAKE A MOMENT TO READ THE INSTRUCTION MANUAL BEFORE STARTING YOUR INSTALLATION. IF YOU HAVE ANY QUESTIONS OR CONCERNS, PLEASE CONTACT YOUR CERTIFIED WET SOUNDS DEALER OR WET SOUNDS AT: 877-WET-SPKR (1-877-938-7757) www.wetsounds.com Wet Sounds REVO CX Operations / Installation Manual...
- Page 3 The REVO 10 CX series is equipped with a 1.25” titanium dome tweeter. RGB LED lighting is included on the underside of the tweeter for a wide variety of colors to be viewed on the cone. REVO 10 CX series speakers are built with Aluminum baskets, providing improved marine stability and strength over conventional materials used in most marine speakers.
- Page 4 RGB LED wire is attached using both fixtures & 2-sided tape. 2. The tweeter wire on the woofer should be routed through the opening in the basket. The RGB wire has a separate opening in the basket. Wet Sounds REVO CX Operations / Installation Manual...
- Page 5 4. With the grill in place, route the RGB LED wire through the slot in the basket & make sure the RGB wire is flat against the lip of the basket. Affix the RGB wire into the slot using a wire tie. Wet Sounds REVO CX Operations / Installation Manual...
- Page 6 Once these 2 screws are in place, affix the remaining screws, which will attach both the woofer and the grill. YOU HAVE NOW SUCCESSFULLY INSTALLED THE REVO 10 CX SPEAKER! Wet Sounds REVO CX Operations / Installation Manual...
- Page 7 Labor costs and materials needed to complete this service will be at No Charge to the purchaser. Additionally, return shipping FROM Wet Sounds, Inc. to the purchaser will be paid for by Wet Sounds. Wet Sounds REVO CX Operations / Installation Manual...
- Page 8 LIMITED WARRANTY HOW TO GET SERVICE Contact Wet Sounds, Inc. either by phone (877-938-7757) or by email (warranty@wetsounds.com). A service representative will assist you in confirming that the problem you are experiencing is caused by a defective product and if that product is covered under warranty. The service representative will issue you a Return Manufacturer’s Authorization (RMA) and other details to obtain service for your product.
