Summary of Contents for Proview PA-15BA7
-
Page 2: Federal Communications Commission (Fcc) Statement
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits of a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. - Page 4 IMPORTANT SAFETY INSTRUCTIONS To prevent any injuries, the following safety precautions should be observed in the installation, use, servicing and maintenance of this equipment. Before operating this equipment, please read this manual completely, and keep it nearby for future reference. Important Safety Instructions This symbol indicates caution points.
- Page 5 ▪ To reduce the risk of fire or electric shock, Do not expose this appliance to rain or moisture. ▪ Do not install the equipment near any heat sources such as radiators, heat registers, stoves, or any other apparatus that might produce heat. ▪...
- Page 6 Please do not remove or damage it. 7. To maintain the water-resistant functions, please inspect the TV periodically, once every two years by a certified Proview service center. The inspection will acquire a nominal charge. PLEASE NOTE:...
-
Page 7: Antenna Connection
ANTENNA CONNECTION EXAMPLE OF OUTDOOR ANTENNA GROUNDING If an outdoor antenna is connected, follow the precautions below: An outdoor antenna should not be located in any area where it could come in contact with overhead power lines, or any other electric light or power circuits. When installing an outdoor antenna system, extreme caution should be taken to prevent contact with power lines. -
Page 8: Table Of Contents
CONTENTS FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT ........1 IMPORTANT SAFETY INSTRUCTIONS ................2 ANTENNA CONNECTION ....................6 CONTENTS ......................... 7 PREPARATION Features ........................8 Package Contents ......................9 Your LCD TV View Front ......................10 Rear View ......................11 Remote Control ...................... -
Page 9: Preparation
▪ WIDE VIEWING ANGLE Watching attractive digital video from anywhere in the room, thanks to PROVIEW’s wide viewing angles. Viewing angles range up to 160º in both the horizontal and vertical planes, increasing mounting options. Lie in the bathtub or stand up for a shower –... -
Page 10: Package Contents
Package Contents Make sure all of the following contents are included. If you are missing any items, please return this product to the original place of purchase. LCD TV SOURCE DIGEST MANUAL DISPLAY INFO LIST MENU EXIT RETURN ENTER VOL. C.C. -
Page 11: Your Lcd Tv
Your LCD TV Front View ITEM DESCRIPTION The LED light indicates when the LCD TV is activated (blue 1 LED light indicates on and amber indicates off). 2 IR Infrared Receiver Adjusts the volume up and down. Selects the main menu item 3 VOLUME and change values for items when in the OSD mode. -
Page 12: Rear View
Your LCD TV Rear View DC IN AUDIO IN TV ANT. S-VIDEO VIDEO ITEM DESCRIPTION 1 DC IN Connects to a wall outlet via the included power adapter. Connects to the S-VIDEO output jack on external video 2 S-VIDEO equipment. Connects to the VIDEO output jack on external video 3 VIDEO equipment. -
Page 13: Remote Control
Remote Control Turns your LCD TV on and off. SOURCE Selects the video equipment connected SOURCE DIGEST MANUAL to the video input of your LCD TV: TV/VIDEO/S-VIDEO DISPLAY INFO LIST DISPLAY MENU EXIT Displays information on the Carry TV screen such as channel and channel label. -
Page 14: Installing The Batteries In Your Remote Control
Installing the Batteries in Your Remote Control Use a coin to open the back cover to remove the battery compartment of the remote control. Insert one CR2032 size battery. Make sure to match the (+) and ( - ) sides of the battery with the (+) and ( - ) sides indicated in the battery compartment. -
Page 15: Installation
INSTALLATION Refer to the owner’s manual of any external equipment to be connected. When connecting any external equipment, do not connect any AC power cords to wall outlets until all other connections are completed. Connecting a TV Cable or Antenna Basic Connection: Connect the supplied antenna cable. - Page 16 A. Combination VHF/UHF antenna VHF/UHF Antenna 300/75-ohm adapter (not included) VHF/UHF Antenna 300-ohm twin- lead cable 75-ohm coaxial cable B. Separate VHF and/or UHF antennas Antenna Antenna Combiner 300-ohm twin- (not included) lead cable 75-ohm coaxial cable 300-ohm twin- lead cable INSTALLATION...
- Page 17 CABLE TV (CATV) Connecton NOTE TO CATV SYSTEM INSTALLER This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code (NEC) that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building accurately, or as close to the point of cable entry as possible.
- Page 18 In order to ensure a healthy and relaxed body position when using the TV at visual display workstations, you are able to adjust the monitor’s angle of the stand. The stand angle of the LCD TV may be adjusted as shown: Use a antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT.
-
Page 19: Connecting An External A/V Device
Connecting an External A/V Device Method 1: Use an AV cable to connect the external A/V device’s audio and video output jacks to the LCD TV’s audio and video inputs. Method 2: Use an audio cable to connect the A/V device’s audio output jacks to the LCD TV’s audio inputs. - Page 20 Press the button on the remote to turn on the LCD TV. To view the A/V device’s input, press the button on the remote repeatedly SOURCE to select , or AV(METHOD 1) S-VIDEO(METHOD 2). INSTALLATION...
-
Page 21: Using The Features
USING THE FEATURES Setting up the Channel List With the LCD TV connected to a television MENU programming source, press the button on the VIDEO ADJUSTMENT remote control. CHANNEL SETTING C.C./V-CHIP AUDIO SETUP Press the button on the remote control to MENU SETUP MENU display the OSD menu, and use ▼... -
Page 22: Watching Your Lcd
Watching Your LCD Press the button to turn the LCD TV on. SOURCE DIGEST MANUAL Press the button to select TV. SOURCE DISPLAY INFO LIST MENU EXIT Press the ▲▼ buttons to change channels, or use the buttons to choose a channel, then press the button. -
Page 23: Using The Menu
Using the Menu To select the signal source, press the button on the remote control. MENU The main menu will appear on the screen. MENU VIDEO ADJUSTMENT CHANNEL SETTING C.C./V-CHIP AUDIO SETUP SETUP MENU RESET EXIT ▲▼ : MOVE OK : SELECT Use ▲▼... -
Page 24: Video Adjustment Menu
VIDEO ADJUSTMENT Menu The OSD displays: VIDEO ADJUSTMENT CONTRAST BRIGHTNESS SATURATION SHARPNESS COLOR TEMPERATURE RETURN ▲▼ : ◄► : MOVE ADJUST menu includes the following options: VIDEO ADJUSTMENT DESCRIPTION OPTION CONTRAST Controls the difference between the brightest and darkest regions of the picture. BRIGHTNESS Controls the overall brightness of the picture. -
Page 25: Channel Setting Menu
CHANNEL SETTING Menu If the signal source is , the OSD displays: CHANNEL SETTING TUNER MODE CH SEARCH CH MEMORY FINE TUNE RETURN ▲▼ : MOVE OK : SELECT menu includes the following options: CHANNEL SETTING OPTION DESCRIPTION Select the tuner input source: TUNER MODE Antennae: AIR Cable: STD, IRC, and HRC... -
Page 26: C.c./V-Chip Menu
C.C./V-CHIP Menu The OSD displays: C.C./V-CHIP C.C./V-CHIP C.C. OFF INPUT SECRET No. - - - - RETURN ▲▼ : OK : MOVE SELECT menu includes the following options: C.C./V-CHIP OPTION DESCRIPTION C.C./V-CHIP Allows to select from 4 closed caption modes: CC/CC/CC/CC: Display a printed version of the dialog and sound effects of the program being viewed. - Page 27 Using the V-CHIP setting: The US has 2 rating system for viewing content: Movie blocking(MPAA) and TV Blocking. The TV Blocking conjuncts with the V-CHIP to help parents block inappropriate programs from their children. The Movie blocking(MPAA) is used for original movies rated by the Motion Picture Association of America(MPAA) as broadcasted on cable TV and not edited for television.
- Page 28 TV GUIDELINE has 1 rating methods: Age-Based Rating. TV GUIDELINE includes the following options: AGE-BASED RATING DESCRIPTION All children TV-Y Directed to children age 7 and older TV-Y General Audience TV-G Parental Guidance suggested TV-PG Parents strongly cautioned TV- Mature Audience only TV-MA ...
-
Page 29: Audio Setup Menu
AUDIO SETUP Menu The OSD displays: AUDIO SETUP BASS TREBLE BALANCE MUTE RETURN ▲▼ : ◄► : MOVE ADJUST menu includes the following options: AUDIO SETUP OPTION DESCRIPTION Press ◄ ► to adjust the intensity of lower-pitched audio BASS components from 0 to 100. Press ◄... -
Page 30: Setup Menu
SETUP Menu The OSD displays: SETUP MENU LANGUAGE ENGLISH SLEEP TIMER H POSITION V POSITION OSD TIME OUT RETURN ▲▼ : ◄► : MOVE ADJUST menu includes the following options: SETUP OPTION DESCRIPTION LANGUAGE Choose the OSD menu language from among: English, Chinese (Traditional), Chinese (Simplified), Portuguese, French, Deutsch, Poland, Netherland, Italiano. -
Page 31: Troubleshooting
TROUBLESHOOTING Before consulting service personnel, check the following chart for a possible cause of the trouble and for a possible solution. PROBLEM SOLUTION Make sure the power cord is plugged in, then press TV will not turn on • button on the remote. •... -
Page 32: Specifications
SPECIFICATIONS Panel System 15 inch Display Resolution 1024 pixels (horizontal) x 768 pixels (vertical) NTSC Television System Inputs /Outputs Composite Video In S-Video In Audio In Analog TV Tuner SPEAKER OUT 3W x 2 POWER SOURCE 12V DC, 4A, 48W (Power consumption(Max)) DIMENSION 14.8(w) x 12.7(h) x3.4(d) inch...
