  • Page 1 F 220 NT Installationsanleitung Installation Instructions...
  • Page 2: Table Of Contents

    F 220 NT Vorschriften, Richtlinien und Regeln Installationsanleitung Inhaltsverzeichnis Vorschriften, Richtlinien und Regeln ....2 Gerätebeschreibung ........... 3 • Planungshinweise ..........6 • • Installation ............8 • • • • Erstinbetriebnahme ........... 14 • Außerbetriebnahme ........... 14 • Frostgefahr ............14 Anforderungen an das Heizungswasser ..
  • Page 3: Gerätebeschreibung

    Gerätebeschreibung Lieferumfang • • • rapidomatic  ® 1 Kessel im Block 3 Verkleidung Abb. 2.1 Abb.2.2 2 lose Kesselglieder 3 Verkleidung 5 Kesselteile 4 Schaltpult SP 2.2 Abb.2.3...
  • Page 4 Abmessungen Abb. 2.5 Geräteabmessungen F 220 NT Maße mm F 220/7 NT F 220/8 NT F 220/9 NT F 220/10 NT F 220/11 NT F 220/12 NT F 220/13 NT 1100 1100 1100 1100 1100 1100 1100 1100 1210 1320...
  • Page 5 Technische Daten Gerätetyp F220 /7 NT /8 NT /9 NT /10 NT /11 NT /12 NT /13 NT Leistungsbereich Nennwärmeleistung 80/60°C 70-90 80-105 95-125 110-145 125-165 140-190 160-215 Nennwärmebelastung 76-98,8 87-115,1 103-136,8 120-158,4 136-180,1 152-207,1 174-234 Betriebsdaten Gliederzahl Max. Betriebsüberdruck Max.
  • Page 6: Planungshinweise

    Planungshinweise Abb. 3.2 Beton Bewehrung Schalldämmung Sockel Flachstahl Breite 120 mm Aufstellungsort Versiegelung (fakultativ) Abb. 3.3 F220 /7 NT /8 NT /9 NT /10 NT /11 NT /12 NT /13 NT L / mm 1140 1270 1400 1530 1660 1790 1920 A / mm 1040...
  • Page 7: Installation

    Heizungsanlagenschema Nennwärmeleistung (kW) Mindesförderstrom Bypasspumpe (m /h) = Nennwärmeleistung (kW) Mindestförderstrom Heizungspumpe bei ΔT=10K (m /h) = 11,6 Nennwärmeleistung (kW) Mindestförderstrom Heizungspumpe bei ΔT=20K (m /h) = 23,2 Abb. 3.4 Klassische Kesselinstallation mit Rücklaufanhebung...
  • Page 8: Installation

    Installation Montage des Kesselblocks Abb. 4.1 Pos. Benennung Pos. Benennung Kesselglied vorne Ankerstange M12x925 Kesselglied Mitte (ohne Standfüße) Ankerstange M12x1255 Kesselglied Mitte (mit Standfüßen) Ankerstange M12x1140 Kesselglied hinten Ankerstange M12x1375 Strahlungswandler Ankerstange M12x720 Reinigungsdeckel Abgassammelkasten Ankerstange M12x830 Brennertür Ankerstange M12x1050 Tauchhülse Mutter M12 Verschlußstopfen 1 1/4"...
  • Page 9 • • • Abb. 4.2 Abb. 4.3...
  • Page 10 Montage der Kesselverkleidung Abb. 4.4 Abb. 4.5 Pos. Benennung F220 /7 NT /8 NT /9 NT /10 NT /11 NT /12 NT /13 NT Steckzapfenklemme 1058 1168 1278 1388 1498 Verkleidung hinten 1100 Befestigungsblech für Verkleidung seitlich — — — —...
  • Page 11 Abb. 4.6 Abb. 4.8 Abb. 4.9 Abb. 4.7...
  • Page 12 Montage des Schaltpultes (Zubehör) Abb. 4.12 Abb. 4.10 Abb. 4.13 Beachten Sie bei der Elektroinstallation die Installationsanleitung des Schaltpultes. Abb. 4.11...
  • Page 13 Rauchgasseitiger Anschluss Montage des Brenners (Zubehör) Da es sich um einen Kessel für die Überdruck- feuerung handelt, ist nach der Montage des Brenners der Spalt zwischen dem Brenner- Voraussetzung für die optimale Funktion der flammrohr und der Türisolierung sorgfältig Feuerungsanlage ist der richtig dimensionier- mit einer Schnur aus Isolierungsmaterial ab- te Schornstein.
  • Page 14: Erstinbetriebnahme

    Erstinbetriebnahme Anforderungen an das Heizungswasser • • • • rapidomatic ® • • • • • • Außerbetriebnahme der Anlage • • Frostgefahr...
  • Page 15: Reinigung, Pflege Und Wartung

    Reinigung, Pflege und Wartung Abb. 9.3 Abb. 9.1 Abb. 9.4 Abb. 9.2...
  • Page 16 Konformitätserklärung F220 NT/ RAPIDO WÄRMETECHNIK GMBH Technische Änderungen, auch ohne vorherige Ankündigung, vorbehalten. Die Abbildungen zeigen eventuell Ausstattungsvarianten, die nicht in alle Länder geliefert werden, bzw. in allen Ländern zugelassen sind. Bestimmte Abbildungen erfolgen mit Zubehören, die nicht im Grundpreis des Gerätes enthalten sind.
  • Page 17 F 220 NT Installation Instructions...
  • Page 18: Rules, Regulations & Guidelines

    F 220 NT Rules, Regulations & Guidelines Installation Instructions Table of Contents Rules, Regulations & Guidelines ..... 18 Equipment Description ........19 • Planning notes ........... 22 • • Installation ............24 • • • • Commissioning ..........30 •...
  • Page 19: Equipment Description

    Equipment Description Scope of supply • • • rapidomatic  ® 1 Boiler block 3 Casing Fig. 2.1 4 Control panel SP 2.2 Fig. 2.2 2 Loose boiler sections 3 Casing 5 Boiler parts 4 Control panel SP 2.2 Fig. 2.3...
  • Page 20 Dimensions Fig. 2.5 Dimensions of unit F 220 NT Dim. mm F 220/7 NT F 220/8 NT F 220/9 NT F 220/10 NT F 220/11 NT F 220/12 NT F 220/13 NT 1100 1100 1100 1100 1100 1100 1100 1100...
  • Page 21 Technical data Boiler type F220 /7 NT /8 NT /9 NT /10 NT /11 NT /12 NT /13 NT Capacity range Nominal heating capacity 80/60 °C 70-90 80-105 95-125 110-145 125-165 140-190 160-215 Nominal heating rating 76-98.8 87-115.1 103-136.8 120-158.4 136-180.1 152-207.1 174-234 Operating data Number of sections Max.
  • Page 22: Planning Notes

    Planning Notes Fig. 3.2 Concrete Beton Reinforcement Bewehrung Sound insulation Schalldämmung Foundation Sockel Place of installation Flat steel bar Flachstahl Width 120mm Breite 120 mm Sealing Versiegelung (optional) (fakultativ) Fig. 3.3 F220 /7 NT /8 NT /9 NT /10 NT /11 NT /12 NT /13 NT L / mm 1140 1270...
  • Page 23 Heating System Layout Nominal thermal output (kW) Min. pump flow of by-pass pump (m /h) = Nominal thermal output (kW) Min. pump flow of heating pump at ΔT=10K (m /h) = 11,6 Nominal thermal output (kW) Min. pump flow of heating pump at ΔT=20K (m /h) = 23,2 Dibo-...
  • Page 24: Installation

    Installation Assembly of the boiler block Fig. 4.1 Pos. Designation Pos. Désignation Boiler section, front Anchor rod M12x925 Boiler section, middle (without feet) Anchor rod M12x1255 Boiler section, middle (with feet) Anchor rod M12x1140 Boiler section, rear Anchor rod M12x1375 Radiation converter Anchor rod M12x720 Cleaning cover, waste gas collecting box...
  • Page 25 • • • Fig. 4.2 Fig. 4.3...
  • Page 26 Assembly of Boiler Casing Fig. 4.4 Fig. 4.5 Pos. Designation F220 /7 NT /8 NT /9 NT /10 NT /11 NT /12 NT /13 NT Plug clamp 1058 1168 1278 1388 1498 Casing, rear hinten 1100 Fastening plate for lateral casing —...
  • Page 27 Fig. 4.6 Fig. 4.8 Fig. 4.9 Fig. 4.7...
  • Page 28 Control Panel Assembly (accessory) Fig. 4.12 Fig. 4.10 Fig. 4.13 During electrical installation observe the installation instructions for the control panel. Fig. 4.11...
  • Page 29 Connection on flue gas side Burner assembly (accessory) Since the boiler is designed for overpressure firing, the gap between burner flame pipe and door insulation must be carefully sealed with The properly dimensioned chimney is a a strip of insulating material after the burner prerequisite for the optimal function of the installation.
  • Page 30: Commissioning

    Commissioning Heating Water Requirements • • • • rapidomatic ® • • • • • • Shutting down the System • • Danger of Frost...
  • Page 31: Cleaning, Care & Maintenance

    Cleaning, Care & Maintenance Fig. 9.3 Fig. 9.1 Fig. 9.4 Fig. 9.2...
  • Page 32: Declaration Of Conformity

    Declaration of Conformity F220 NT/ RAPIDO WÄRMETECHNIK GMBH Subject to technical modifications without prior notification. The illustrations show possible equipment variants which are not delivered to all countries or approved for all countries. Particular illustrations include accessories not covered by the base price of the unit.
