POLARIS TIMER CONSOLE
Timer Console Power
Batteries
The new Polaris timer is powered by four AA alka-
line batteries instead of an AC adapter as in the past.
The timer runs 50 to 60 hours on a new set of batter-
ies. Always turn the timer off before changing the
batteries and always replace all four batteries at the
same time – do not mix old and new batteries.
To check the battery level, follow these steps:
1) Press SETUP to access setup functions.
2) Press NEXT CHOICE until Check Battery is
displayed (just one or two presses).
3) Press ENTER to show remaining battery life.
4) Press SETUP to return to normal operation.
Keep in mind that when the console is first turned on
after being off for a while (e.g., overnight), the re-

Timer Connections

Connections on the rear of the timer console have
changed with the introduction of the new Polaris
timer. The jack is gone and in its position is
Power
the Input jack. The Input
optional input devices such as a bar code reader and
numeric keypad to be offered in the future. Do not
plug an AC adapter from an older FarmTek timer
into the jack on the new Polaris. It can cause
Input
serious damage!
©
FarmTek, Inc.
jack is for connection of
ported battery level is artificially high for the first
half-hour or so of use.
When storing the timer console for an extended pe-
riod, it is best to remove the batteries.
Low Battery Warning
A low battery icon is flashed in the upper right cor-
ner of the Status display when about 2 to 4 hours of
console battery life are left. Note that the battery
icon is also displayed whenever an electric eye in
the arena has a low battery. Check the console's
battery level as described previously to see if it is
the reason the icon is flashing.
Power On/Off
Turn the Polaris timer on and off using the slide
switch located at the upper right corner of the timer
console.
The Display jack is now called the
however, its functions are the same: Output of score-
board data and output of computer/printer data.
The functions of the
Horn
the previous version of the Polaris timer: It provides
audio output of the horn sound to a PA system and
also connects to our stand-alone horn.
Output jack,
jack are unchanged from
