Summary of Contents for Creator LAN G15
- Page 1 User ’ Manual User ’ Manual Programmable Touch Screen Programmable Touch Screen V1.1 CREATOR Corporation (CHINA)
- Page 2 Meaning of the icons ■ Safety Instruction Symbols are used in the Manual and devices, referring to the possible risk to users or others ， as well as the damage to property, for helping you to safely and properly use the devices. The instruction and the implications are as follows.
- Page 3 Important Notices Note in Wiring ◆ Installation and wiring shouldn't be conducted Caution To ensure the device in reliable use and personal until external electric power is cut off, otherwise, safety, please abide by the following items when in electric shock or device damage could happen. installation, use and maintenance: ◆...
- Page 4 Please refer to the manufacturer or dealers for inquiry. CREATOR Electronics own the copyright of the Manual. Without permission, any unit or person shall not take part or total of the Manual for business purpose.
-
Page 5: Table Of Contents
Chapter 1 Overview..............................1 System Introduction............................1 Functions and Features...........................1 Regular Operations............................1 LAN G15 Dimension............................. 2 Installation of Touch Screen Driver....................... 2 1.5.1 Touch Screen Driver under Windows XP..................2 1.5.2 Touch Screen Driver under Other Windows Systems..............4 Chapter 2 Touch Screen..............................5 2.1 Panel Instruction..............................5... -
Page 6: Chapter 1 Overview
User’s Manual of LAN G15 Programmable Touch Screen Chapter 1 Overview several dozen times of speed of USB 1.1, 1.1 System Introduction convenient for the download of programmed multiple language control picture and information CR-LAN G15 Programmable Touch Screen is picture. -
Page 7: Regular Operations
User’s Manual of LAN G15 Programmable Touch Screen fashionable and beautiful outlook design. 1.3 Regular Operation ◆ Turn on Directly touch the screen area to turn it on. ◆ Turn off Configure the property setup of touch screen to delay power off. -
Page 8: Installation Of Touch Screen Driver
User’s Manual of LAN G15 Programmable Touch Screen 图 1-2 1.5 Installation of Touch Screen 4.Select “install from list or appointed position Driver (premier)(s)”, click on “Next step” to see 1.5.1 Touch Screen Driver under “hardware update wizard” dialogue box, as... -
Page 9: Touch Screen Driver Under Other Windows Systems
User’s Manual of LAN G15 Programmable Touch Screen 6.click on “finish” to finish the installation of touch screen driver, then Creator_g7 will be displayed in device manager, as seen in picture 1-7 Picture 1-4 Picture 1-7 7. Open PC editing software Think Draw, customize your unique user interface and update it to touch screen for experience. -
Page 10: Chapter 2 Touch Screen
User’s Manual of LAN G15 Programmable Touch Screen Chapter 2 Touch Screen 1. Select Calibration key to have system 2.1 Panel Instruction calibration, as seen in the picture. And calibrate it Rear Panel： as per the instructions. Picture 2-2 ① RJ45：Network port，for connecting to PC or 2. -
Page 11: Main Page
User’s Manual of LAN G15 Programmable Touch Screen 2.2.2 Main Page Picture 2-4 This keyboard comprises of input bar, characters zone and functional bar. Select your needed value in characters bar, you will see relevant digit displayed, with limitation of up to 20 characters. -
Page 12: Lan
User’s Manual of LAN G15 Programmable Touch Screen 1、 As seen in picture 2-7, the page is for 2、 When you need to alter the network adjusting date and time, with date ranging from parameter at right side, click on corresponding the year 2009 to 2049. -
Page 13: Language
User’s Manual of LAN G15 Programmable Touch Screen 2.2.6 Language 2. Click on Turn To Standby digit region to see an pulley for adjusting standby time (0 to 10 minutes). System initial value is 8 minutes, i.e. accessing to digital album after 8 minutes. -
Page 14: About Us
User’s Manual of LAN G15 Programmable Touch Screen 2.2.9 About US 1. Correctly connect to power and USB data cable, run the system, software system icon is on, as seen in picture 2-15 Picture 2-13 As seen in picture 2-13, this page displays the history of our company and contacts (subject to you need), without making any configuration. - Page 15 User’s Manual of LAN G15 Programmable Touch Screen Picture 2-16 ThinkDraw Editing Software Picture 2-18 Interface 3.PC editing software ThinkDraw will display the 1. Correctly connect to power and USB cable, process of data transmission, as seen in pictures run the system to see “Transfer--》Send File 2-19 and 2-20.
-
Page 16: System Connection Diagram
User’s Manual of LAN G15 Programmable Touch Screen refers to the size of update data. Status refers to current states. And the bar indicates the percentage of current running process. 4. When finishing update, the program will automatically jump to control interface. -
Page 17: Chapter 3 Technical Parameters
User’s Manual of LAN G15 Programmable Touch Screen Chapter 3 Technical Parameters Parameters CR-LAN G15 Display mode TFT LCD true color Screen resolution 800X600 Control mode Wired Application range For connecting to CR-PGMIII control system Touch screen backlight Communication port... -
Page 18: Chapter 4 Common Troubles Shooting
User’s Manual of LAN G15 Programmable Touch Screen Chapter 4 Common Troubles Shooting Failure Resolution Host cannot be controlled by touch screen ● Check to see if the Join No. value of touch screen project button is the same as that in host program;... -
Page 19: Chapter 5 Maintenance
User’s Manual of LAN G15 Programmable Touch Screen Chapter 5 Maintenance 1、 Use soft dry cloth to wipe out the dust on touch screen； 2、 Avoid placing the touch screen under sunshine, but it should be placed at dry area. - Page 20 CREATOR CORPORATION（CHINA） Copyright by CREATOR Last Revision：09/2011...
