MAINTENANCE
CLEANING THE LENS
If your CDs jump tracks, skip passages or don't play properly, this is likely to be
caused by surface damage or dirt on the CD rather than any fault of the unit.
In extreme cases, however, these phenomena could be due to dirt or dust on the
lens. If the CD lens gets dusty or dirty, use a proprietary lens cleaner and follow
the instructions carefully. Alternatively,
clean it with camera lens blower.
Be careful never to scratch the surface of the lens.
If you keep the CD cover closed at all times when the unit is not in use, the lens is
unlikely to get dirty.
Be careful not to scratch the surface of the lens.
CLEANING THE CABINET
From time to time, clean the cabinet with a soft dry cloth. For more stubborn
stains, slightly moisten the cloth with water or a mild detergent solution.
Never use benzene, alcohol or other solvents as they may damage the
finish of the cabinet.
Do NOT clean the inside of the CD player with a cloth. Lightly blow out any dust.
Tesco Stores Ltd,
Delamare Road, Cheshunt, Herts, EN8 9SL
WARRANTY
Your appliance is covered by a warranty for 12 months from the date of
purchase. If a fault develops during this period, please contact your nearest
Tesco store. Please have your original purchase receipt with you when you
call. This warranty in no way affects your consumer rights.
SPECIFICATIONS
Output Power :
3mW per channel.
Matching Impedance:
32 Ohms (Headphones)
Freq. Response :
20Hz ~ 20000 Hz
Power:
DC 4.5V external and "AA"( UM-3, HP-7, R6) batteries 1.5V x 2,
Dimensions :
130 mm(W) x 142 mm(D) x 29 mm(H)
Produced after 13th August 2005.
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check
with your Local Authority or retailer for recycling advice.
User Guide
PCD-307
Personal CD/MP3 Player
Advertisement
Table of Contents
Related Manuals for Technika PCD-307
Summary of Contents for Technika PCD-307
- Page 1 Local Authority or retailer for recycling advice. Do NOT clean the inside of the CD player with a cloth. Lightly blow out any dust. PCD-307 Tesco Stores Ltd, Personal CD/MP3 Player Delamare Road, Cheshunt, Herts, EN8 9SL...
-
Page 2: Troubleshooting Guide
IMPORTANT SAFETY INFORMATION WARNING: DANGER OF RADIATION PLEASE READ CAREFULLY These labels tell you that the unit contains a laser component. Opening the TROUBLESHOOTING GUIDE lid and defeating the safety interlocks will expose the user to radiation from Read these instructions. If you experience difficulties in the use of this player please refer to the the laser beam. -
Page 3: Program Play
PROGRAM PLAY At each stage you can edit the program or add extra tracks to the program. CONTROLS AND DISPLAYS NO DISC You can program the player to play up to 64 tracks. TO PLAY THE PROGRAM: Press PLAY/PAUSE Program play will CD MODE MP3 MODE CD DOOR OPEN... -
Page 4: Connecting Batteries
CONNECTING BATTERIES MP3 Disc playback ELECTRONIC SHOCK PROTECTION The battery compartment is located inside the CD Compartment. Most MP3 discs are organised in folders. The disc is called the 'root' folder: ESP is enabled during MP3 playback and cannot be switched off. (See Page 6) Open the CD Door. -
Page 5: External Connections
EXTERNAL CONNECTIONS A: LINE OUT CONNECTIONS PROGRAM PLAY TO PLAY THE PROGRAM: Press PLAY/PAUSE Program play will commence from track 8 You can programme the player to play up to 64 tracks. You will need to purchase a cable with a Stereo 3.5 jack In Program Play a MODE functions are fully operational. -
Page 6: Basic Player Operation
Open the CD Door: PRELIMINARIES PLAYING A CD TO GO BACK TO THE START OF A TRACK DURING PLAY Load a disc into the Disc compartment with the label side up. Gently Press SKIP/SEARCH once. Unpack the player carefully. The packing consists of the player and a pair of Load a CD into the Disc compartment with the label side up.
