This cable can be ordered as Part Number C1062-005-XX where XX is the cable length. Connector
kits containing the RJ-45 and ENC8F connectors are also available (Part Number SCK1062-005).
NOTES: 1. Use proper crimp tool for Item #2 connection
2. Remove cable filler gel from conductors before inserting into Item #2.
3. Insure that all eight conductors reach to end of interior channel before crimping Item #2
ITEM #2
RADIO_ETH_TX+ 1
RADIO_ETH_TX- 2
RADIO_ETH_RX+ 3
VDC 4
VDC 5
RADIO_ETH_RX- 6
GND 7
GND 8
RJ 45 Plug
W/OR 1 8
NO TAB
ITEM
PART NO.
1 5EXH04P24-BK-R-CMS-PV
AT8X8SC-2224
2
3 EN3C8F (fig. A)
CAT5 Power/Ethernet Cable
ITEM #1
WHT/ORN
ORN
WHT/GRN
WHT/BRN
WHT/BLUE
GRN
BLUE
BRN
BR
MATERIAL
MANUFACTURER
CommScope
Allen Tel
Switchcraft
- 92 -
VIP 110-24 Operator's Manual (rev E)
ITEM #3
2
1
4
6
5
3
7
8
Solder Cups
W/BL
5
6
W/BR
7
BL
REAR VIEW
DESCRIPTION
Cable, CAT5, Outdoor, Solid Cond.
Plug Connector, 8 Cond., RJ45-type
8 Pin Field Connector, Female
W/GR
4
GRN
3
W/OR
2
1
OR
8
BR
