Summary of Contents for DOD IS420W

  • Page 1 IS420W User Manual...

  • Page 2: Table Of Contents

    Installing Your Camera ....................14 External GPS Module ....................... 16 Basic Camera Operation ....................19 Camera Modes ......................... 20 Camera Settings ......................24 Transferring Files ......................30 Video Output ........................30 Firmware Update ......................31 DOD Video Player ......................31 Specification ........................32...

  • Page 3: Product Features

    WDR technology, well-balanced exposure for any condition. It makes night shots brighter; prevent overexposure and to create the clearest image. DOD GPS Player The DOD GPS Player generates 1080p video recordings with real-time driving data clearly at a glance. 140º Wide View Angle Wide angle, wide view, without distortion.

  • Page 4: Loop Recording

    Large Aperture Glass Lens - Super Low Light Performance IS420W possesses the f/1.8 large aperture, capturing the better night shots than f/2.0, and records clearly sophisticated details such as the license plate and others. 6G Sharp Glass Lens 6-Element sharp lens, made up of 6 layers of glass, provides stunning clear and non-deformed images.

  • Page 5: Safety Precautions

    Do not operate or handle power cable with wet hands. In specified cars, the power may be constantly supplied to the device even the engine is turned off. This may run out the vehicle battery. The optional DOD DP4 kit equipped with low-voltage protection design to prevent battery drain.
  • Page 6 ,which will not be covered by warranty. DOD is NOT responsible for the loss of any recorded video during operation due to unexpected factors or force majeure when driving.

  • Page 7: Package Contents

    Package Contents Dash Cam User Guide External GPS Module DOD Player Installation CD Car Power Adaptor Bracket Note: Supplied accessories may vary by region.

  • Page 8: Optional Accessories

    Optional Accessories DA2S DP4 hardwiring kit offers constant DA2S Suction Savior provides a long source and prevent battery drain with lasting adhesion to suction cups. low-voltage protection.

  • Page 9: Camera Controls

    Camera Controls Record/Shutter/OK【 】 ● Video Mode: Start/Stop recording Camera Mode: Take a photo Video Playback Mode: Play / pause Video Settings Mode: Select highlighted item. Power Button ON/OFF【 】 ● Turn on/off the unit. AV Out: A/V Video Output Port ●...
  • Page 10 Camera Controls Speaker ● Reset Button ● Reset to factory settings. Press to force the device to reboot. Use a small pin to press the button.
  • Page 11 Camera Controls MicroSD Slot ● Required a microSDHC/SDXC card, class 6 or above. Support 8~32GB. Arrow Keys【/】 ● Used to navigate through menus and select videos for playback. Menu/SOS Emergency File Lock【 】 ● While recording, this button locks the current file from being over written. When recording has stopped, this button will access the settings menu.
  • Page 12 Camera Controls Mode/Mute【 / 】 ● Reset to factory settings. While recording, press and hold this button to turn on/off the microphone. Change camera modes when not recording videos. Operation Status LED ● Steady blue - Unit is powered off and is charging. Steady pink - Unit is Standby Mode, Camera Mode or Playback Mode.

  • Page 13: Getting Started

    Set up your camera inside your vehicle to ensure easy access to power. 1. Insert the MicroSD Card. Format the MicroSD card before initial use. To save recorded videos stably, DOD Tech recommends formatting your SD card every two weeks. Note: Requires the MicroSD card up to 32GB Note: After formatting the SD card, all of your data will be lost.
  • Page 14 Note: In specified cars, the power may be constantly supplied to the device even the engine is turned off. This may run out the vehicle battery. The optional DOD DP4 kit equipped with low-voltage protection design to prevent battery drainage.

  • Page 15: Installing Your Camera

    Installing Your Camera...
  • Page 16 Do not turn on Motion Detection unless your vehicle is parked. If Motion Detection is enabled while driving, the camera may not continuously record. DOD Tech recommends setting the G-Sensor to low.

  • Page 17: External Gps Module

    External GPS Module Note: Please point the adhesive side upwards. DOD Tech suggests to place GPS module on windshield for best signal reception.
  • Page 18 2. Adjust the Angle The mount has an adjustable ball joint which allows angle adjustment to aim at desired angle. DOD Tech suggests to aim your camera slightly below the horizon line for maximum front view. 3. Install the Cigarette Adapter If you have not done so previously, plug the cigarette adapter into your vehicle's power port.
  • Page 19 Do not turn on Motion Detection unless your vehicle is parked. If Motion Detection is enabled while driving, the camera may not continuously record. DOD Tech recommends setting the G-Sensor to low.

  • Page 20: Basic Camera Operation

    Basic Camera Operation Everyday Operation Your dash camera will automatically turn on and start recording when it starts receiving power. By default, the camera will record over the oldest videos when the memory card is full (loop recording). Continuously Powered Electrical Outlet If your camera is continuously powered, the camera will not automatically shut down when your vehicle is turned off.

  • Page 21: Camera Modes

    Camera Modes When the camera is not recording video, you can switch between three modes by pressing the【 】: 1. Video Recording 2. Photo 3. Video Playback 1. Video Recording Mode The camera defaults to video recording when the camera is first turned on. Recording Mode: Press【●】to start/stop recording.
  • Page 22 Indicates the WDR function is on. ● Recording Status Flashes red when recording video. Video Recording Mode Indicates the device is in video mode. Resolution Indicates the current recording resolution. Indicates the current video recording length Loop Recording per file. Exposure Value Indicates the current exposure value setting.

  • Page 23: Photo Mode

    Camera Modes 2.Photo Mode Press【 】once to enter the Photo Mode during the Standby Mode. Press【 】to take a photo. Note: Photo Mode is only accessible during the Standby Mode. Self-Timer (2s) Shake Reduction (On) Image Resolution Exposure Value (Auto) Camera Mode ISO Sensitivity (Auto) WDR Enabled...

  • Page 24: Playback Mode

    Camera Modes 3.Playback Mode You can watch previously recorded videos in Playback Mode. Press【 】twice to enter the Playback Mode during the Standby Mode. Play the Video Press【 】to play and pause.  Press【/】to move or back forwards and press【 】 ...

  • Page 25: Camera Settings

    Camera Settings Each mode has a unique set of settings. See the description below. Two Camera Settings pages are accessible: Functional Settings System Settings The menu settings can be switched by pressing【 】. If you move the cursor before pressing【 】, you must exit and try again.
  • Page 26 Note: Parking Surveillance requires consistent power supply via vehicle battery. (It is recommended to use optional DOD DP4 kit equipped with low-voltage protection design to prevent battery drainage. Please ensure to enable G-sensor function in setting menu before switch to Parking Surveillance.
  • Page 27 Camera Settings Plate Stamp Imprints a customized set of 8 digits to the recorded video. Add license plates or other identifying features to watermark your video. GPS Logging On/Off.  Default: On.  Set Time Zone Sets the current time zone for GPS time and date calibration. Not the time zone must be manually adjusted for daylight savings Speed Units Select metric or imperial units.
  • Page 28 Camera Settings Functional Settings (video recording mode) Accessed by pressing【 】once. Time-Lapse The time-lapse function is used to create a sped-up video. When set, the camera will record one frame every 200ms (milliseconds)/500ms/1 second/5 seconds. Head Up Display After a customized period of time a new screen will appear showing speed and direction. If enabled, the GPS speed warning will appear on this screen.
  • Page 29 Camera Settings Functional Settings (photo mode) Accessed in “Photo Mode”. WDR (Wide Dynamic Range) Cannot be changed. Shows WDR processing is enabled. Color Apply a color filter to the photo. Capture Mode Sets a timed delay before taking a photo. Change the ISO settings.

  • Page 30: System Settings

    Camera Settings System Settings Accessed by pressing【 】twice. Format Completely deletes all files including locked footage on the memory card and optimizes the card for recording. Date/Time Sets year/date/time format. Beep Sound Turns on/off notification sounds. TV Mode Switches between the NTSC and PAL video output standard. Default Settings Sets all settings back to the original settings.

  • Page 31: Transferring Files

    Transferring Files Video files can be transferred to your electronic device for viewing and storage. USB Cable 1. Connect a USB cable from the camera’s USB port to computer. 2. Turn on your camera. A black screen should appear showing “Mass Storage”. 3.

  • Page 32: Firmware Update

    Firmware Update See the support section on DOD Tech’s website for any available firmware updates and instructions. DOD Video Player...

  • Page 33: Specification

    Specification 1920x1080@30fps Video Resolution 1280X720@60fps 1280X720@30fps Sensor SONY Exmor CMOS sensor Wide-Angle Lens 140° Aperture f/1.8 ISO Sensitivity up to ISO 3200 Display 2.7" 16:9 TFT LCD Video Format H.264 MOV Recording Media micro SDHC/SDXC Card (Up to 32GB) Audio Mic and Speaker(Mono)Equipped Battery 3.7V 140mAh Lithium-ion Battery...
  • Page 34 Copyright ©2016 DOD Tech All Rights Reserved Under the copyright laws, this manual may not be copied, in any way, shape, or form, without the written consent of DOD Tech.
