Aria -130 Installation Manual

Hide thumbs Also See for Aria-130:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Programming Manual
Aria-130
Digital Key Telephone System
Installation
Manual
Aria Communications
Quadrant Business Park
Unit 3 / 15 Pickering Road
Mulgrave
VIC 3170
ABN : 22 090 723 925

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aria-130 and is the answer not in the manual?

Questions and answers

Related Manuals for Aria Aria-130

Summary of Contents for Aria Aria-130

  • Page 1 Aria-130 Digital Key Telephone System Installation Manual Aria Communications Quadrant Business Park Unit 3 / 15 Pickering Road Mulgrave VIC 3170 ABN : 22 090 723 925...
  • Page 2 Aria Communications Pty. Limited. Every effort has been made to ensure that this manual documents the operation of the Aria-130 Digital Key Telephone System. However, due to the on-going improvement and update of software, Aria Communications cannot guarantee the...
  • Page 3 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual REVISION HISTORY ISSUE DATE Contents of Changes REMARK Field Trial Nov. 2002 Initial Document 10/March/03 Release Version 30/Sep/03 Change System Aria-130 BRI Capacity 11/11/03 Add STIB (network side) to capacity chart...
  • Page 4 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Blank sheet...

  • Page 5: Table Of Contents

    Notice Of Replacement With Lithium Battery ................11 SECTION 2. GENERAL DESCRIPTION..........12 INTRODUCTION ....................12 SYSTEM CAPACITY ..................13 2.2.1 System Capacity .......................... 13 2.2.2 Aria-130 Maximum Port Capacities ..................... 14 2.2.3 System Configuration Chart ......................15 2.2.3.1 Overview ........................15 SYSTEM SPECIFICATIONS ................16 2.3.1 Dimension And Weight ........................
  • Page 6 ISDN Boards ..........................32 2.4.10.1 GDK-100 ISDN PRIB (Primary Rate Interface Board) ..........32 2.4.10.2 ARIA-130 ISDN PRIB(Primary Rate Interface Board) ........... 33 2.4.10.3 GDK-100 ISDN BRIB (Basic Rate Interface Board: T interface only) ......33 2.4.10.4 ARIA-130 ISDN BRIB ....................33 2.4.10.5...
  • Page 7 VOIU Installation ......................78 3.4.6 ISDN Board Installation ........................ 78 3.4.6.1 ARIA-130 ISDN BRIB (Basic Rate T Interface) Installation .......... 79 3.4.6.2 ARIA-130 ISDN BRIU (Basic Rate T Interface) Installation .......... 80 3.4.6.3 ARIA-130 ISDN PRIB (Primary Rate T Interface) Installation ........81 3.4.6.4...
  • Page 8 Station/CO Line Number Assignments ............132 Other Information ..................132 SECTION 5. DECT Installation ............133 Components of the ARIA-130 WOTS ............133 How to Make Calls in the ARIA-130 WOTS ..........136 ARIA-130 WOTS .................... 137 System Configuration .................. 142 5.4.1 Before Installation ........................
  • Page 9 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual...

  • Page 10: Section 1. Introduction

    The local Carrier may make changes in its communications facilities or procedures. If these changes could reasonably be expected to affect the use of the Aria-130 system or compatibility with the network, the carrier is required to give advanced written notice to the user, allowing the user to take appropriate steps to maintain telephone service.

  • Page 11: Hearing Aid Compatibility

    1.2.6 Hearing Aid Compatibility The Aria-130 Digital Key Telephone has been designed to comply with the Hearing Aid Compatibility requirements as defined in ACA Technical Standards ACA TS004-1997.

  • Page 12: Section 2. General Description

    1’st and the 2’nd cabinet to house plug-in Printed Circuit Boards, and 2) providing support for different types of instrumentation. The KSU of ARIA-130 is a wall-mounted cabinet that houses the MB(Mother Board) and card slots for the CO line/Key Station/SLT/ISDN/LAN interface boards, and other useful boards. There are two-story KSU in the system.

  • Page 13: System Capacity

    * Note A ; Time slots are used to allocated flexibly to support each function PSTN, ISDN, VMIB, WTIB, MOH, Paging, Modem, DTMF detection, etc. Maximum ports of ARIA-130 are 132. * Note B ; Option : 2chs/DTRU, 4chs/DTRUII, 4chs/DTRU4, 2chs/MPB ·...

  • Page 14: Aria-130 Maximum Port Capacities

    2.2.2 Aria-130 Maximum Port Capacities When considering total port of the capacities of the system, it is necessary to consider the type of PMU that will be installed. The Aria-130 has four types of PMU: - • PMU 1 & 2 •...

  • Page 15: System Configuration Chart

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.2.3 System Configuration Chart 2.2.3.1 Overview The maximum capacity of the system configured only with the wired extensions will be limited by the physical condition of the system, e.g. the quantity of slots and cards limitation. System configuration charts are as follows;...

  • Page 16: System Specifications

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.3 SYSTEM SPECIFICATIONS The following Tables provide general system specifications. 2.3.1 Dimension And Weight Item Height(mm/in) Width(mm/in) Depth(mm/in) Weight(kg/lbs) 230.5 13.2 Digital Keyset 236/9.3 192/7.6 84/3.3 1.5/3.3 Digital DSS/DLS Console 236/9.3 125/4.9...

  • Page 17: Base Station Specification (Gdc-330B)

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.3.3.2 Base Station Specification (GDC-330B) Item Specification +30V DC Power feeding Transmission Max Power 250mW Access Method/Duplex TDMA/TDD Frequency Band 1,880 ~ 1,900MHz Channel Spacing 1.728MHz Modulation GFSK Data rate 1.152Mbps Max.

  • Page 18: Specification For Voib/Voiu

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.3.3.6 Specification for VOIB/VOIU Item Specification LAN Interface 10 / 100 Base-T Ethernet(IEEE 802.3) Speed 10 Mbps or 100 Mbps(Auto-Negotiation) Duplex Half Dulpex or Full Duplex(Auto-Negotiation) VoIP Protocol H.323 Revision 2 Voice Compression G.711 / G.729A / G.729B / G.723.1 / G.726 / G.727...

  • Page 19: System Components

    Installation Manual 2.4 SYSTEM COMPONENTS The following table shows the available slots in which every card can be installed. Some boards for GDK- 100/ARIA-300 can be used in ARIA-130 system. Others are used in only ARIA-130 system. Board Number Slot Position...
  • Page 20 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Board Number Slot Description Position Name of Ports 1’st VOIB Voice Over Internet Protocol Interface Board VOIU VOIB Voice Over internet protocol Interface Unit PLLU Phase Lock Loop Unit for ISDN cards...
  • Page 21 Issue: 1.2 Installation Manual The following Fig 2.4.1 System configuration diagram shows the ARIA-130 system configuration for all kinds of board in this system that includes the existing boards for the GDK-100/ARIA-300 system and the developed new boards. CO/Extension Board -.

  • Page 22: Ksu (Key Service Unit)

    6 universal slots, MPB slot, PSU, PFTU, RGU, CN11(clock chain) and connector for Link cable. ARIA-130 system is 2-story KSU consisted of the 1’st and 2’nd KSU. It’s possible to install all kinds of boards according the Table 2.4.1. Cable ties are located on the front edge of the lower card rail to allow connecting cables for the station boards, CO interface boards, and MISB to be neatly installed.

  • Page 23: Psu (Power Supply Unit)

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual MB contains various kinds of connectors as in the Fig 2.4.3 Board Configuration of MB. There are six universal slots in the MB(SLOT 1~6). Any kind of peripheral card can be installed in the universal slot.

  • Page 24: Mpb (Main Processor Board)

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.4.5 MPB (Main Processor Board) SMEMU CN17 PLLU DMEMU S3C4530A SIU / MODU CN16 DBID II LANU ARIA-130 MPB Serial Port PJ 1 PJ 2 RLY1 ALARM RLY2 JTAG Battery connector Switch Figure 2.4.5 MPB Configuration...
  • Page 25 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual A RJ21 type female connector is mounted on the front edge of the MISB for the connection to above circuits. MISB can be installed only in the slot No.6 of the 1st KSU.

  • Page 26: Vmib (Voice Mail Interface Board)

    1200 min. ACD/UCD Announcement User Greeting Table 2.4.2 Capacity of Memory, ADPCM channel of VMIB • VMIB allows a FMEU or a VCEU to be expanded. • ARIA-130 allows 2 VMIB boards to be installed. RESET VCEU (D6301A) (D6301A) ROM1 ROM1...

  • Page 27: Extension Boards

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.4.8 Extension Boards The various types of ARIA-130/ARIA-300/GDK-100 Extension Boards have capable of supporting various types of terminals as followings, Board Name Function Remark DTIB12 Provides 12 Digital Terminal interfaces 2 wire...

  • Page 28: Slib24/Slib48 (Single Line Interface Board With 6 Ports)

    Issue: 1.2 Installation Manual 2.4.8.2 SLIB24/SLIB48 (Single Line Interface Board With 6 Ports) SLIB allows single line analog devices to be connected. Five kinds of SLIB boards are available in ARIA-130 system; Board Name Interface circuit Feed voltage Remark SLIB24...

  • Page 29: Slib2E (Single Line Interface Board With 12 Ports)

    PCB to indicate the status of ports connected to SLIB II. It will turn on when one or more ports are busy. SLIB II can be installed in the universal slot No. 1-6 in any KSU. The maximum extension ports are limited by 96 extensions in ARIA-130 system. Add-on boards: DTRU II, MSGU II 2.4.8.4...

  • Page 30: Dsib (Dktu/Slt Interface Board With 12 Ports)

    2.4.8.6 WTIB / WTIU (Wireless Terminal Interface Board / Unit) The WTIB provides standard interface between the ARIA-130 digital Key Telephone system and DECT (Digital Enhanced Cordless Telecommunications) Network. The system can accommodate two WTIBs in the same KSU, which are capable of supporting up to 16 Base Stations. The WTIB can be optionally equipped with WTIU to expand Base Stations, which can support up to additional 4 base stations.

  • Page 31: Analog Trunk Boards

    In case of using two WTIBs, the boards should be installed in the same KSU. S/W Version of WTIB Board is 1.0H 2.4.9 Analog Trunk Boards Five kinds of analog trunk boards are available in ARIA-130 system; Board Name Interface circuit...

  • Page 32: Emib (E&M Tie Line Interface Board)

    Note: - that the Australian version of the EMIB supports 4 wire E & M only, it does not support 2 wire working. 2.4.10 ISDN Boards ARIA-130 ISDN Boards are capable of supporting various types of ISDN as followings, Board Function...

  • Page 33: Aria-130 Isdn Prib(Primary Rate Interface Board)

    2.4.10.2 ARIA-130 ISDN PRIB(Primary Rate Interface Board) ARIA-130 PRIB (Primary Rate Interface Board) is capable of connecting to 1 PRI line, which has an interface circuit for 30 time slots with 2.048Mbps data rate speed. PRIB will be positioned at reference point la on ETS 300 001, that is TE slave without power feeding.

  • Page 34: Isdn Stib (Basic Rate Interface Board: Switch-Able S/T Interface)

    192Kbps(2B+D). Data & bit clock are transmitted by the NT master and extracted by TE slave. ARIA-130 can be positioned at reference point Ia (T) or Ib (S) on ETS 300 012 that is TE-slave without power feeding or NT-master with power feeding. By selecting the jumper position on each line interface, STIB supports S-interface (Line card function) or T-interface (Trunk function).

  • Page 35: Add-On Boards

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual To insure Quality of Service (QoS), it is also recommended to use this board under Intranet which guarantees the quality of network. VOIB can be installed in the universal slot No. 1-6 in any KSU.

  • Page 36: Pmu2 (Programming Memory Module)

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.4.12.2 PMU2 (Programming Memory Module) PMU2 is installed on MPB , has a program for system control, administration, and call processing. PMU2 has 4M byte Flash ROM which download software through RS-232C, ISDN line, LAN port, or Modem port on MPB.

  • Page 37: Asmu1 (Advanced Software Module Unit1)

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.4.12.3 ASMU1 (Advanced Software Module Unit1) ASMU1 is one of the program package, the functions are as follows ; -PC Attendant -CTI -Networking ASMU1 package contains a CD-ROM, a PMU (labeled as ASMU1), a serial cable, SMEMU.

  • Page 38: Siu (Serial Interface Unit)

    The DTRU II can be optionally installed on SLIB II. The DTRU4 can be optionally installed on LCOB8, SLIB2E and SLIBII. Maximum DTMF receivers are 46 in ARIA-130 system. 2.4.12.9 MSGU/MSGU48/MSGU II (Message Wait Unit) The Message Wait Unit sends 90V DC signal to the SLT illuminating the Message Wait lamp. The MSGU and MSGU48 contain 6 circuits to support 6 SLTs.

  • Page 39: Cmu (Call Metering Unit)

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.4.12.11 CMU (Call Metering Unit) The Call Metering Unit detects call metering signals from the CO or PABX to monitor call duration/charges. There are six kinds of CMUs as followings, 12KHz...

  • Page 40: Digital Keysets And Terminals

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.4.13.1 Digital Keysets And Terminals Various types of digital terminals are used with ARIA-300 DTIB12/DTIB24/DSIB as below: Model Description Model Description KD-36EXE 24 Flexible Button Display KD/E-36EXE 24 Flexible Button Display...

  • Page 41: Mohu (Music On Hold Unit)

    The MOHU provides External Music Source to the system through any kind of Single Line Interface including 2B-SLIU30 in ARIA-130 System. The external music source provided through single line interface is used as music source of the system, that is, the music source through MOHU offers the same function that the other external music source of the system do.

  • Page 42: Module

    LKD-30DS. These 2B-modules can be installed only in LKD-30DS. See Figure 2.4.19 2B modules. In ARIA-300 system, LDK-30DS with 2B-module can be connected to every even-numbered port (0,2,4,…) of DTIB12/DTIB24/DSIB. In that case, any digital terminal can not be connected to the consecutive port (1,3,5,…).

  • Page 43: Gdk-Pc Phone (Cti)

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 2.4.13.4 GDK-PC Phone (CTI) GDK-PC PHONE is based on Microsoft TAPI (Telephony Application Programming Interface) Standard Specification and Windows 3.1 or Windows 95/98 environment. With Computer Telephony, a customer can use computer to take an advantage of a wide range of sophisticated communication features and services over a telephone line.

  • Page 44: Section 3. Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual SECTION 3. INSTALLATION 3.1 INTRODUCTION As with any sophisticated communications device, installation of the ARIA-130 System requires the care and forethought of a competent technician. Installation proceeds in 5 major steps; − Site Preparation −...

  • Page 45: Backboard Installation

    If any equipment is damaged or missing, notify appropriate personnel to correct the situation. 3.3 KSU Installation ARIA-130 system consists of two KSUs, 1st and 2nd KSU. The 2nd is used for expansion KSU. Caution: Installing 1st and 2nd KSU together on the brick wall can cause the connection between Basic and Expansion KSU to be unstable.

  • Page 46: Mounting 1St And 2Nd Ksu

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.3.1 Mounting 1st and 2nd KSU The 1st KSU is metal frame cabinet designed for wall mounting. The KSU must not be mounted on a masonry or dry-wall surface, in this case a wooden backboard is required, reference paragraph backboard Installation.
  • Page 47 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.1 KSU Exterior...
  • Page 48 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.2 1st KSU Mounting Holes & Installation Layout...
  • Page 49 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.3 1st, and 2nd KSU Mounting Holes & Installation Layout 1...
  • Page 50 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.4 1st and 2nd KSU Mounting Holes & Installation Layout 2...
  • Page 51 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.5 Connection between 1st KSU and 2nd KSU...
  • Page 52 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.6 Connection between 1st KSU and 2nd KSU...

  • Page 53: Rgu Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.3.2 RGU Installation The Ring Generator Unit(RGU6) is needed in the 1st and 2nd KSU if SLIB24, SLIB48, SLIBII, SLIB2E and DSIB are to be installed, to provide Ring voltage and Message Wait Source.
  • Page 54 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual An earth terminal is provided, and the grounding method of the PFTU is shown in Fig 3.3.9 when the PFTU is installed outside KSU. And there is a test switch on the surface of PFTU; TEST position of the switch is used for testing PFTU function, and NORMAL position of the switch for normal operation.

  • Page 55: Ksu Grounding

    Issue: 1.2 Installation Manual 3.3.4 KSU Grounding Before connection to the mains supply, the Aria-130 system must have a hard-wired protective earth installed by a qualified person. The protective earth is required for user safety and also to minimise EMC interference.

  • Page 56: Ac Input Selection At Psu

    220/230 volts, move the switch to the “220/230V” position, CN5 . Default setup of the PSU : 220/230VAC(CN5). The range of main input voltage and the fuse ratings of ARIA-130 PSU according to the position of VOLTAGE SELECTOR switch are as follows;...
  • Page 57 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.10.a Power Supply Unit...
  • Page 58 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.3.10.b PSU Shield Cover To Frame Ground ○ ○ LED1 Power Inlet ○ 110V ○ ○ 220/230V ○ Input Voltage Selection Figure 3.3.10.c AC Input Selection...

  • Page 59: Pcb Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.4 PCB INSTALLATION 3.4.1 PCB Handling And General Installation No board should not be installed or removed with power applied. Power must be turned off prior to insertion or removal of the PCB.

  • Page 60: Mpb Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.4.2 MPB Installation The MPB is installed only in the MPB slot of the 1st KSU. The MPB may be equipped with 6 add-on boards; PMU for software program, a MODU for modem access to the system, and a SDRAM for software downloading and additional features.
  • Page 61 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of SW3 The MPB also has an eight-position DIP switch, SW3. The function of each switch position is as followings; Default setting: All ON position Switch Function Administration Programming Access...

  • Page 62: Pmu Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual * Note: − MPB should be installed only in the MPB slot of the 1st KSU. − The Dipswitch, SW1 should be turned ON before the MPB installation to protect system data in the case of a power fail.

  • Page 63: Pllu Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.4.2.4 PLLU Installation PLLU board has the function to synchronize the system clock to network, when using ISDN board and digital trunk(E1, R2DCOB). PLLU should be installed on MPB through the dual line connectors, CN16 and CN17 of MPB.

  • Page 64: Misb Installation

    One MISB can be installed only in the slot No. 6 of the 1st KSU. − In ARIA-130, SIU can not be installed on MISB . 3.4.4 Extension Board Installation The system can be equipped with any combination of the extension boards; DTIB12, DTIB24, SLIB24, SLIB48, SLIBII, SLIB2E, DSIB, and WTIB.

  • Page 65: Slib24/Slib48 Installation

    The distance between Digital Terminal Interface Board and Digital Terminal: see Table 2.3.5 In ARIA-130 system, LKD-30DS with 2B-module and secondary terminal can be connected to only every even-numbered port (0,2,4,…) of DTIB12/DTIB24/DSIB, then any digital terminal can not be connected to the consecutive odd port(1,3,5,…) in that case.

  • Page 66: Slibii Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of various connectors Connector Function Remark CONN1 and CONN2 DTRU connection CONN3 and CONN4 MSGU and MSGU48 connection CHAMP1 RJ21 type connector (female) for terminal connection Table 3.4.8 connector on SLIB24/48...
  • Page 67 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of various connectors Connector Function Remark CN2 and CN4 DTRUII connection CN3 and CN5 MSGUII connection RJ21 type connector (female) for terminal connection Table 3.4.10 connector on SLIBII Note: If you want Message Waiting function on SLIBII, MSGUII should be installed on SLIBII.

  • Page 68: Slib2E Installation

    Country mode : H/W gain and transmission characteristics depend on Each country Spec. CTR21 mode : H/W gain and transmission characteristics depend on CTR21 Specification. ARIA-130 does not support the function of normal/service selection. SW2 is used for selection of short loop or long loop in special country.
  • Page 69 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of various connectors Connector Function Remark CN1 and CN2 DTRU4 connection CN6, CN7 and CN5, CN8 MSGU48 connection RJ21 type connector (female) for terminal connection Table 3.4.13 connector on SLIB2E Note: If you want Message Waiting function on SLIB2E, MSGU48 should be installed on SLIB2E.

  • Page 70: Dsib Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.4.4.5 DSIB Installation DSIB can be installed in any universal slot and allows 6 Digital terminals and 6 single line analogue devices to be connected. A MSGU with 6 circuits can be optionally installed on DSIB to light a message waiting lamp in the SLT connected to DSIB, and a DTRU with 2 DTMF receivers can be optionally installed on DSIB to receive DTMF signals using a system resource.

  • Page 71: Dtru/Dtru Ii/Dtru 4 Installation

    There are several types of analog CO line boards available. Every CO line board contains several types of connectors for the line connection on the front edge of the boards themselves. Maximum 40 CO lines can be installed in ARIA-130 system. 3.4.5.1 LCOB Installation LCOB provides 4 Loop Start CO line interfaces.
  • Page 72 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of LED Function Remark LED1 The status of line 1, ON: in use, Green LED2 The status of line 2, ON: in use, Green LED3 The status of line 3, ON: in use, Green...

  • Page 73: Lcob8 Installation

    CTR21 mode : H/W gain and transmission characteristics depend on CTR21 Specification. ARIA-130 does not support the function of normal/service selection. SW2 is used for selection of short loop or long loop in special country. [ special country (impedance = 600ohm ) : Standard, India, Israel, China ]...
  • Page 74 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of LED Function Remark LED1 The status of line 1, ON: in use, Green LED2 The status of line 2, ON: in use, Green LED3 The status of line 3, ON: in use, Green...

  • Page 75: Emib Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.4.5.3 EMIB Installation The EMIB provides 4 analog E&M interfaces. It can only support 4 wire E&M signalling, (not 2 wire). It is designed to comply with the Australian specification. Function of LED...
  • Page 76 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Figure 3.4.12 Board Layout and DTRU installation...

  • Page 77: Voib Installation

    Installation Manual 3.4.5.4 VOIB Installation The VOIB/VOIU can be installed in ARIA-130. Its main job is to provide the Ethernet interface for S/W applications and VoIP features with optional VoIP daughters. The VOIB has the capacity for maximum four(4) VOIUs, and each VOIU provides two(2) VoIP channels.

  • Page 78: Voiu Installation

    PCM voice and fax channels. 3.4.6 ISDN Board Installation There are 6 kinds of ISDN boards such as ARIA-130 BRIB, ARIA-130 BRIU, ARIA-130 PRIB, GDK-100 BRIB, GDK-100 PRIB and GDK-100 STIB, which can be used with ARIA-130. Each ISDN board contains RJ45 type jack on boards themselves.

  • Page 79: Aria-130 Isdn Brib (Basic Rate T Interface) Installation

    Installation Manual 3.4.6.1 ARIA-130 ISDN BRIB (Basic Rate T Interface) Installation The BRIB card provides 2 interface circuits of BRI (Basic Rate Interface) format digital CO interface. If more than one ISDN board is required, some special cable should be used for clock signal control.

  • Page 80: Aria-130 Isdn Briu (Basic Rate T Interface) Installation

    RJ45 CON5 Figure 3.4.15 BRIB Layout 3.4.6.2 ARIA-130 ISDN BRIU (Basic Rate T Interface) Installation The BRIU card provides 2 additional interface circuits of BRI (Basic Rate Interface) format digital CO interface for ARIA-130 BRIB. Function of LED The BRIU card provides 2 additional interface circuits of BRI (Basic Rate Interface) format digital CO interface for ARIA-130 BRIB.

  • Page 81: Aria-130 Isdn Prib (Primary Rate T Interface) Installation

    (default ON) 3.4.6.3 ARIA-130 ISDN PRIB (Primary Rate T Interface) Installation The PRIB card provides one interface circuit of PRI (Primary Rate Interface) format digital CO interface. If more than one ISDN board is required, some special cables should be used for clock signal control.
  • Page 82 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual LED1 LED2 LED3 LED4 LED5 LED6 CON1(OUT) CON2(IN) RJ45 CON8 ARIA-130 PRIB Figure 3.4.16 ARIA-130 PRIB Layout Check Points PRIB can be installed in the universal slot No. 1-6 of any KSU.

  • Page 83: Isdn Brib (Basic Rate T Interface) Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.4.6.4 GDK-100 ISDN BRIB (Basic Rate T Interface) Installation The BRIB card provides 4 interface circuits of BRI (Basic Rate Interface) format digital CO interface. If more than one ISDN board is required, some special cable should be used for clock signal control.
  • Page 84 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual The line connector and terminating resistors Line No RJ45 type jack Terminating Resistors Switch All ON All OFF Line 1 CON8 terminating open Line 2 CON7 terminating open Line 3 CON6...

  • Page 85: Isdn Stib ( Basic Rate S/T Interface) Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Check Points BRIB can be installed in the universal slot No. 1-6 of any KSU. The 2nd pole of SW1 should be set to the proper position according to the type of TEI.
  • Page 86 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual • Note CON1: Trace for the purpose of development and maintenance. The external module for RS-232C serial interface should be required for trace. See GDK-TRC1 in section 2.4.15. CON3, CON4: They are used to control the reference clock signal when multi-ISDN boards are installed.

  • Page 87: Isdn Prib (Primary Rate T Interface) Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Check Points STIB can be installed in the universal slot No. 1-6 of any KSU. Each interface should be set to the correct type, T or S with S/T selection connectors, according to the needs of user.
  • Page 88 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of LED Remark Status Function LED1 PLL Synchronization Sync. Error Normal LED2 Loss Of Signal from the Line Normal LED3 Alarm error Normal LED4 Frame Alignment Error Error Normal LED5...
  • Page 89 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual CON5 and application circuits on PRIB are removed on PRIB issue 2A to unify the method of tracing peripheral cards such as PRIB, BRIB, STIB and WTIB in all LDK systems.

  • Page 90: Vmib (Voice Mail Interface Board) Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.4.7 VMIB (Voice Mail Interface Board) Installation VMIB provides system announcement, ACD/UCD announcement, and User Greeting. If necessary, the FMEU(Flash Memory Expansion Unit) can be installed on VMIB for the expansion of User Greetings.
  • Page 91 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Function of various connectors Connector Function Remark Serial interface connector( 4pin) for trace Note 1 For the purpose of development Note 2 CN3, CN6, CN7 Not used CN4~CN5 VCEU expansion connector...

  • Page 92: System Wiring

    The external batteries must provide 24 Volts DC. This is generally accomplished by connecting two 12 volt batteries in a series arrangement. Operation on batteries is controlled by the PSU. This ARIA-130 PSU will provide charging current to the batteries during normal AC power operation at a maximum of about 500 mA.

  • Page 93: Rs-232C Wiring On Mpb And Siu

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.2 RS-232C Wiring on MPB and SIU MPB contains one standard RS-232C interface and SIU on MPB contains one standard RS-232C interfaces. RS-232C is connected by 9-pin “D” connector as shown in Figure 3.5.2. Wiring connector for RS-232C must include the Clear to Send(CTS) lead if it is enabled by Switch position 2 of the MPB.

  • Page 94: Misb Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.3 MISB wiring MISB provides connections for 2 music sources, 2 external page ports, 4 relay contact controls, and an alarm/door-bell input monitor through RJ21 type female connector. Table 3.5.2 shows the contact assignments of RJ21 type connector on MISB.
  • Page 95 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Relay contacts for general purpose MISB supports up to 4 Relay contacts, which can be used for the functions of Loud Control, Door Open and so on under the software control. These relay contacts are respectively connected with external equipment through 4 pairs of a RJ21 type connector, CHAMP1 on the board.
  • Page 96 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Table 3.5.2 shows the contact assignments of RJ21 type female connector on MISB. RJ21 MISB connector MISB Pair Color-Code Designation WH/BL RLY1-R BL/WH RLY1-T WH/OR RLY2-R OR/WH RLY2-T WH/GN RLY3-R GN/WH...

  • Page 97: Extension Board Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.4 Extension Board wiring Extension boards such as DTIB12, DTIB24, DSIB, SLIB24, SLIB48, SLIB II and SLIB2E contain a RJ21 type female connector for station wiring to each interface circuit on each board.
  • Page 98 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Area D Area A Area B Area C Area E RJ21 type connector on the board Figure 3.5.4.b Basic connection method between digital terminal interface of the system and digital terminal ...
  • Page 99 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Area D Area A Area B Area C Area E RJ21 type connector on the board Figure 3.5.4.c Connection method when the 4-wire line cord, or special connection method with contact number 2 and 5.

  • Page 100: Single Line Telephone Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.4.2 Single line Telephone wiring SLT interface boards such as SLIB24, SLIB48, SLIB II, SLIB2E and DSIB are wired to SLT or standard analog device with a single pair of wire that provides battery feed, voice and signaling from/to the connected SLT.

  • Page 101: Intercom/Door Phone Box Installation

    Intercom/Door Phone Box installation The Intercom/Door Phone Box is intended to be wall mounted. There are two kinds of Intercom/Door Phone Boxes in ARIA-130 system available. KD-Digital Phone Box can be connected to the digital terminal interface. First, separate the ICM/Door Box from the base plate by inserting a flat thin edged screw driver in the bottom of the product.

  • Page 102: Mohu Installation

    The ‘PORT 2’ is connected to the ‘MOH 2’. The maximum distance of the installation is 1 Km (3.2 Kft) from the system. ARIA-130 system is capable of accommodating up to 5 external music sources through 5 single line interfaces, which are limited by the main program.

  • Page 103: Contact Assignments Of Rj21 Type Connectors On Extension Boards

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.4.5 Contact Assignments of RJ21 Type Connectors on Extension Boards Table 3.5.3.a shows the contact assignments of RJ21 type connector on DTIB12/DTIB24. Rj21 DTIB connector DTIB Port Pair Color-Code Designation WH/BL...
  • Page 104 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Table 3.5.3.b shows the contact assignments of RJ21 type connector on SLIB24/SLIB48 and SLIBII/SLIB2E. SLIB Port SLIB connector RJ21 (SLIB24/SLIB48/SLIB II/SLIB2E) Pair Color-Code Designation WH/BL VT-1 SLIB24/48, BL/WH VR-1 SLIBII/SLIB2E WH/OR...
  • Page 105 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Table 3.5.3.c shows the contact assignments of RJ21 type connector on DSIB. RJ21 DSIB connector DSIB Port Pair Color-Code Designation WH/BL DT-1 0 (DKT 0) DKT I/F BL/WH DR-1 WH/OR DT-2...

  • Page 106: Pftu Wiring

    CO Line inputs from the telephone company, to the CO Line inputs of the system, and to Power Failure SLTs. The CO lines and SLTs are used as CO line inputs and extensions of ARIA-130 System in normal operation, but each CO line and SLT is directly connected in power failure mode by connecting as shown in Figure 3.5.8.
  • Page 107 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Table 3.5.4 shows the contact assignments of RJ21 type connector on PFTU. RJ21 PFTU connector PFTU Pair Color-Code Designation Circuit WH/BL COT1-IN Circuit BL/WH COR1-IN WH/OR COT1-OUT OR/WH COR1-OUT WH/GN TEL1-T...

  • Page 108: Analog Co Line Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.6 Analog CO Line wiring Analog CO boards such as LCOB and LCOB8 contain a RJ21 type male connector to connect to analog CO line on each board. The following provides details on the connection of each type of analog CO line Board.

  • Page 109: Contact Assignments Of Rj21 Type Connectors On Analog Co Boards

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.6.2 Contact Assignments of RJ21 type Connectors on Analog CO Boards Table 3.5.5 shows the contact assignments of RJ21 type connector on LCOB and LCOB8. RJ21 LCOB, LCOB8 connector LCOB Line...

  • Page 110: Emib Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.6.3 EMIB wiring You don't need to consider the polarity of 2 voice wires(for both transmit and receive path in 2 wire E&M or transmit path and receive path respectively in 4 wire E&M), but you should connect the Ear wire(-48V) of one system to the Mouth wire(open in the idle state) of the other system and the Mouth wire(open) of one system to the Ear wire(-48V) of the other system.

  • Page 111: Vacant Section

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual EX) The wiring of 4-wire voice path ARIA-130 system ARIA-130 system(or PABX) Voice path (TX-A, TX-B) (RX-A, RX-B) (RX-A, RX-B) (TX-A, TX-B) Mouth(GND) Ear(-48V) Signal path Mouth(GND) Ear(-48V) 3.5.6.4 Vacant Section...

  • Page 112: Voib Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.6.5 VOIB wiring The contact assignment of RJ45 type jack on VOIB is shown in Figure 3.5.11. 1 2 3 4 5 6 7 8 Figure 3.5.11 contact assignments of RJ-45 type jack of VOIB...

  • Page 113: Isdn Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.7 ISDN wiring ISDN boards such as BRIB, STIB and PRIB contain RJ45 type jack on each board, to connect to ISDN. Following Figure shows ISDN reference point and Functional group,...
  • Page 114 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual ISDN trunk connection (Basic Rate) LDK System ISDN Board ISDN BRIB STIB(T) Max. 1000 meters 1. Point to Point connection 2. TR: Termination resistor, 100 ohm Figure 3.5.13.b ISDN Trunk connection (Basic Rate Interface: T)
  • Page 115 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual ISDN Trunk connection (Primary Rate) LDK System ISDN Board Repeater ISDN PRIB Max. 1000 meters 1. Point to Point connection only 2. Without power feed. 3. Line Impedance: 120 ohm Figure 3.5.13.d ISDN Trunk connection (Primary Rate Interface)

  • Page 116: Brib Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.7.1 BRIB wiring BRI lines are connected to BRIB/BRIU through RJ45 type jacks. The contact assignment of RJ45 type jack on BRIB is shown in Figure 3.5.14.a. 1 2 3 4 5 6 7 8 Figure 3.5.14.a Contact assignment of RJ-45 type jack of BRIB...

  • Page 117: Stib Wiring

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.7.2 STIB wiring STIB is capable of connecting to 4 Basic Rate Trunk lines or Terminals through RJ45 type jacks. Each line is switchable by hardware and software setting. (see clause 3.4.6.2) The contact assignment of RJ45 type jack on STIB is shown in Figure 3.5.15.a.

  • Page 118: Prib Wiring

    3.5.7.3 PRIB wiring PRIB of ARIA-130 supports only TE mode(slave), so ARIA-130 PRIB can not used as NT mode for Q-sig, but GDK-100 PRIB can be used as NT mode for Q-sig in ARIA-130 system. PRIB is capable of connecting to 1 Primary Rate Trunk lines through an RJ45 type jack.

  • Page 119: Terminating Resistors On Basic Rate Interface(Brib/Stib)

    GDK-100 BRIB issue 3 or later version, GDK-100 STIB issue 2 or later version and ARIA-130 BRIB/BRIU issue 1 or later version. So switches on each line of the board should be ON to terminate them when installing line.

  • Page 120: Clock Control Cable Wiring- Multi Isdn Board Installation

    Clock Control Cable wiring- Multi ISDN board installation ARIA-130 system allows Multi-ISDN boards to be installed. When Multi-ISDN board installation, clock control cable should be connected according to the priority of the cards. Then, in case that the ISDN line of the board with the higher priority is in the state of Loss of signal or clock failed, the synchronized clock for system will be supplied from next daisy chained ISDN board.
  • Page 121 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Back Plane (Basic Mother Board) Priority < < of Boards STIB PRIB BRIB (T interface(s)) (TE mode) PLLU Clock Control Cable BRI Line PRI Line  Note: 1. Clock control cables supplied by LGE should be connected between ISDN boards according to the priority of them when multi-ISDN boards installation.
  • Page 122 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Back Plane (Basic Mother Board) Priority < < of Boards STIB STIB STIB (T interface(s)) (all S interfaces) (T interface(s)) PLLU (the highest priority) Clock Control Cable BRI Line  Note: 1.
  • Page 123 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual The followings are the clock chain with the other ISDN board in the ARIA-130 system. There are three cases. Lowest Priority Highest Priority Figure 3.5.19.a Case 2 of clock chain...
  • Page 124 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Highest Priority Figure 3.5.19.b Case 3 of clock chain...
  • Page 125 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Highest Priority Figure 3.5.19.c Case 4 of clock chain...

  • Page 126: Qsig Connection

    3.5.7.6 QSIG connection ARIA-130 system supports QSIG function using ISDN boards. There are two kinds of connection for supporting QSIG function. One is the direct connection between LDK systems with PRI line, the other is the connection through Public Network with PRI or BRI lines.
  • Page 127 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual The connection through Public Network LDK/GDK PRIB/BRIB/STIB can be used for this connection. For more details, see the manual for GDK-162/100/FPII Q-signaling Interface. LDK/GDK system LDK/GDK system PRI/BRI(TE) PRI/BRI(TE) Public ISDN PRI /BRI(TE) Figure 3.5.20.b The connection through the Public Network for QSIG feature...

  • Page 128: Emi Suppression

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.7.7 EMI Suppression Installation of EMI core on line(s) of STIB is required to suppress EMI. Install two EMI cores supplied in STIB package as following Figure 3.5.21. When the core is installed on 1 or 2 lines, it may be slip down. In that case, winding wire with a string such as cable tie is recommended.

  • Page 129: Contact Assignments Of Various Types Of Connectors

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.8 Contact Assignments of various types of connectors The contact assignments of various types of connectors are described in this clause. 3.5.8.1 RJ21 type connectors The contact assignments of RJ21 type (25-pair Amphenol) connectors a.

  • Page 130: Miniature 8-Position Jack For Isdn Connection

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 3.5.8.3 Miniature 8-position jack for ISDN connection The contact assignments of miniature 8-position jack used for ISDN connection. a. Basic Rate User network Interface ISO 8877 ITU-T Rec. I.430 Contact Polarity...

  • Page 131: Section 4. Isdn Boards

    Installation, and 3.5.7 ISDN wiring. Otherwise, for more details for the features and Admin programming related to ISDN, see Programming Manual. 4.1 Basic Information There are several kinds of ISDN board on ARIA-130 system as follows; Channels Board Channels (Option) Interface Max.

  • Page 132: Station/Co Line Number Assignments

     ISDN TES (Terminal Equipment) There are many ISDN TES. (ex. ISDN Phone, Video-Phone, G4 Fax, PC-Card, etc.) ARIA-130 supports all ISDN TES which are compatible with Euro-ISDN (ETSI ISDN Specification) till now on. ISDN phone can call another station on the ARIA-130 and access analog/ISDN CO lines.

  • Page 133: Section 5. Dect Installation

    The GDC-330H/335H/340H is a wireless terminal. The ARIA-130 WOTS is connected to an existing telephone system and accommodates up to 16 base stations and up to 80 wireless terminal users. Each base station provides 5 channels and calling coverage of up to 190,000 square meters in open space.
  • Page 134 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual (a) ARIA-130 Key Telephone System (b) Wireless Terminal (c) Charger(330-SSC) (d) Base station(GDC-330B) (GDC-33Xh) (e) Wireless Terminal(GDC-340H) (f) Charger(340-SSC) Figure 5.1.1 Components of a ARIA-130 and ARIA-300 WOTS...
  • Page 135 In ARIA-130 system, Maximum 80 wireless terminals can be registered. Base stations may be mounted on walls or desktops up to 600 meters away from the ARIA-130 WOTS using twisted 2-pair unshielded cable (0.5φ, AWG 24). They are remotely powered (DC 30 volts) by the WTIB.

  • Page 136: How To Make Calls In The Aria-130 Wots

    A. Before Making Initial Call It is similar to other calls in a telephone system to make a call in ARIA-130 WOTS, except that every call to or from a wireless terminal involves establishing RF link to the wireless terminal through a base station.

  • Page 137: Aria-130 Wots

    Figure 5.3.1 Layout of the ARIA-130/ARIA-300 WTIB LED, Switch and Modular Connector The 9 LEDs mounted on the ARIA-130/ARIA-300 WTIB provide diagnostic information for status of the board. Table 5.3.1 shows the meaning of various status of the LEDs. LED Number...
  • Page 138 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual The modular connector JK1, JK2, JK3, JK4(WTIB), JK1, JK2, JK3 and JK4(WTIU) are connected to base stations by twisted 2-pair unshielded cable. Table 5.3.2 shows the relation between modular connectors and associated cell numbers.
  • Page 139 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Base stations may be mounted on wall or desktop up to 600 meters away from the WTIB using a twisted 2-pair unshielded cable(0.5φ). The system supports max. 24 base stations. In typical office environments, each base station has a broadcast range of 50 meters and supports an area of 8,000 square meters.
  • Page 140 If the user moves out the area and into the service area of adjacent base station, the latter one will intercommunicate with the user’s wireless terminal. So, in the whole area where the base stations of ARIA-130 WOTS cover, users can make or receive a call without any problem. It is called ‘Roaming’...
  • Page 141 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual  The LCD displays call information and the status of terminal.  The keypad contains specially labeled keys assisting users to make calls and operate telephone features. Subscription The wireless terminals associate unique identities, to prevent unauthorized use of the PSTN line. See the User Guide of the GDC-33xH and GDC-340H for the subscription of wireless terminals.

  • Page 142: System Configuration

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Charger (330-SSC & 340-SSC) The GDC-33xH comes with a charger that accommodates GDC-33xH and one type of battery pack. And the GDC-340H comes with a charger that accommodates GDC-340H and standard rechargeable battery.

  • Page 143: Before Installation

    Issue: 1.2 Installation Manual The ARIA-130 WOTS is used in single cell or multi-cell (maximum 16 cells). 5.4.1 Before Installation Followings are the factors that affect the quality of service for the ARIA-130 WOTS. • Location of base station •...
  • Page 144 Once you have completed the steps described in Site Survey on sub-clause A and determined the number of base stations you need, you should determine where to install the base stations for optimum coverage and operation of the ARIA-130 WOTS. C. Traffic Guidelines Each base station supports five simultaneous calls, but because all users are not simultaneously in call statistically, a base station can support a greater number of wireless terminal users in practice.
  • Page 145 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual ARIA-100 WOTS Number of Cell Recommended Number Number of maximum Simultaneous (Base station) Registered Wireless Terminals Wireless Conversation 8~80 Table 5.4.1 Suitable Wireless Terminal Number according to Base Station Number D. CRS(Cell-Coverage Region Survey) Tool For the easy installation, LGE prepares the portable tools which consist of the base station and the wireless terminal.

  • Page 146: Hardware Installation

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Place the base stations where to minimize obstructions near antennas. If you mount a base station on a wall, place it higher than the average tall person and do not mount it near doors that could temporarily obstruct antennas when the door is opened.
  • Page 147 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Aria-100 WOTS Equipment • WTIB, WTIU (optional) • Base stations (GDC-330B) , Connecting block and line cord, Ferrite core • Wireless terminals (GDC-33xH, GDC-340H), Single-slot charger (330-SSC, 340-SSC), Battery (330-SBP, standard rechargeable battery AAA size) and Adapter (330-HAP) Fig 5.4.3 show the packing components of the WTIB and WTIU.
  • Page 148 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Line Cord Base Station(GDC-320-B) Base Station(GDC-330B) 1 Ferrite Core Wall Mounting Wedge Connecting Block for base line cord Figure 5.4.4 Packing Components of GDC-330B Note: Place the Ferrite Core close to a System(WTIB) side as close as it can be.
  • Page 149 B. Unit Installation WTIB/WTIU Installation In ARIA-130 Digital Key Telephone System, WTIB is a base station interface board. ARIA-130 system can have two WTIB and WTIU. If the WTIB is installed in a power-on system, the system and/or WTIB can be damaged. Thus after system power is off, the WTIB should be plugged in/out to/from the system.
  • Page 150 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Before mounting base station permanently, you should determine a suitable location providing the best coverage. Use the last sheet of this manual for mounting template to drill pilot holes in the wall.
  • Page 151 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Installing the Base Station using the wedge, Determine at first the location on wall where the wedge prepared for mounting the base station is to be fixed. The wedge should be settled by using two screws on the wall.
  • Page 152 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Ferrite core is provided in the package of Base station for EMI. Ferrite core should be installed when WTIB is installed in the key telephone system. One Ferrite core in the package of base station is for line cord between base station and each port of WTIB &...
  • Page 153 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual To install a GDC-33xH(GAP), GDC-340H(GAP), simply take out the handset and batteries (330-SBP, rechargeable battery), charger(330-SSC, 340-SSC) and AC/DC adapter(330-HAP) from the package and assemble it. Before using the GDC-33xH and GDC-340H, you should recharge the battery fully.

  • Page 154: User Subscription/Desubscription

    5.4.3 User subscription/desubscription A. System ID Description System ID is given to the ARIA-130 system attached the wireless GAP terminal for identification. System ID, which is PARK(Potable Access Rights Key), is written on MPB. PARK: 31100013411741 Authentication Code as well as system ID should be entered at only attendant station, before you begin to subscribe wireless terminal (GAP) to ARIA-130 system.
  • Page 155 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual Conditions You must program for system ID when you install the system. If you program system ID, all data that were related to wireless features will be erased. The initial PARK value is 00000000000000. So the value will be display in LCD at first B.
  • Page 156 ③ Press Flexible Button 1. ④ Enter the station number. ⑤ Enter the phone type (LG-GAP for ARIA-130 system or standard GAP for any other system). In case of LG-GAP terminal, press [1] button. Otherwise press [2] button. * Note : In case of GDC-340H, If MPB version is 1.0Ba above, press [3] button.
  • Page 157 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual ⑪ If failed, repeat ③~⑥ steps of the attendant and ①~⑧ steps of wireless terminal. The key sequence of the PARK : LLP__________PC : Two digits decimal representation of PARK length (Bit count)
  • Page 158 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual D. User Desubscription Description This procedure makes a wireless terminal loose access right to the ARIA-130 system. To de-subscribe the wireless terminal, it should be in an idle state. Operation Attendant station [Trans/Pgm] Flex.
  • Page 159 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual ② Press ‘ 0, # ’. ③ Press flexible button 7. ④ Enter password. ⑤ Press [Hold/Save], you will be heard confirmation tone.  To erase a special wireless terminal [Trans/Pgm] + Flex.

  • Page 160: Summary Of Dect Installation

    ② If there isn’t next registered system, handset displays “UNREGISTERED” on LCD. 5.4.4 Summary of DECT Installation Check and prepare the equipment. Install a ARIA-130 Digital Key Telephone System. Install the WTIB (and WTIU). Determine location of base stations. Install base stations.

  • Page 161: Aria-130 Dect - A Quick Programming Guide

    Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual 5.4.5 Aria-130 DECT - A Quick Programming Guide Determine the PARK number. The Portable Access Rights Key number can be found on a label on the MPB. e.g. 31100013505703. If the PARK No has already been entered into the system, you can read it from the attendant position,...
  • Page 162 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual At the GDC-340H wireless terminal: - At the GDC-335H wireless terminal: - • • Press the function button. Press the MENU button • • Dial 0 Select “register” (dial 5 + 1) •...
  • Page 163 Aria-130 Digital Key Telephone System Issue: 1.2 Installation Manual To enter the Technicians Menu from the GDC-335H Wireless Terminal • Press function key • Dial * • Dial PIN - LGGAP (= 54427) ( FAC code) • Press function key •...
