Thank you for using our company's Bluetooth Headset product, for your fast & skilled operating of this
product.,please read this manual carefully.
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
NOTE 1: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
A.Start Use
1.Charge Bluetooth Headset
This bluetooth headset with built-in rechargeable lithium battery.The first time you use it,please charge it
at least 4 hours to make it full of power,then following time,charge about 1 -2 hours is enough. When you
charge, solid red LED light indicates charging and will turn blue when full charged,full battery can
be support about 10 hours of continuous working hours.
Plug in the Micro USB cable and charge before use (Suggestion : Don't use the car charger at first
time).
2. Button Function and Interface
S1.Multifunction button: Reject a call(incoming call status),Power on/off, Answer/Hang Up,Redial and
Pair to other bluetooth devices.
S2. Previous button: Play previous (stereo status), Speaker silent(phone state)
Z-B80 User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z-B80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZONOKI Z-B80

  • Page 1 Z-B80 User Manual Thank you for using our company’s Bluetooth Headset product, for your fast & skilled operating of this product.,please read this manual carefully. FCC WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
  • Page 2 S6: Pause/ Play button (stereo condition) LED: Work Indicator 3.Connect to bluetooth device Z-B80 should be paired to mobile phone(or other Bluetooth devices) before using. 1).First step: Shutdown status: press S1 and hold for 5 seconds→red & blue light will flash twice at the same time→...
  • Page 3 Blue light flash slowly Bluetooth:Connection has been established, the headset can start operating. Red&blue light flash Bluetooth: Quickly flashing indicate the headset can be alternately connected, but it has not been connected. No indicator Power off Battery status Indicator Battery Note Red light flash with <10%...
  • Page 4 Dial a call Dial-up using the phone's keypad 1).Using your phone, dial numbers as usual, during connecting , headphones with vibration ring tones. When getting calls, sound will be automatic switched to the bluetooth headset, after getting the calls,the red light will flash 2 times per second. If you want to hang up, just press S1button once. 2).Press S1 button twice, it can automatic to dial the telephone number which you made phone calls the latest time,when coming in call,sound will be automatic switched to the bluetooth headset,after getting the calls,the blue flash 2 times per second.If you want to hang up, just press S1 button once.
  • Page 5 Third step:Start-up“My bluetooth”in computer,searching the bluetooth equipment,then you can find the “Z-B80”in equipment list. Fourth step: Choose“Z-B80” in the list,input the Pin-Code “0000” in computer. (Note:“0000” is the fixation pairing Pin-Code for bluetooth headset.) Fifth step: Pairing successfully, blue light flash slowly(around 1 time per 4 seconds).
  • Page 6 8. When my mobile is searching the headphone,why do several bluetooth equipment appear? —Within the effective distance,when you mobile phone is paring,all of the bluetooth devices can be searched (such as IPDA,Notebook…) . It may display “Z-B80” (or Unknown Equipment) on your mobile.
  • Page 7 —The communication QQ & SKYPE be effected by the network. 12. What should I do if my headset can not hear very clearly? —Adjust the volume button or press “Volume+” on your mobile to increase the volume and test if mobile is within a strong-signal area.
  • Page 8 penetration. • Prohibit to use when jogging or walking in rain. •Please don't use if sweat. • Depending on the way to use, water enter may result in fire, electric shock or other problems. Under all of the above cases, please use headset in the case of the USB jack covered completely. F.
  • Page 9 ● About 10 meters long-distance transmission range (open environment). ● 3 color to choose : titanium gray/black, metallic blue/black and white/cool gray Item: Specification: Bluetooth edition Bluetooth V4.0 +APT-X Frequency coverage 2.402GHZ~2.480GHZ ISM Band Transmit Range <=10m Frequency Response 20HZ-20KHZ Status Indication LED indicator Pairing products...
