WNM

Wireless Network Module

May 2016

236-705-00C

900MHZ, 2.4GHZ

Ethernet Serial

Table of Contents

Need help?

Do you have a question about the WNM and is the answer not in the manual?

Questions and answers

Summary of Contents for Moore Inductries WNM

Page 1 Wireless Network Module May 2016 236-705-00C 900MHZ, 2.4GHZ Ethernet Serial...
Page 2: Table Of Contents
PTP (Point to Point) Network (Serial only) ........................14 SSE (Smart Switch Ethernet) Network (Ethernet only) ....................14 WNM Configuration ................................15 Installing the WNM Configuration Program ..........................16 Connecting the WNM to PC ..............................16 For Ethernet WNM Radio ..............................16 For Serial WNM Radio ..............................16...
Page 3 Antennas ..................................28 Surge Suppression ................................29 Power Supply ................................29 Other Items..................................29 Operation & Diagnostics ...............................30 Radio LED Status Indicators ............................30 Diagnostics Tools (WNM Ethernet Only) ..........................31 Signal Strength ................................31 Spectrum Analyzer ................................31 Password..................................33 Customer Support ................................34 Appendix A - Antenna Selection ............................35...
Page 4: Introduction
The available combinations may vary in the first version 2.4GHZ band (specify for Ethernet or serial or both): WNM radios if the Model WNM is ‘Serial only’ or an WNM/ETHERNET/…/-2.4GHZ/… Ethernet (with serial). For any combination of first and...
Page 5 Please use this manual as your guide as readily as the 900 MHz band. for your WNM radio familiarization, performance, installation guidelines, safety considerations, and diagnosis of operation. Figure 1. Typical WNM wireless network system using Master, Repeater and Remotes. (REMOTE) WNM Wireless Network Module...
Page 6: About This Manual
Caution - provides information on steps to take in avoiding procedures and practices that could risk damage to the WNM or other equipment. Note - provides information to help you avoid minor inconveniences during calibration, installation, or operation of the WNM.
Page 7: Dimensions
Wireless Network Module Figure 2. WNM Current Installation Dimensions. 25mm 900 MHZ (.98 in) 36mm (1.52 in) 135mm (5.3 in) 4.8mm (.19 in) 118mm 31mm (4.64 in) (1.23 in) 25mm (.98 in) 36mm 2.4 GHZ (1.52 in) 135mm (5.3 in) 4.8mm...
Page 8 Wireless Network Module Figure 3. WNM Legacy Installation Dimensions. Ethernet Radio 53mm (2.1 in) 31mm (1.25 in) 117mm (4.6 in) 114mm 41mm (4.5 in) (1.6 in) Serial Radio 52mm (2.05 in) 23mm (.93 in) 94mm (3.7 in) 104mm 44mm (4.1 in) (1.74 in)
Page 9: Terminal Designations For Ethernet And Serial Models
DCE; no data; use for WNM Legacy Serial only configuration only * Use care when grounding WNM to prevent ground loops. Power supply GND is internally connected also to WNM metal case, RF connector, DB9 connectors, signal GND within DB9, and COM. Ground cables properly.
Page 10: Quick Setup Guide
Also included is The following guide provides an outline of the steps any RF (lighting) coax cable surge protection to planning, configuring and installing your WNM plus a lighting earth rod at ground level. network. For more detailed information please refer to Preferred is a short coax cable length from the relevant topics in this manual.
Page 11: Configuration
(for future The WNM Configuration program can be used to maintenance purposes, as desired). modify and save the WNM setup and also to monitor Verify the correct WNM radios (refer to WNM radio performance. Please see the Configuration factory tags regarding Master and various section for more information.
Page 12: Network Architecture
Master Radio Hand sketch your system on paper as to All WNM communication network types must have a physical layout (map). This includes the host Master radio. There is always only one Master radio site plus all remote sites.
Page 13: Repeater Radio
Master radio. Communications may be from: any remote to the Master WNM radio; the Master WNM to any WNM remote radio; any WNM remote radio via the Master WNM and then to any other WNM remote radio;...
Page 14: Pmp (Point To Multipoint) Network (Serial Only)
WNM Master radio. The WNM Master radio then sends this message to every WNM remote radio. This method is bandwidth intensive since all data is sent to all WNM sites. PTP (Point To Point) Network (Serial only)
Page 15: Wnm Configuration
Industries prior to shipping. They are also tagged on the bench or ‘on the air’ in an ‘already to indicate where each WNM is to be installed. If configured and operational’ communications no changes are required, then this section may be network.
Page 16: Installing The Wnm Configuration Program
Installing the WNM the PC Configuration Program Connect the computer to your WNM Master radio as Refer to Table 1 for the equipment needed. follows. These same connections apply to all other WNM radios. Connect the computer to only one WNM Insert the Moore Industries Interface Solution radio at a time.
Page 17 Figure 5. Connecting WNM Ethernet radio to PC Power 10-24VDC RJ45 Ethernet Crossover Cable P/N: 803-821-26 Ethernet Ethernet LAN Switch Straight Cable Straight Cable P/N: 803-824-26 P/N: 803-824-26 Figure 6. Connecting WNM Serial only Legacy to PC Power 10-24VDC Serial Cable P/N: 803-831-26 The Interface Solution Experts...
Page 18: Wnm Configuration Example
This is later saved on the laptop hard disk as the filename for this particular Load and run the WNM Configuration program. The network. In the future, these saved networks following is familiarization to set up a small network may be retrieved via ‘Configuration’, ‘Modify’,...
Page 19: Setting Up The Master Radio
RF Encryption Level is normally set at 128- bit AES via the pull down menu. Optionally The WNM radios are designed to operate as a you may select ‘Disabled’ if no encryption is transparent communications link. That is, the WNM desired.
Page 20 If the WNM Config program does not successfully laptop computer via an Ethernet cable, press the identify the Model WNM IP address; or the ‘Config ‘Select Radio’ button. The WNM Config program will Radio’ button does not operate then perform the perform a ‘Discovery Scan’...
Page 21 ‘Serial Settings’ button. This is to configure the power settings. Normally this is not required. Do serial port setups on this WNM radio. Use the setup not exceed the minimum amount of power required as shown here for most RS485 serial networks. You to provide reliable communications.
Page 22: Setting Up Remote Radios
Each time the ‘Configure Radio’ button is pressed, physically travel to each of the remote sites to the entire radio setup is sent to the particular WNM correct the discontinuous address path. radio. A graphic bar shows progress of the download.
Page 23: Save Configuration
Windows Explorer. This may be a timesaving convenience if most networks are virtually identical to others. There is no ‘Save As’ feature in WNM Config’. All files are saved in the same folder as WNM Configuration program. Loading a Network Configuration Previously stored network configurations can be retrieved from the computer.
Page 24: Bench Setup
The WNM radios are pre-configured to (cable). That is, if the WNM is to replace an Ethernet operate as a radio network. The WNM provides the cable or a serial twisted pair cable for a long distance ‘transparent’...
Page 25: Installation
Wireless Network Module Installation In the event of accidental contact with electrical wires during installation or any future time, lethal voltages may be become present on antenna, structures, Important Safety Information cables, and on wiring entering building. Assure The statements contained in this section are required. cabinets are all grounded properly.
Page 26: Industry Canada Requirements
These radio devices comply with Part 15 of the FCC Rules as well as Industry Canada Rules. Operation is The Model WNM is factory configured with standard subject to the following two conditions: antennas to be at or less than the maximum RF power allowed.
Page 27: Eu And International Requirements
Grounding antenna installations. Consult local requirements. The WNM metal case is connected to its DIN rail. It is recommended that the DIN rail be connected to earth ground. This is the same recommendation for Field Installation grounding of any metal case instrument.
Page 28: Wnm Accessories
For best installation, always comply with the instructions included with each antenna. Antennas Antennas for each WNM on network must be the same frequency band. It is OK to use any combination of omnidirectional antennas and Yagi antennas on the same network.
Page 29: Surge Suppression
Power supply should be 10 V to 24 Vdc, regulated. For RFI suppression, install a ferrite bead on power supply cable adjacent to WNM power supply connector. Power supply cable length should not to exceed 3 meters (9 feet) length.
Page 30: Operation & Diagnostics
If the radio is not linked, the signal strength leds will illuminate one at a time and repeat. *Ethernet led is not present on Legacy “Serial Only” Models Figure 7. WNM Front Panel LED Layouts LEGACY CURRENT The Interface Solution Experts...
Page 31: Diagnostics Tools (Wnm Ethernet Only)
Network Module Diagnostic Tools (WNM Ethernet only) Additional diagnostic tools are provided for the Ethernet version of the WNM by the PC Configuration program. For set up of the program please see Installing the WNM Configuration Program section. Verifying Communication...
Page 32 Next, use your mouse to navigate to the ‘Select Radio’ button and click. This will require a few seconds as the WNM Configuration program scans for all of the Ethernet radios on this network. Select the desired radio from the network and press the ‘OK’ button. This process will likely be repeated for each radio site to be investigated.
Page 33: Password
Clear: Deactivates the red color graphic and a comparative interpretation of the RF spectrum. It is disables historical peak (Max Peak = Max desirable that the signal strength of the WNM network Hold) be 10dB (or higher) greater than other RF signals to Show Mean Value: Mathematical average of obtain optimum transmissions.
Page 34: Customer Support
Wireless Network Module Customer Support Moore Industries is recognized as the industry leader in delivering top quality to its customers in products and services. We perform stringent quality assurance checks on every unit we ship. If any Moore Industries product fails to perform up to rated specifications, call us for help.
Page 35: Appendix A-Antenna Selection
All WNM radios, coax, RF surge accessories Antennas supplied by Moore Industries are and antennas use 50 Ohm impedance. No suited for mounting atop metal poles. Such...
Page 36 Wireless Network Module Antenna Types Directional. This antenna style is most common for the remote sites There are a moderate number of antenna types. Each has its advantage depending upon particular a) Yagi. Sometimes referred to as a application. Here are the popular types for process ‘beam’...
Page 37 RETURN PROCEDURES To return equipment to Moore Industries for repair, follow these four steps: 1. Call Moore Industries and request a Returned Material Authorization (RMA) number. Warranty Repair – If you are unsure if your unit is still under warranty, we can use the unit’s serial number to verify the warranty status for you over the phone.
