  • Page 1 blue PiraT2 / 5E User Guide Version 2.4.1 / 21.09.2016...
  • Page 2: Table Of Contents

    6.6.7.7 Install configuration ..................19 6.6.7.8 Safely remove ext. Mem................20 Starting the blue PiraT2 ....................21 Download and installation of the Telemotive System Client ........23 Interfaces at the rear side ..................25 Adapter cables ......................... 27 Universal adapter cable .................... 27 Power cable for blue PiraT2 5E (Art.
  • Page 3 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 3 von 71 User Guide 9.4.1 Status Logger: OK ................... 34 9.4.2 Status Logger: WARN ..................34 9.4.3 Status Logger: RING ..................34 9.4.4 Status Logger: MEM ..................35 9.4.5 Status Logger: ERROR ................... 36 10 Interfaces .........................
  • Page 4: License Agreement

    The software is a copyright property of the Telemotive AG. The program or parts of it may not be further licensed to third parts, rented, sold or be further marketed in any form without explicit writ- ten approval by Telemotive AG.
  • Page 5: Product Liability

    The burden of proof is with the customer. The Telemotive AG does ensure the legal warranty according to German law. Except for warran- ties expressly set forth in this agreement, any and all products are delivered “as is” and the pro- ducer makes and the customer receives no additional express or implied warranties.
  • Page 6: Overview

    Overview This user guide describes the administration of the second generation of blue PiraT data logger of the Telemotive AG, called blue PiraT2, as well as for the newest, for Ethernet recording op- timized generation, the blue PiraT2 5E. In all functions which are equal to both devices we use the name blue PiraT2 in this user guide.
  • Page 7: System Requirements

    User Guide System requirements Control Unit A Windows based Laptop or PC is needed to configure the devices of Telemotive AG by Telemotive System Client. It also allows to save the recorded data and to use them offline later. Telemotive System Client The software client is used for configuring the data logger as well as downloading the recorded data or convert these into your needed file format.
  • Page 8: Further Manuals

    User Guide Further manuals Beside this user guide we offer the main manuals for our client as well as for the different data logger generations in our ServiceCenter at https://sc.telemotive.de/bluepirat. User manual for the Telemotive System Client https://sc.telemotive.de/4/uploads/media/TelemotiveSystemClient_UserManual.pdf User manual for blue PiraT2 / blue PiraT2 5E https://www.telemotive.de/4/uploads/media/blue_PiraT2_UserManual.pdf...
  • Page 9: Additional Features By Optional Licenses

    Additional features by optional licenses Additional features can be activated by purchasing and installing licenses. Licenses can be or- dered at our sales team. You find the user guides for these additional features in the Telemotive ServiceCenter. Currently the following licensed features are available.
  • Page 10: The Blue Pirat2 System

    Ethernet. For the download and the conversion of the logging data the Telemotive System Client is available. For the available conversion options to various trace file formats please have a look at chapter Fehler! Verweisquelle konnte nicht gefunden werden.
  • Page 11: Model Versions Of Blue Pirat2 / Blue Pirat2 5E

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 11 von 71 User Guide Model versions of blue PiraT2 / blue PiraT2 5E The blue PiraT2 supports a lot of bus systems which can be recorded by the data logger. This table shows which model of the blue PiraT2 supports which number of interfaces and channels.
  • Page 12: Control Elements At The Front Side

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 12 von 71 User Guide Control elements at the front side The next section describes the usage of the controls and connectors of the blue PiraT2 / 5E. Figure 6.1: Front side of the blue PiraT2 Attention: If you have ordered an external antenna, e.g., for GPS, the connector has to be bolt only by hand NOT with any tools.
  • Page 13: On / Trigger Button

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 13 von 71 User Guide On the front side of the blue PiraT2 you will find the display and some control elements. The blue PiraT2 is available with one 1-Gbit-Ethernet port on the front and also with four addi- tional 100-Mbit-Ethernet ports, where an Ethernet switch is integrated.
  • Page 14: External Storage

    The blue PiraT2 offers additional the possibility to store data parallel to a removable media as SD card or USB device. The configuration of the feature [Logging to External Storage] is de- scribed in the Telemotive System Client user guide. 6.4.1 Compact Flash card (CF) The CF card has to be formatted in the FAT32 file format.
  • Page 15: Usb Storage

    PiraT2 5E. External power supplies are not needed. Note: Telemotive AG recommends the testing of every external storage before using it in a measurement. We suggest that especially USB devices with USB 3.0 are sometimes not recognized by the system.
  • Page 16: Startup

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 16 von 71 User Guide 6.6.1 Startup During the Startup phase the display shows: blue PiraT2 After the Startup phase is finished, the display shows the status of the most important interfac- es.
  • Page 17: Info

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 17 von 71 User Guide 6.6.3 Info This main category has currently twelve sub categories: 1. Firmware: current firmware of the logger 2. Hardware: mainboard version of the logger 3. SerialNr: Serial Number of the logger 4.
  • Page 18: Memory Device

    In order to copy the recorded data to an external memory you have to perform the following steps: 1. In the Telemotive System Client under General / External Storage set [Logging on Ex- ternal Storage] to [Off] 2. Click on the button [Write to logger] 3.
  • Page 19: Create Bug Report

    There are two ways to update the firmware of the logger with a removable device. 1) Over the device menu a) In the Telemotive System Client under General / External Storage: set [Firmwareupdate via Removable Media (CF/SD/USB):] to [Selection by user via device menu] b) After pressing the [menu] knob a verification message will be displayed.
  • Page 20: Safely Remove Ext. Mem

    Otherwise the message <install failed of Config file> is shown. 2) Automatically when plugged in or on startup a) In the Telemotive System Client under General / External Storage: Set [Configuration via Removable Media (CF/SD/USB):] to [Automatic detection on startup / plugin].
  • Page 21: Starting The Blue Pirat2

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 21 von 71 User Guide Starting the blue PiraT2 Connect the blue PiraT2 via the power harness (red/+/clamp 30 and black/GND/-/clamp 31) with the vehicle battery or a power supply. Figure 7.1: Power connection of the blue PiraT2 Note: blue PiraT2 5E has a separate power cable which is separated from the main cable set! Figure 7.2: Power connection of the blue PiraT2 5E...
  • Page 22 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 22 von 71 User Guide Pressing down the [menu] knob will enter the menu mode. Now select the main category “[1] Info”, then choose the sub category “9/12” with the IP in the display. This IP address is required for the next step.
  • Page 23: Download And Installation Of The Telemotive System Client

    The connection between the logger and your computer system will be established. Please take care that the network settings of your network adapter are set to Obtain IP address automati- cally. Click [Download], to download the Telemotive System Client directly from the logger. Follow these steps, depending on your browser: Browser...
  • Page 24 Datum: 21.09.2016 Seite 24 von 71 User Guide After successful installation you will find the Telemotive System Client icon on your desktop. Double-click the icon to start the application. Figure 7.6: Desktop icon You can download the entire manual for the Telemotive System Client in our ServiceCenter.
  • Page 25: Interfaces At The Rear Side

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 25 von 71 User Guide Interfaces at the rear side Figure 7.8: Rear side of the blue PiraT2 with MOST150 On the various data logger types are the following connectors possible: ...
  • Page 26 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 26 von 71 User Guide Figure 7.9: Rear side of the data logger blue PiraT2 5E MOST150 Important: In contrast to the blue PiraT2 the blue PiraT2 5E has a separate power supply (see at the right side below) Figure 7.10: new power supply connector with reverse polarity protection The newly delivered loggers are equipped with a reverse polarity protected power supply con-...
  • Page 27: Adapter Cables

    This section describes which adapter cables are available for the bluePiraT2 and blue PiraT2 Universal adapter cable Telemotive AG offers adapter cables that connect to the multi function connector and split up its lines to separate connectors. Figure 8.1: Connecting the blue PiraT2 via the universal adapter cable...
  • Page 28: Adapter Cable Serial/Rs232, Analog/Digital

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 28 von 71 User Guide Adapter cable Serial/RS232, Analog/Digital The following figure shows the adapter cables for 6x RS232, one digital IN and one analog IN. Figure 8.3: RS232/digital/analog adapter cable Note: The blue PiraT2 actively sends data on the “Tx”...
  • Page 29: Adapter Cables For Analog/Digital

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 29 von 71 User Guide Adapter cables for Analog/Digital The following figure shows the adapter cables for ECL, 4x digital IN, 8x analog IN and 2x digital OUT. Figure 8.5: Adapter cables for digital/analog This adapter cable is only available for the logger types 150M14C8LFR and 25M24C8LFR.
  • Page 30: Adapter Cable For Remote Control Voice (Rcv)

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 30 von 71 User Guide Adapter cable for Remote Control Voice (RCV) Figure 8.8: Adapter cable for Remote Control Voice (RCV) Please note: When using a blue PiraT2 5E the power connector of the universal cable set has to be connected too although this device has an own power cable because this connection is needed for the RCV/RC.
  • Page 31: Logging Data

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 31 von 71 User Guide Logging data Setting markers Interesting points in time can be designated by the [ON / Trigger] button at the front panel or at the Remote Control. When pressing this button, the data logger saves the current time to hard drive.
  • Page 32: Time Stamp

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 32 von 71 User Guide Figure 9.2: Setting triggers using digital Input The setting for the <Sampling interval> is needed to debounce the external push button and be sure that only one trigger is set. The external push button can be connected to the power supply of the car and the Digital In mentioned above.
  • Page 33: Standby Mode

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 33 von 71 User Guide Standby mode The table below shows, which busses or signals are monitored for keeping the logger alive and which busses or signals are able to wake up the logger. Table 9.2: Standby mode –...
  • Page 34: Memory Space And Level

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 34 von 71 User Guide Memory space and level About the ring buffer and other options, such as the protection of areas around markers, the characteristics of the logger can be configured what to do, when the internal memory is full. The following status messages can occur during operation of the data logger.
  • Page 35: Status Logger: Mem

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 35 von 71 User Guide blue PiraT2 Memory-LED is off. blue PiraT2 display Line three shows the level of the ring buffer on the internal memory. Table 9.4: Status Logger: RING 9.4.4 Status Logger: MEM Internal memory is nearly full, no more data will be stored soon Case 1: The ring buffer is enabled and more than 95 % full (as Status RING), in addition over...
  • Page 36: Status Logger: Error

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 36 von 71 User Guide blue PiraT2 Memory-LED switches on. blue PiraT2 display The following message is displayed, when recording medium is full (Memory: 100% Prot: 100%). The third line shows flashing that the storage medi- um is full.
  • Page 37: Interfaces

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 37 von 71 User Guide Interfaces The different interfaces of the blue PiraT2 supported bus systems are described in this chapter in more detail. 10.1 CAN The blue PiraT2 is able to record data in compliance with the CAN specification 2.0a (11 Bit identifier) and 2.0b (29 Bit identifier).
  • Page 38: Recording Contents

     Overrun These error states are only included in the Telemotive file formats. After reaching a certain number of errors (50 errors), the recording of error states is interrupted until reception of the next successful CAN message to avoid an overload of the recorded data.
  • Page 39: Lin

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 39 von 71 User Guide 10.2 LIN The blue PiraT2 is able to record data compliant to the LIN specification V1.3, V2.0 and V2.1. The data logger does not actively appear as a bus member. Sending LIN messages is currently not supported.
  • Page 40: Serial (Rs232)

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 40 von 71 User Guide 10.3 Serial (RS232) Channels 6x RS232 Data bits 5, 6, 7, 8 Stop bits 1, 2, 1.5 Parity None, odd, even Table 10.3: Serial interface The blue PiraT2 supports only the RS232 specification. 10.3.1 Segmentation of the serial data The received serial data are clustered into data blocks separately for each channel.
  • Page 41: Ethernet

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 41 von 71 User Guide 10.5 Ethernet All versions of the blue PiraT2 data logger are able to log Ethernet data. All data loggers have a 1-Gbit-Ethernet port with RJ45 connector on the front. On the rear side there is a FCI connector which provides four 100 Mbit Ethernet interfaces.
  • Page 42: Tcpserver

    10.5.6 SpyMode By using the Ethernet Spy mode it is possible to log all Ethernet data (promiscuous mode). More information can be found in the Telemotive System Client User Guide. 10.5.7 EsoTrace By using the EsoTrace mode it is possible to log data in the EsoTrace protocol.
  • Page 43: Most25

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 43 von 71 User Guide 10.6 MOST25 The blue PiraT2 MOST25 data logger is able to log messages from the MOST25 bus of the following types. Status MPR (Maximum Position Register), SBC, Light on, MOST Lock Flag Control Control Messages Packet...
  • Page 44: Ecl

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 44 von 71 User Guide The data logger is not an active part of the bus system because it is working in a spy mode. The device is able to log messages immediately after wake up. Before the logging data are saved on the internal memory, they are buffered in a ring buffer.
  • Page 45: Conversion Of Recorded Traces

    User Guide Conversion of recorded traces All trace data will be recorded internally in the proprietary Telemotive TMT format (*.tmt). If the recorded trace data will be downloaded and sorted, the data will be converted to an Extended TMT format (*.xtmt).
  • Page 46: Service And Safety Instructions

    It may only be used the original Telemotive components. Other components such as special cable sets have to be prepared strictly according to the pin assignment in the user guide. You should always spare an extra fuse in the wiring harness.
  • Page 47 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 47 von 71 User Guide Three pins with the names clamp 30 and clamp 31 are interconnected for the voltage supply of the data logger. Caution: A short circuit between the clamp 30 and clamp 31 on the plug may lead to the destruction of the data logger.
  • Page 48: Data Sheet

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 48 von 71 User Guide Data sheet General data blue PiraT2 blue PiraT2 5E Nominal power supply volta- 13.8 V 13.8 V Power supply voltage 6.5 to 32 V (at system start up logger needs > 5 to 32 V (at system start up logger needs >...
  • Page 49 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 49 von 71 User Guide Connectors blue PiraT2 blue PiraT2 5E Connectors Gbit Ethernet, Wi-Fi 802.11 b/g/n (optional), like blue PiraT2 GPS (optional), CF-Flash, USB 2.0 type A (front) + USB 2.0 type B BP2 150M14C8LFR Power supply, like blue PiraT2...
  • Page 50 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 50 von 71 User Guide CAN recording blue PiraT2 blue PiraT2 5E All types Channel BP2 150M14C8LFR: like blue PiraT2 12 High Speed, 2 Low Speed BP2 25M24C8LFR: 22 High Speed, 2 Low Speed Baud rate Up to 1000000 Baud at HS-CAN like blue PiraT2...
  • Page 51 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 51 von 71 User Guide Analog recording blue PiraT2 blue PiraT2 5E (#1 and #2) All types Channel 1x Ubat (internal), 1x external like blue PiraT2 Range of measurement 0 V to + 20 V like blue PiraT2 Resolution 7 mV...
  • Page 52: Pin Assignments And Harnesses

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 52 von 71 User Guide Pin assignments and harnesses blue PiraT2 blue Pirat2 5E Cable Interfaces Power, GND, Wake 12x High Speed CAN blue PiraT2 / blue PiraT2 5E 2x Low Speed CAN universal harness ...
  • Page 53 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 53 von 71 User Guide Warning: Clamp 31 should be the only ground connection between the data logger and connected devices. Connecting signal ground lines is limited to special cases in which one can guarantee that ground loops cannot occur.
  • Page 54: Data Logger: Multi Function Connector

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 54 von 71 User Guide 14.1 Data logger: Multi function connector Name Type Manufacturer-Nr. Manufacturer ELO 54pin Shield 1-1355928-2 Tyco Housing 1355929-2 Tyco Housing 1355930-2 Tyco Contakt 2-1411550-1 Tyco Table 14.2: MQS 54pin 14.1.1 Pin assignment of the blue PiraT2 multi-function connector @ Logger...
  • Page 55 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 55 von 71 User Guide KL 30 Please combine pins 35, 37, 39 for the KL 30 banana plug ---- HSCAN_L_12 High Speed CAN #12 LOW DSUB-9 / male KL 30 Please combine pins 35, 37, 39 for the KL 30 banana plug ----...
  • Page 56: Pin Assignment Of The Blue Pirat2 5E Multi-Function Connector

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 56 von 71 User Guide 14.1.2 Pin assignment of the blue PiraT2 5E multi-function connector @ Logger @ Vehicle Interface comment / depiction / signal name Signal Type 54pin KL15_Wake Wakeup from KL 15 banana plug blue ----...
  • Page 57 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 57 von 71 User Guide LSCAN_H_2 Low Speed CAN #14 HIGH DSUB-9 / male LIN_CON_4 LIN #04 DSUB-9 / male LIN_CON_5 LIN #05 DSUB-9 / male LIN_CON_6 LIN #06 DSUB-9 / male LSCAN_L_RC CAN RemoteControl LUMBERG KV81-8...
  • Page 58: Blue Pirat2 5E - Power Harness

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 58 von 71 User Guide 14.2 blue PiraT2 5E – power harness Name Type Manufacturer-Nr. Manufacturer SUB-D 3pol male Connector 303W3CSXX43A10X CONEC Housing 10070163-01LF Table 14.5: blue PiraT2 5E – power harness @ Logger @ Vehicle Interface comment / depiction / signal name...
  • Page 59: Serial Connector (D-Sub 26)

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 59 von 71 User Guide 14.3 Serial connector (D-Sub 26) The 26-pin-D-Sub-connector combines RS232 digital and analog interfaces. Name Type Manufacturer-Nr. Manufacturer DSUB 26pin Connector HD 26F (Reichelt) Shell 1-1478762-5 Tyco Table 14.7: D-Sub 26pin @ Logger @ Vehicle Interface...
  • Page 60: Analog/Digital Connector (26-Pin) (Not At 14C6S8L)

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 60 von 71 User Guide 14.4 Analog/Digital connector (26-pin) (not at 14C6S8L) Name Type Manufacturer-Nr. Manufacturer Ribbon 26pin Plug Connector 10126-3000PE Shell 10326-52F0-008 Table 14.9: Mini D Ribbon 3M 26pin @ Logger @ Vehicle Interface comment / depiction / signal name Signal...
  • Page 61: Ethernet Connector

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 61 von 71 User Guide 14.5 Ethernet connector Name Type Manufacturer-Nr. Manufacturer Cable Assembly 10054999-R0050Aulf Table 14.11: FCI-Connector (Cable assembly 50 cm) @ Logger @ Vehicle Interface comment / depiction / signal name Signal Type 26pin...
  • Page 62: Flexray Connector

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 62 von 71 User Guide 14.6 FlexRay connector Name Type Manufacturer-Nr. Manufacturer Ribbon 14pin Plug Connector 10114-3000PE Shell 10314-52F0-008 Table 14.13: Mini D Ribbon 3M 14pin @ Logger @ Vehicle Interface comment / depiction / signal name Signal Type...
  • Page 63: Can/Flexray (D-Sub 44) (25M24C8Lfr Only)

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 63 von 71 User Guide 14.7 CAN/FlexRay (D-Sub 44) (25M24C8LFR only) Name Type Manufacturer-Nr. Manufacturer DSUB 44pin Connector 17EHD-044-P-AA-0-00 Amphenol Shell 17E-1726-2 Amphenol Table 14.15: D-SUB 44pin @ Logger @ Vehicle Interface comment / depiction / signal name D-SUB Signal...
  • Page 64 blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 64 von 71 User Guide Not connected ---------------------- ---- Not connected ---------------------- ---- Not connected ---------------------- ---- Not connected ---------------------- ---- Not connected ---------------------- ---- Table 14.16: Pin assignment of the CAN/FlexRay connector Index blue_PiraT2_UserManual_V2.4.1.doc...
  • Page 65: Connection To Remote Control Voice

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 65 von 71 User Guide 14.7.1 Connection to Remote Control Voice Connector KV81-8 for Remote Control / Remote Control Voice is connected to Pins 40, 41, 50, 51 of MQS54. Clamp 30 and clamp 31 are directly connected to the cable harness. @ Logger comment / depiction / @ Vehicle Interface...
  • Page 66: Contacts Of The Remote Control Voice Cable

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 66 von 71 User Guide 14.7.2 Contacts of the Remote Control Voice cable These two drawings show the pinout of the Remote Control Voice cable. Figure 14.4: Pins des DIN-Steckers DIN-Steckers (Lumberg SV81-8 DIN8) Figure 14.5: Pins des gewinkelten LEMO-Steckers (FGH.1B.308.CLAD42) 14.8 Pinning of the FCI connector for the Ethernet-Kit RJ45-Jack...
  • Page 67: Abbreviations

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 67 von 71 User Guide Abbreviations Kürzel / abbreviation Bedeutung / meaning blue PiraT Processing Information Recording Analyzing Tool blue PiraT blue PiraT2 bP2 5E blue PiraT2 5E bPMini blue PiraT Mini RC Touch Remote Control Touch bP Remote...
  • Page 68 SFTP Secure File Transfer Protocol Secure Hash Secure Sockets Layer TCP/IP Transmission Control Protocol/Internet Protocol Transport Layer Security Telemotive Packetformat Telemotive System Link User Datagram Protocol Universal Serial Bus Universal Time, Coordinated Wi-Fi Wireless Fidelity WLAN Wireless Local Area Network Universal Measurement and Calibration Protocol Table 15.1: Abbreviations...
  • Page 69: List Of Figures

    Figure 7.2: Power connection of the blue PiraT2 5E ..............21 Figure 7.3: Switching on ......................21 Figure 7.4: Info screen IP address .................... 22 Figure 7.5: Telemotive Client Portal..................23 Figure 7.6: Desktop icon ......................24 Figure 7.7: links to the manuals ....................24 Figure 7.8: Rear side of the blue PiraT2 with MOST150 ............
  • Page 70: List Of Tables

    blue PiraT2 / 5E / 5E Datum: 21.09.2016 Seite 70 von 71 User Guide List of tables Table 4.1: Additional features by optional licenses ..............9 Table 5.1: Model versions of blue PiraT2 / blue PiraT2 5E ............11 Table 6.1: LED behavior ......................14 Table 6.2: Interface abbreviations and status information ............
  • Page 71: Contact

    PiraT2 / 5E / 5E Datum: 21.09.2016 User Guide Seite 71 von 71 Contact Telemotive AG Office München Frankfurter Ring 115a 80807 München Tel.: +49 89 357186-0 Fax.: +49 89 357186-520 E-Mail: info@telemotive.de Web: www.telemotive.de Sales Tel.: +49 89 357186-550 Fax.:...
