Summary of Contents for Scale Weighing Systems SWS-PCS-60

  • Page 1 SWS-PCS Series Retail Scale User Manual...

  • Page 2: Table Of Contents

    V1.0 Contents Subject to Change without Notice CONTENT 1.Specification....................2 2.Display Panel & Outline................3 3.Keys function..................4 4.Operation....................5 5.LCD contrast and Back-Light mode setting.........7 6.Auto-off time setting................8 7.Display A/D inner code and working voltage........8 8.The details about RS232 communication..........8 9. Date and time setting：...............10 10.Business name setting...............10 11.Key function in the trade name or business name setting mode...10 12.The meaning of the special displayed character......11...

  • Page 3: Specification

    SWS-PCS Retail Scale Instruction Manual SWS-PCS Thank you for purchasing Model Retail Scale. Please read all operating instructions carefully before using and note the following points:  Avoid using in extreme heat, cold or wet and the environment which has intensive change in temperature, humidity and pressure.

  • Page 4: Display Panel & Outline

    Platter size: W x D: 295mm x 225mm, 11.61” x 8.86” 2.Display Panel & Outline 2.1 Bottom view of scale： AC adapter socket Battery compatment calibration switch reset Bottom view of scale cymbiform switch when you were to use the scale and AC adaptor to power to charge the battery ,you need turn on this switch and then the AC lamp will be on...

  • Page 5: Keys Function

    2.4 Symbol Meaning: 2.4.1 WEIGHT: Weight display 2.4.2 UNIT PRICE: Unit price display 2.4.3 TOTAL PRICE: Total price display 2.4.4 ZERO: Zero indicator 2.4.5 TARE: Tare indicator 2.4.6 KG/LB/OZ: Weight unit indicator, maybe only one or two units. 2.4.7 SAVE: Unit price fixing indicator 2.4.8 $/KG、$/LB、$/oz: Unit price per kg/lb/oz indicator, maybe only one or two units.

  • Page 6: Operation

    4. O peration After electrify it will enter this mode, then weighing, price counting, and input/store the unit price. 4.1.Turn the power on and off： 4.1.1 When the scale is off, press ON/OFF/EXIT key to power on the scale ，The self-examination will run and the scale will give the zero reading.
  • Page 7 4.6.2.2 Print out format when OS-203/213 printer is connected (example): Label dimension is 58mm × 40mm Label dimension is 58mm × 60mm 4.6.2.3 Content of printed out: 4.7.Input the unit price directly： Use numerical key to enter unit price(range: 0000.00～9999.99), the data can be removed by CLEAR key, or confirmed by ENTER key within 3s.

  • Page 8: Lcd Contrast And Back-Light Mode Setting

    when 232.out is set to PRTd60), the unit price window shows the last six char of the ingredients. 4.10.6 Use numerical keys and CLEAR key to input the ingredients (the length of the ingredients is 80 char), use ENTER key to confirm the char on flashed position or confirm the ingredients, or use ON/OFF/EXIT key to exit this mode and return back to the normal weighing mode.

  • Page 9: Auto-Off Time Setting

    6.Auto-off time setting Under the normal weighing mode, press and hold ON/OFF/EXIT and 2 key at the same time until the scale displays “Setup” in weighing unit window, “A.OFF.t” (auto off time) in unit price window and auto-off time xx（xx=00～30,when 00 is used that means no auto off function） in total price window. Use numerical keys to input the auto-off time and press ENTER key for confirmation.
  • Page 10 xxx. Use 1、2、3 key to select data format: 1—8N1 8 bits data, no odd or even , 1 start bit, 1stop bit 2—7O1 7 bits data, 1 even , 1 start bit, 1stop bit 3—7E1 7 bits data, 1 odd, 1 start bit, 1stop bit, Press Enter key to confirm the input and go to the next step, or use ON/OFF/EXIT key to exit this mode.

  • Page 11: Date And Time Setting

    8.8 Then, the unit price window shows “URT.cFt” (communication format), the total price window shows communication format xxx. Use the numerical keys 0, 2 to select the communication format: 0—Non communication 2—When the scale becomes stable, the data will be output after pressing PRINT key, the format when “232.out”...

  • Page 12: Business Name Setting

    9.1. Under the normal working mode, press and hold 5 and ON/OFF/EXIT key for more than 3s to enter into this mode. In this mode, you can set the system date and time. （Note: the date and time in scale will be lost after the scale power off if no RTC module is installed）...

  • Page 13: Id Setting

    À Â Æ Ç È É Ê Ë Î Ï Ô Ù Û Ü 13.ID setting 1. Under the normal working mode, press and hold 6 and ON/OFF key for more than 3s to enter this mode. In this mode, you can set ID code. （Note: the data will be lost after the scale reset） 2.

  • Page 14: Printer Origin Setting

    label.）, use 0 to select “DISABLE”，use ENTER key to confirm and exit this mode. 15. Printer Origin setting 15.1 Under the normal working mode, press and hold 8 and ON/OFF key for more than 3s to enter this mode. In this mode, you can set the origin point.
  • Page 15 16.4Press “Open” or “open file” button in “File” menu，it will first remind you whether to save the current file, and then open the file and dialogue box to choose and open the right file.
  • Page 17 16.5 Choosing “Down Load” in “Serial” menu ， the scale will display “DNLOAD”, the status bar will display the present download information, if it displays “downloading business name”, it means it’s downloading the store name. If it displays “Downloading Mxx”, it means it’s downloading the information of M1~M9 (direct unit price). If it displays “Downloading No.
  • Page 18 16.7Date and Time setting Choose ”Pair” in “Serial” menu to open the date and time setting dialogue box, it will display the system clock of PC, press “Confirm” or exit the dialogue box directly. After the software send date and time setting data to the scale, it will display “Pair successful.”.

  • Page 19: Lcd Test Mode

    1 7 .LCD test mode 18.1 Long press the key, until all segments of LCD are displayed ON/OFF+PRINT 18.2 (a) Press --- all segments are shown; 0 key (b) Press --- different segments will be shown; 1 key (c) Press --- segments on different COMs will be shown;...
  • Page 20 Err01 The weight exceed 9d of the max Remove the object; Or capacity; or the load cell output change the load cell; signal is too strong Calibrate the PCB with 0 regulation-resistance Err31；Err30 The load cell signal is too small or Calibrate the PCB with 0 too big.

  • Page 21: The Meaning Of Some Displayed Symbols

    19 .The meaning of some displayed symbols 20.1 Err01： Weight signal is too large 20.2 Err02： No proper data can be displayed 20.3 Err03： Weight signal is too small 20.4 Err04： Zero point is over the setting range 20.5 Err05： Zero point is below the setting range 20.6 Err06 : Error in unit key operation...

  • Page 22: Warranty

    Limited Warranty Statement (2) Year Warranty Scale Weighing Systems, (SWS), warrants it’s products against defects in materials or workmanship for a period of two years from the date of original purchase. During the specified warranty period, replacement and/ or repair of the product will be made at the discretion of SWS and it’s authorities based on this warranty.
  • Page 23 Neither Scale Weighing Systems or any of it’s third party suppliers make any other warranty of any kind, whether expressed or implied, with respect to SWS products. This warranty is exclusive and in lieu of all other express warranties and unless stated herein, any statements or representations made by other persons or firm are void.
