ZIYA 11
This sleek 6W recessed up light features an eye-catching stainless steel trim, ideal for up lighting pergolas, pathways and features
on a villa or building (Also available in RGB).
PRODUCT FEATURES
Trim Material
Trim Finish
Glass
Fixture Material
Optic
Sleeve Material
Static Load Pressure
Binning
Wiring
Life Span
POLAR DISTRIBUTION CURVE
www.globallightllc.com
Grade 308 Stainless Steel
Stainless Steel
High intensity Tempered Glass
Die-cast Aluminum
Acrylic Optical lens
Aluminium Alloy
800kg
Single binning for optimal color
consistency
90 Centimeter of 4 core
0.75mm
rubber cable
2
40,000 hours
info@globallightllc.com
PRODUCT SPECIFICATIONS
LED Chip
Number of LEDS
Power Consumption
Input Voltage
Available Beam Angles
Operating Temperature
Total Lumen Output
Available Color
Temperatures
Color Rendering Index
IP Rating
Warranty
Agency Approval
Total Weight
ILLUMINANCE CONE
Tel: +971 4 340 44 58
6W RECESSED UP LIGHT
CREE
3
6W
24V DC
220~240V AC, 50/60Hz
(Single color available on
request)
5°, 12.5°, 20°, 30°, 45°
from -20°C to 65° C
Warm White: 570
Day Light: 600
Cool White:660
2700K, 3000K, 4000K, 6000K, RGB
>80
67
3 years against manufacturing
defects
CE, RoHS
1000g
Fax: +971 4 341 10 90
