ONERALARM PT01 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Updated on 1/8/2009
GPS
Tracker
USER MANUAL
V5.0
PT01
ONERALARM GPS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT01 and is the answer not in the manual?

Questions and answers

Summary of Contents for ONERALARM PT01

  • Page 1 ONERALARM GPS Tracker USER MANUAL V5.0 PT01 Updated on 1/8/2009...

  • Page 2: Table Of Contents

    5.1.2 Set Interval for automatic timed report 5.1.3 Stop automatic timed report 5.1.4 SOS/Call B/Call C 5.2 GPRS Setting by SMS 5.2.1 Set ID for PT01 5.2.2 Set APN 5.2.3 Set IP Address and Port 5.2.4 Set Time Interval for Sending GPRS Packet 5.2.5 Enable GPRS Tracking Function...

  • Page 3: Product Overview

    Read these simple guidelines. Not following them may be dangerous or illegal. Read the full user manual for more information. Switch on Safely - Do not switch on PT01 when wireless phone use is prohibited or when it may cause interference or danger.

  • Page 4: Getting Started

    - User Manual - Other document or software if required 4.2 Light and Button Functionality Your PT01 has four buttons and three LED lights with three different colors to indicate the status of the unit. Red LED - indicating power status Power is off or charging is complete Flashing (every 0.1 second)

  • Page 5: First Use

    GPS when you turn on the device. Check that the Red LED (power) on PT01 is flashing (on for 1 second and off for 2 seconds). Check that the Green LED (GSM) is flashing (on for 0.1 second and off for 2.9 seconds).

  • Page 6: Basic Sms Commands

    5.1 Basic SMS Commands 5.1.1 Return the location of the tracker Description: To know the location of your PT01, send an SMS or make a telephone call directly to PT01 and it will report its location by SMS. Command: W<password>,<000>...

  • Page 7: Gprs Setting By Sms

    SMS sent: W000000,003,3,1,123456789 SMS received: Set Tel Ok/3,1,123456789 Meaning: When the SOS button is pressed, PT01 will send an SMS to telephone number “123456789” and also make a phone call to it. When a call is coming in, the green light is on. Press SOS button to receive the incoming call and then talk with the caller by earphone.

  • Page 8: Set Time Interval For Sending Gprs Packet

    X=1, to set TCP X=2, to set UDP Example: W000000,013,1 PT01 will reply with an SMS to confirm this setting. For more information regarding of bulk configuration by USB cable please refer to < GPS Tracker Parameter Editor>. For more information regarding GPRS settings please refer to <GPRS Communication Protocol >.

  • Page 9: Sms Command List

    Tall buildings, trees, heavy rain, can cause problems with the GPS reception. Bad GPS reception Place the front side of PT01 towards sky Battery is low Recharge the unit and the GPS will start working. If any other problem occurs, please contact our salesperson or engineer.
  • Page 10 Set low power alert W******,004,X X (voltage preset value) =0 , to turn off this function When PT01 voltage is lower =1, <3.3V send SMS alert than the preset value, it will =2 , <3.4V send SMS alert send one low power alert to =3 , <3.5V send SMS alert (default )
  • Page 11 ONERALARM GPS Set sleep mode W******,021,XX### XX=00 turn off sleep mode for saving power XX=01 sleep mode XX=02 deep sleep mode ### is the ending character phone number W******,030,T telephone number wiretapping wiretapping and max. 16 digits Set time zone difference...
