Cooper Bussmann 915U-2 User Manual

Wireless mesh i/o and gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cooper Bussmann
Read and
Retain for
915U-2 Wireless Mesh I/O and Gateway
Future

User Manual

Reference
Version 1.2.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 915U-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cooper Bussmann 915U-2

  • Page 1: User Manual

    Cooper Bussmann Read and Retain for 915U-2 Wireless Mesh I/O and Gateway Future User Manual Reference Version 1.2.2...

  • Page 2: Safety Notice

    Incorrect termination of supply wires may cause internal damage and will void the warranty. To ensure that your 915U-2 Wireless Mesh I/O and Gateway enjoys a long life, check this user manual to verify that all connections are terminated correctly before turning on power for the first time.

  • Page 3: Fcc Notice

    • This device must accept any interference received, including interference that may cause undesired operation. The 915U-2 module must be installed in a suitable enclosure that provides mechanical, shock, and fire hazard protection. This device must be operated as supplied by ELPRO. Any changes or modifications made to the device without the written consent of ELPRO may void the user’s authority to operate the device.

  • Page 4: Important Notice

    Systems should be designed to be tolerant of these operational delays. To avoid the risk of electrocution, the aerial, aerial cable, serial cables and all terminals of the 915U-2 module should be electrically protected. To provide maximum surge and lightning protection, the module should be...
  • Page 5 Before deploying a system, make sure that you have carefully considered the security aspects of your installation. Release Notice This is the December 2013 release of the 915U-2 Wireless Mesh I/O and Gateway User Manual version 1.2.2, which applies to version 1.2.2 firmware. Follow Instructions Read this entire manual and all other publications pertaining to the work to be performed before installing, operating, or servicing this equipment.

  • Page 6: Table Of Contents

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual CONTENTS Chapter 1 - INTRODUCTION ....8 Dual Band Operation ..... . 29 1.1 Overview .
  • Page 7 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Radio Settings ......69 Mesh Fixed Routes .

  • Page 8: Chapter 1 - Introduction

    A system can be a complex network or a simple pair of modules. An easy-to-use configuration procedure allows you to specify any output destination for each input. Each 915U-2 radio can have up to 24 expansion I/O modules (ELPRO 115S) connected by RS-485 twisted pair cable. Any input signal at any module may be configured to www.cooperbussmann.com/wirelessresources...

  • Page 9: Module Structure

    1.2 Module Structure The 915U-2 module is made up of different areas that all interface with a central input and output storage area (I/O store). The I/O store is an area of memory made available for the status of the physical on-board I/O and internal I/O registers.

  • Page 10: Getting Started

    The expansion port, allows 115S expansion I/O modules to be added to the module. Expansion I/O is dynamically added to the internal I/O of the 915U-2 module by adding an offset to the address. 1.3 Getting Started Most applications for the 915U-2 module require little configuration. The 915U-2 has many sophisticated features, but if you do not require these features you can use this section to configure the units quickly.

  • Page 11: Chapter 2 - Installation

    2.1 General The 915U-2 Series modules are housed in a plastic enclosure with DIN rail mounting, providing options for up to 14 I/O points, and separate power and communications connectors. The enclosure measures 170 x 150 x 33 mm, including the connectors.

  • Page 12: Expansion I/O Supply

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual The power supply should be CSA Certified Class 2, approved for normal operation. If the device is being used in a Class I Div 2 explosive area, the supply must have Class I Div 2 approval.

  • Page 13: Internal I/O

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual As a guide, when using the I/O power connection from the 915U-2, the number of I/O modules is limited to three 115S-11 (using inputs), or one x 115S-12, or one x 115S-13. If more I/O modules are required, you need to calculate the overall current consumption using the following criteria, and power the modules from an external supply.

  • Page 14: Radio

    The radio operates in the 902–928 MHz ISM band, which is split into two frequency bands, 902–914 MHz (low) and 915–928 MHz (high). In the United States and Canada, the 915U-2 can use both high and low bands. However, in other countries, such as Australia, only the 915–928 MHz band is available.

  • Page 15: Meshing Capability

    See “3.4 WIBMesh” for configuration details. 2.4 Antenna The 915U-2 module operates reliably over large distances. The distance that can be reliably achieved varies with each application and depends on the type and location of antennas, the degree of radio interference, and obstructions to the radio path (such as hills or trees).

  • Page 16: Dipole And Collinear Antennas

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual An antenna should be connected to the module via 50-ohm coaxial cable (such as RG58, RG213, or Cellfoil), and terminated with a male SMA coaxial connector. The higher the antenna is mounted, the greater the transmission range.

  • Page 17: Yagi Antennas

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 7 Collinear Antenna Mounting Yagi Antennas Yagi antennas provide high gain in the forward direction, but lower gain in other directions. They may be used to compensate for coaxial cable loss for installations with marginal radio path. The Yagi gain also acts on the receiver, so that adding Yagi antennas at both ends of a link provides a double improvement.

  • Page 18: Connections

    Figure 9 Bottom Panel Connections Ethernet Port The 915U-2 modules provides a standard RJ-45 Ethernet port compliant to IEEE 802.3 10/100BaseT. This port provides full access to the module, including configuration, diagnostics, log file download, and firmware upload of both the local and remote units. Additionally, the Ethernet port can provide network connectivity for locally connected third-party devices with Ethernet functionality.

  • Page 19: Port

    RS-232 Port The 915U-2 module provides an RS-232 serial port that supports operation at data rates up to 230,400 baud. This port supports Modbus protocol. The RS-232 port is provided by an RJ-45 connector wired as a DCE according to the EIA-562 Electrical Standard.

  • Page 20: Side Access Configuration Panel

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Side Access Configuration Panel A small access panel on the side of the module hides a factory boot switch, USB host port, and a small bank of DIP switches that are used for analog input voltage and current selection, external boot, and default configuration settings.

  • Page 21: Front Panel Connections

    Digital or Pulsed Inputs Each digital I/O channel on the 915U-2 module can act as either an input or an output. The input/output direction is automatically determined by the connections and configuration of the I/O. If you have an I/O channel wired as an input but operate the channel as an output, no electrical damage will occur but the I/O system will not operate correctly.

  • Page 22: Digital Outputs (Pulsed Outputs)

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 13 Digital/Pulsed Input Wiring Digital inputs 1–4 can be used as pulsed inputs. The maximum pulse frequency is 50 kHz for input 1 and 2, and 1 kHz for input 3 and 4. Digital/pulsed inputs are suitable for TTL signal level, NPN-transistor switch devices, or voltage-free contacts (a relay or switch with debounce capacitor).

  • Page 23: Digital Output Fail-Safe Status

    Figure 14. A bypass diode (IN4004) is recommended to protect against switching surges for inductive loads such as relay coils. The digital channels D1–4 on the 915U-2 module can be used as pulse outputs with a maximum output frequency of 10 kHz.

  • Page 24: Differential Current Inputs

    Common mode voltage can be up to 27 Vdc. Figure 17 indicates how to connect loop-powered or externally powered devices to the 915U-2 differential analog inputs. It should also be noted that the differential inputs can also be used to connect single-ended current sinking or current sourcing devices.
  • Page 25 Figure 18 AI 1 & 2 Single-ended Current Inputs Single-ended current input mode is useful if the sensor loop is grounded to the 915U-2 module. Devices can be powered from the 24V analog loop supply (ALS) generated internally from the module.

  • Page 26: Voltage Inputs

    Figure 20 Voltage Inputs Analog Outputs The 915U-2 module provides two 0–24 mA DC analog outputs for connecting to analog inputs on equipment (such as PLCs, DCS, and loggers) or connecting to instrument indicators for displaying remote analog measurements. The 915U-2 analog outputs are a sourcing output and should be connected from the analog output terminal through the device or indicator to ground (GND).

  • Page 27: Chapter 3 - Operation

    3.1 Overview The 915U-2 Series I/O modules are designed to provide standard off-the-shelf telemetry functions at an economic price. Telemetry is the transmission of data or signals over a long distance via radio or twisted-pair wire cable. 3.2 LED Indicators When the module is initially connected to power, it performs internal setup and diagnostics checks to determine if it is operating correctly.

  • Page 28: Input And Output Indicators

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Input and Output Indicators LED Indicator Condition Meaning D 1–8 Orange Digital input is on D 1–8 Flashing Orange - (Long On) Update failure (fail-safe state is on) D 1–8...

  • Page 29: System Design

    (see “Radio Settings” on page 69). In countries that utilize the full 902–928 MHz bandwidth (such as the United States and Canada) the 915U-2 uses both sub-bands, which makes it possible to force the frequency hopping to the other band (high or low) to avoid radio interference and to separate systems.

  • Page 30: Design For Failures

    (for example, a tower, or mast). Repeater modules can have their own I/O and act as a normal 915U-2 module within the system.

  • Page 31: Wibnet Communication Registers

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual WIBNet Communication Registers The WIBNet radio has a number of registers available to indicate a communication failure with a particular remote address. General purpose digital registers 10501–10595 indicate a communication fail for the corresponding remote radio address.

  • Page 32: Chapter 4 - Configuration

    Figure 24 DIP Switch #6 in On Position b. Power cycle the module. When the 915U-2 is powered on with DIP switch #6 set to “on,” the module goes into Setup mode and temporarily loads its factory-default settings. In Setup mode, wireless operation is disabled. The previous configuration remains stored in non-volatile memory and will only change if a configuration parameter is modified and the change is saved.
  • Page 33 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 25 Local Area Connection Properties 6. On the General tab, enter IP address 192.168.0.1 and subnet mask 255.255.255.0, and then click OK. Figure 26 TCP/IP Properties 7. Verify the Ethernet connection to the module by using the “ping” command: c.

  • Page 34: Mconfig Utility

    1. Go to the Cooper Bussmann website: http://www.cooperindustries.com/content/public/en/bussmann/wireless/ resources 2. Under Resources, click Technical Resources Library, and then click ELPRO Configuration Software. 3. Download the zip file “915U-2 Wireless Mesh I/0 and Gateway Configuration” to your PC and extract the zip file. 4. Open the file “INST_CFG_MCconfig<version>.exe.”...

  • Page 35: Starting Mconfig

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 28 Installation Wizard Starting MConfig Follow these steps to start the MConfig Utility. 1. From the Windows Start menu, choose Programs-->Meshing Config Utility-->Meshing Config Utility. The Project Selection screen appears.

  • Page 36: Project Screen

    The Project screen is displayed when you open or create a project. The project tree on the left shows the project name, followed by any 915U-2 module units that have been added to the project (the project tree is empty when you start a new project).

  • Page 37: Adding Units To A Project

    Adding Units to a Project Click Units in the project tree to add a new 915U-2 configuration to the project or import (load) an existing 915U-2 configuration to the project. The new or imported 915U-2 will appear in the project tree. A configuration can be imported by directly connecting to a 915U-2 module over Ethernet or USB, or by selecting a pre-saved configuration file from a 915U-2 module.
  • Page 38 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Once a 915U-2 module is added to the project, selecting the module in the project tree displays the Unit Details screen where you can enter or change information about the module.
  • Page 39 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Program Unit Displays the Program Unit screen (see Figure 33) where you can choose the method to be used to configure the module: • Ethernet (Local)— Program the module using the local Ethernet interface displayed in the list.

  • Page 40: Displaying The Ip Address List

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 34 Load Unit Figure 35 IO Diagnostics Displaying the IP Address List Click IP Address List in the project tree to display the module name and corresponding radio and Ethernet IP address, subnet mask, and network address for each module in the project.

  • Page 41: Editing Module Ip Addresses

    Units screen (see “Adding Units to a Project” on page 37). New modules are assigned a radio address based from this default. The radio IP address can also be manually edited by clicking the 915U-2 module in the project tree, and then clicking Edit (see Figure 32).

  • Page 42: Mappings

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Mappings Mappings are used to send I/O values between 915U-2 modules. The I/O value is typically sent via the radio interface, but at times it can be sent via the Ethernet interface between modules. To display the current mappings for a module, open the module in the project tree and click Mappings (see Figure 38).

  • Page 43: Adding Or Editing Mapping Parameters

    • Ethernet IP Address—When Ethernet IP address is selected, the mapping will be sent to the Ethernet address port of the 915U-2. Click the Ethernet option in the project tree and ensure that the Ethernet port is enabled for the sending and receiving 915U-2 modules.
  • Page 44 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual IO Table Allows you to map each I/O to an output. 1. Click the Local Name field to see a drop-down list of all available I/O, or click the Local Address field to view a tabbed I/O selection screen that will allow you to select an I/O point (input) that you want to map.

  • Page 45: Startup Or Force Configuration

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Change of State Allows you to set the time period during which the message is delayed from Delay being sent. The purpose is to reduce the amount of radio traffic by holding off the transmission to allow more I/O COS to the mapping.

  • Page 46: Address Map

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Example In the example shown in Figure 40, site A needs to be configured so that on power-up it writes to a register at Site B. Site B then uses this register to trigger an update of any mappings it has that communicate back to Site A.

  • Page 47: Common I/O Registers For The 915U-2

    Common I/O Registers for the 915U-2 The following table shows the basic on-board I/O registers available in a standard 915U-2 module with no expansion I/O connected to it. For a detailed I/O map showing the full register range, see Appendix B.

  • Page 48: Digital Outputs

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 42 I/O Edit (Digital Inputs) The following parameters can be configured for 915U-2 digital inputs. Name Enter a name for the digital input or leave the default name. The name can be up to 30 characters, including spaces.

  • Page 49: Pulsed Outputs

    Analog inputs have more configurable options because each input also has a set point assigned to it. Analog inputs can also be used as voltage inputs by selecting DIP switches on the 915U-2 modules (see “DIP Switches” on page 20).
  • Page 50 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 46 IO Edit (Analog Inputs) The following parameters can be configured for 915U-2 analog inputs. Name Enter a name for the analog input or leave the default name. The name can be up to 30 characters, including spaces.

  • Page 51: Analog Outputs

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Window Selecting this option sets the set point operation to Window mode. Deselecting this option sets the set point operation to default mode. • Window Mode—In this mode, if the analog value is inside the upper and lower set points, the set point will be active (on, “1”), and if the analog value is outside...

  • Page 52: Adding Expansion I/O Modules

    RS-485 serial port on the 915U-2 is configured by default to communicate using the Modbus protocol. The default serial parameters of the RS-485 port on the 915U-2 are 9600 baud, no parity, 8 data bits, 1 stop bit, which match the defaults of the 115S serial expansion modules.

  • Page 53: Adding An Expansion I/O To Mconfig

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual When adding expansion I/O modules to the 915U-2, there are two inbuilt registers indicating the communication status of the expansion I/O module: • Communication Fail—Located at register location 10019 + offset value. This register indicates “1”when the module is in failure.
  • Page 54 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 50 Fail-safe Block Analog In the example shown in Figure 51, digital outputs 1–8 will be initialized on startup (turned on) and then start the fail timeout countdown from 60 seconds after which time the outputs will be set to the fail value (off) unless the output is updated.

  • Page 55: Invalid Register State

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Invalid Register State All registers within the module can have different states, depending on the type of register and the type of value it holds. A typical analog range is between 0 and 65535, and a digital can be 0 or 1. Registers that are not associated with a physical I/O can also be in the “invalid”...

  • Page 56: Serial Configuration

    Select the number of counts the register needs to change before a COS trigger occurs. Serial Configuration The 915U-2 module has an RS-232 and an RS-485 port for serial communications. These ports are used to connect ELPRO 115S-11, 115S-12, and 115S-13 serial expansion I/O modules. The ports can also be used to connect external Modbus RTU master or slave devices.

  • Page 57: Modbus Rtu Master

    Modbus RTU Master from the Operating Mode drop down menu (see Figure 55). The Modbus RTU master should be configured if the 915U-2 is acting as a Modbus RTU master and polling Modbus slave devices via the selected serial port. It also allows Ethernet Modbus/TCP clients connected to the 915U-2 Ethernet port to communicate with Modbus RTU slave devices connected to the configured serial port.

  • Page 58: Serial Expansion I/O

    (such as an 115S-11, 115S-12, or 115S-13) to the RS-485 port of the 915U-2, the I/O is automatically available from within the I/O store of the 915U-2. See Appendix E for location addresses, or refer to the 115S Expansion I/O User Manual.

  • Page 59: Serial Modbus Rtu Slave

    Modbus TCP or RTU devices. The 915U-2 has predefined data areas for inputs and outputs and the different I/O types (bits, words, long, floats, and so on), which include the onboard input/outputs and are shared for both client and server. For a full list of the available I/O and address locations see Appendix B.

  • Page 60: Modbus Tcp Server And Rtu Slave Tab

    Modbus TCP Server & RTU Slave Tab Figure 59 Modbus TCP Server Allows the 915U-2 to accept connections from one or more Modbus TCP clients enabled via Ethernet or RTU masters via the RS-485 or RS-232 serial interfaces. All Modbus transactions routed to the on-board Modbus TCP server/RTU slave are directed to/ from the on-board general purpose I/O registers.

  • Page 61: Modbus Tcp Client And Rtu Master Tab

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Modbus TCP Client and RTU Master Tab Click this tab in the Modbus configuration screen to set the Modbus client scan rate, which is common to both the Modbus TCP client and Modbus RTU master (see Figure 60). The default rate is 1000 msec. Each mapping is configured with a response timeout, which is the period of time that the master will wait for a response before indicating the failure on the Comms Fail Register.

  • Page 62: Modbus Tcp Mapping Examples

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 61 Modbus TCP Client Mapping Local Register When the Function Code Modbus command is “Read” the Local Register field will (Master) be the destination register (output location) on the local device. When the Function Code command is “Write”...

  • Page 63: Modbus Rtu Master

    The third mapping (#3) is similar to the second mapping, but instead of reading from the local Ethernet subnet (LAN) it is reading from an IP address on the radio network (another 915U-2 module). The Function code is “Read” from IP address 192.168.10.101 and device ID #1.

  • Page 64: Rs-232/Rs-485 Modbus Parameters

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual The second mapping (#2) shows a read mapping from a serial device connected on the RS-485 port with a device ID of 5. It is reading 16 I/O points, starting at remote address 10001, and writing the value into the local address 501.

  • Page 65: Web-Based Configuration Utility

    4.3 Web-Based Configuration Utility The 915U-2 module provides an embedded Web-based management utility that resides in flash memory on the module’s CPU board. This utility allows you to manage wireless connection links between all 915U-2 modules in the ® ®...

  • Page 66: Mesh Parameters

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 66 Home Page Mesh Parameters Click Mesh on the menu to changes parameters that govern wireless communication between all modules in the system. Figure 67 Mesh Configuration Enable IP Gateway...

  • Page 67: Neighbor Rssi Configuration

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Enable Multipath This option should be enabled when the installation is in an environment that is known RSSI Algorithm to have multipath fading. This typically occurs when units are installed in buildings or environments where the antennas do not have uninterrupted line-of-sight paths, or when there are large metallic objects close to the antennas.

  • Page 68: Ip Routing

    Click IP Routing on the menu to change IP routing to other 915U-2 modules in other wired or wireless networks. When a 915U-2 module receives an IP frame that is destined for an IP address on a different network, it checks to see if the network address matches one of its own interfaces (hard-wired Ethernet, or radio) and forwards the frame appropriately.

  • Page 69: Radio Settings

    Save changes to non-volatile memory. The module needs to be restarted for the changes to take effect. Save Changes and Save settings to non-volatile memory, and reboot the 915U-2 module. Once the Reset module completes the reboot sequence, all changes are in effect.

  • Page 70: Mesh Fixed Routes

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Network Address Unique address used to differentiate one wireless system from another. All radios required to communicate within the system need to have the same network address. Messages received with a different network address will be ignored. This prevents cross-talk between systems.
  • Page 71 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 71 Mesh Fixed Routes Add Entry Click to add a new fixed routing rule. A new blank entry is added to the table. Enter the information for the new rule, and click Save and Activate Changes.
  • Page 72 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Example #1 Normally, a meshing network will learn the routing paths within the network and set up a communication pathway to the destination, but some instances require you to create a fixed radio path. The network diagram in Figure 72 shows a basic network where the remote sites (#2, #3, and #4) all need to communicate back to Site #1 using fixed route paths rather than automatically meshing and finding their own path.
  • Page 73 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 74 Mesh Fixed Route - Repeater Site #2 After configuring all remote sites, you can check the communications paths by clicking Network Diagnostics on the menu, entering in the destination address in the “Remote IP Address” field, and then clicking Trace Route.

  • Page 74: Module Information Webpage

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Module Information Webpage Click Module Information from the menu to change the following information for the module. With the exception of the password, the information entered here is displayed on the module’s home configuration webpage.

  • Page 75: Patch File Firmware Upgrade

    NOTE The Modbus feature key and configuration is not changed or erased during a full upgrade. The following procedure provides instructions for performing a full USB firmware upgrade on a 915U-2. Requirements • USB flash drive • Firmware files (contact ELPRO technical support for these files)
  • Page 76 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual To prepare the USB flash drive 1. Plug the USB flash drive in to the PC. Right-click the drive and select Format from the menu. Figure 80 Formating USB Flash Drive 2.
  • Page 77 3. Remove the cover from the small access panel on side of module to reveal a USB port and switches. Figure 84 Module USB Port and Switches 4. Plug USB stick into USB port and power on the 915U-2 module. 5. The PWR LED will flash, as indicated in Figure 85.

  • Page 78: Product Reconfiguration

    Figure 86 Product Reconfiguration Feature License Keys Feature license keys allow you to upgrade the 915U-2 module with enhanced features or to a more advanced model (for example, by enabling the Modbus option). The feature license keys can be purchased by contacting Cooper Bussmann or your local distributor.
  • Page 79 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 87 Feature Keys Demonstration Selecting this checkbox and clicking Save Changes and Reset temporarily enables all Mode feature license options for 16 hours (or until the unit is reset again). After the module resets, the message “Active”...

  • Page 80: Chapter 5 - Diagnostics

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual 5 - DIaGNOSTICS hapTEr This chapter describes network diagnostic tools and information available from the module’s Web-based configuration utility. To access this utility, see “Connecting and Logging On” on page 65.

  • Page 81: Watchdog Error Log

    • Register 30500 = Firmware patch level Expansion I/O Error Registers The 915U-2 has diagnostics registers allocated for each expansion I/O module. These registers indicate the module type, error counts, error codes, and so on. Each expansion I/O module has the following registers.

  • Page 82: Mesh Connectivity

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Dec Code Hex Code Name Meaning 0001 No Response No response from a poll 0002 Corrupt/invalid Corrupt or invalid data 0003 CRC Fail CRC error check does not match the message.

  • Page 83: Link Quality Indicator

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual RSSI RSSI (received signal strength indicator) measured in dBm. This is a negative value scaled from –40 dBm (good) to –120 dBm (bad). RSSI is displayed for the destination addresses that are direct neighbors. If the destination IP is not the next hop, you will see an RSSI value of “~”...

  • Page 84: Mesh Neighbor Rssi

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual 5.4 Mesh Neighbor RSSI Click Neighbor RSSI on the home page of the Web-based configuration utility to show the receive signal strength for each of the 50 available channels within the frequency band. To find out if the path between two neighboring units has a multipath fading issue, enter the radio IP address of the neighbor you want to view and click Get Graph.

  • Page 85: Mesh Network Diagnostics

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual link is established between two units, the connectivity webpage also shows the calculated RSSI value. 5.5 Mesh Network Diagnostics Click Network Diagnostics on the home page of the Web-based configuration utility to check the communications path to other modules within the system.

  • Page 86: Mesh Network Statistics

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 94 Network Diagnostics - Trace Route Each trace route message has the following components. 192.168.2.108 (192.168.2.108) 874 ms 1 = Hop number 192.168.2.108 = DNS name of the device (192.168.2.108) = IP address of the device...
  • Page 87 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Stats Period The sample period. Select one of the following options: • Live—This option displays the average transmit and receive data through put in kbps and the number of data packets seen on the radio interface (er0), displayed in packet per minute.

  • Page 88: Monitor Communications

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 99 Daily/Weekly Statistics 5.7 Monitor Communications Monitor WIBMesh Radio Communications Click Monitor Radio Comms on the home page of the Web-based configuration utility to view communication frames that are received or transmitted by the radio (Figure 100).

  • Page 89: Monitor Wibmesh Ip Comms

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual The following table describes two data frames from the communications log screen in Figure 100. Time TX/RX Frequency Signal Level Data Length Data 16:05:51.756 Tx : 911.875 1074 ] ( 74) 80 B1 34 86 02 9F 02 65 08 00 16:05:51.771...

  • Page 90: Monitor Wibnet Radio Comms

    Monitor WIBNet Radio Comms If you have reconfigured the 915U-2 to use the legacy WIBNet protocol, you can click Monitor Comms on the home page of the Web-based configuration utility to view the received and transmitted WIBNet data frames. For information on reconfiguring the 915U-2 for legacy WIBNet protocol, see “Product Reconfiguration”...

  • Page 91: Statistics For Wibmesh And Wibnet

    5.8 Statistics for WIBMesh and WIBNet For advanced debugging of 915U-2, click Statistics on the home page of the Web-based configuration utility. This webpage details the state of the 915U-2 and provides performance information. This information is useful to ELPRO technical support personnel in diagnosing problems with the module.

  • Page 92: Chapter 6 - Specifications

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual 6 - SpECIFICaTIONS hapTEr Specifications for the 915U-2 are provided in the following table. Specifications Radio Transceiver Frequency 902–928 MHz ; 869.525 MHz; 869.875 MHz Transmit power 1 mW (+0 dBm) to 1W (+30 dBm)

  • Page 93: Specifications

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Specifications Protocols and Configuration System Address ESSID; 1–31 Character Text String Protocols Supported TCP/IP, UDP, HTTP, FTP, TFTP, Telnet, Modbus RTU Master/Slave, Modbus-TCP Client/Server User Configuration All User Configurable Parameters via HTTPS Configurable Parameters Unit details, I/O mappings and parameters, radio settings.

  • Page 94: Appendix A - Dbm To Mw Conversion

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual a - DBM TO MW CONVErSION ppENDIx Watts Watts 10 mW 10 dBm 200 mW 23 dBm 13 mW 11 dBm 316 mW 25 dBm 16 mW 12 dBm 398 mW...

  • Page 95: Appendix B - I/O Store Registers

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual B - I/O STOrE rEGISTErS ppENDIx Output Coils Output Coils Description 0001 Local DIO1–DIO8 as digital outputs 0008 0009 Spare 0020 0021 Space for locally attached 115s expansion I/O modules. Twenty register per module address, maximum number of modules is 24.

  • Page 96: Holding Registers

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Input Registers Description 30021 Space for locally attached 115s expansion I/O modules. Twenty registers per module address, maximum number of modules is 24. For details, see Appendix C. 30493 30494...

  • Page 97: Appendix C - Expansion I/O Registers

    Adding expansion I/O modules to the 915U-2 will automatically add the I/O from the 115S modules to the internal 915U-2 I/O store. To calculate the register location in the I/O store, find the address of the I/O point in the tables in this appendix, and then add the offset.

  • Page 98: I/O Store For 115S-13 Expansion I/O Modules

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual I/O Store for 115S-13 Expansion I/O Modules I/O Store Description 0001 + Offset DIO outputs 1–8 0008 + Offset 10001 + Offset DIO inputs 1–8 10008 + Offset 10019 + Offset...

  • Page 99: Appendix D - Modbus Error Codes

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual D - MODBUS ErrOr CODES ppENDIx The following are Modbus error response codes that the Master will generate and write to a general purpose analog register (30501, 40501, and so on) in the event of a poll fail.

  • Page 100: Appendix E - Physical I/O Registers

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual E - phYSICaL I/O rEGISTErS ppENDIx Input Output Digital I/O 1 10001 Digital I/O 2 10002 Digital I/O 3 10003 Digital I/O 4 10004 Digital I/O 5 10005 Digital I/O 6...

  • Page 101: Serial Expansion Modules I/O Registers

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Input Output Pulsed Input 2 Rate 30014 Pulsed Input 3 Rate 30015 Pulsed Input 4 Rate 30016 Pulsed Output 1 Count 46001-46002 Pulsed Output 2 Count 46003-46004 Pulsed Output 3 Count...
  • Page 102 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual 115S-11 115S-12 115S-13 Description Inputs Outputs Inputs Outputs Inputs Outputs Digital I/O 15 10015 Digital I/O 16 10016 Analog I/O 1 30001 40001 Analog I/O 2 30002 40002 Analog I/O 3...

  • Page 103: Appendix F - Gnu Free Document License

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual F - GNU FrEE DOCUMENT LICENSE ppENDIx Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.
  • Page 104 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program.
  • Page 105 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.
  • Page 106 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.

  • Page 107: Appendix G - Over-The-Air Configuration

    The MConfig Utility can then be used to configure modules across the radio network. Before you begin, make sure that all 915U-2 modules in the system have been added to the MConfig Utility. For details, see “Adding Units to a Project” on page 37.
  • Page 108 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 105 IP Gateway Mode 2. For each remote module, configure the default gateway address to point back to the radio IP address of the gateway module: a. Click a remote module in the project tree, and then click Ethernet.
  • Page 109 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Figure 107 IP Address Range 3. Configure the default gateway address on the PC to match the gateway module’s Ethernet IP address, or add a routing rule to its default routing table.

  • Page 110: Appendix H - Glossary

    Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual h - GLOSSarY ppENDIx Term Definition Acknowledgment. Access Point An access point connects wireless network stations (or clients) to other stations within the wireless network and also can serve as the point of interconnection between the wireless network and a wired network.
  • Page 111 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Term Definition EIRP Equivalent isotropically radiated power (EIRP) or, alternatively, effective isotropically radiated power is the amount of power that a theoretical isotropic antenna (which evenly distributes power in all directions) would emit to produce the peak power density observed in the direction of maximum antenna gain.
  • Page 112 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Term Definition MAC Address Media Access Control (MAC) address is a unique code assigned to most forms of networking hardware. The address is permanently assigned to the hardware, so limiting a wireless network’s access to hardware (such as wireless cards) is a security feature employed by closed wireless networks.
  • Page 113 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Term Definition TCP/IP The underlying technology behind the Internet and communications between computers in a network. The first part, TCP, is the transport part, which matches the size of the messages on either end and guarantees that the correct message has been received.
  • Page 114 Cooper Bussmann 915U-2 Wireless Mesh I/O and Gateway User Manual Notes www.cooperbussmann.com/wirelessresources Rev Version 1.2.2...
