Summary of Contents for Semi Solution Chanun Nova
- Page 1 User’s Manual Read carefully through this User Manual for safe use before installation, operation, or use.
- Page 2 Before you read the User Manual This User Manual is a basic guide that contains guidelines and instructions for installation and operation of our product Chanun Black Box. Whether you purchase this product for the first time or you have already had experiences of handling other similar products, you are advised to read carefully through the details of this User Manual with special care given to all the safety precautions and notes which are introduced to promote your safe use and protect you against personal injury and property damage.
- Page 3 The copyright to this User Manual belongs to Semi Solution. Use or reproduction of any part or the entire content of this Manual without prior written permission from Semi Solution is strictly prohibited. This User Manual is subject to change for the purpose of improving the performance of the product without advance notice.
- Page 4 Cautions_ Safety instructions This product is safe driving auxiliary products which provides awareness of safe driving , pre-accident prevention and reference for accident by recording videos of the vehicle. Precautions describe in this is to enable the user to use the product safely and avoid the risk of accidents and property damage that may result from the improper use of the products.
- Page 5 It is essential information that must be observed in the case where the user is likely to cause serious injury or death. • The camera lens region of the product always maintain clean. If the camera lens region is contaminated with foreign substances, fingerprint, dust and so on, it reduces the quality of recorded video. Please wipe periodically using a soft cloth.
- Page 6 Caring for SD memory card Please be sure to read the notes the following when you use micro SD which is very s important part of the video recording. With respect to data loss or damage of the recording data on the micro SD card, this company will not be held responsible in any case. •...
-
Page 7: Table Of Contents
Table of Contents Product Overview ....................8 Streaming Method ...................30 Features ........................... 8 LIVE streaming .........................32 Basic Components ......................8 Change of Layout ......................33 Names of Parts and their Functions ................9 Setting of Remote Control ....................33 Playlist ..........................34 Insertion and Removal of Micro SD Card ............ -
Page 8: Product Overview
Product Introduce Feature • Built in 3.5”TFT LCD (800x480) • Various recording mode • GPS(option)/G-sensor • Front Full HD Rear HD high definition • Live/playback video streaming via wifi network • High temperature protection, power management, wide angle sensor and lens and memory management •... -
Page 9: Names Of Parts And Their Functions
Names of each part <Front> <Rear> Camera lens : Shooting video the front of the vehicle. USB Jack : Connect USB Cradle connector : The part that connects the cradle SD card Slot : Insert SD card which stores recorded video. Speaker : Output the voice guidance Micro USB Jack : Connect Micro USB Power LED : Displays the power status... -
Page 10: Insertion And Removal Of Micro Sd Card
Remove/Insert the micro SD card 1. Please check the following before using the micro SD card. - Please use only genuine micro SD card. Using non-genuine micro SD card can cause data loss and product failure. - On inserting micro SD card, it operates after resetting internal software. Before removing micro SD card, must turn off power of black box. 2. -
Page 11: Getting Familiar With Safety Precautions Before Installation
Full knowledge before installing the product • Turn off the engine before installing the product and install in the state of unplugging the car key. • In order to improve the recording quality, it always is sure to keep the glass surface clean. •... -
Page 12: Installation
Installation Cradle • Install the product as shown in the picture on your left. Mounting of the cradle on heating wire may cause damage to the wire during later disassembly, to which you need to pay attention. • Be sure to wipe the foreign matter or dust cleanly off the area where the product is attached with double-sided tape. - Page 13 3. Run the power cable along the gap between the windshield and the ceiling of your vehicle. 4. Guide the cable along the side curve. It is useful to use a tool (such as a credit card or a thin plastic stick).
- Page 14 1. Open the door on the driver’s side and guide the power cable down vertically along the dash board. 2. Run the cable along the edge of the door down to the area where the feet rest and then fix it. 3.
- Page 15 4. Fix the cable at the console box on the driver’s side. 5. Connect the power cable to the cigar socket. The installation is completed when you start the engine and see the lamp of the main body come on; otherwise, check if each connection is securely connected and clear dust or foreign matter off the cigar socket.
-
Page 16: Start System
System startup In order to set the black box in motion, you need to connect it to a constant power supply or a cigar jack in your car. The black box displays only the front view in the event it does not have a rear view camera connected to it. <2-channel screen>... -
Page 17: Screen Layout
Screen configuration • State Information At the top of the screen, it would be shown the date and time in addition to six state information as shown below. State icon Description Normal continuous recording Event Recording by g-sensor and motion. Emergency recording by clicking record button on main UI When the SD card is recognized Flashing periodically when SD state is abnormal or it is time to periodic format... -
Page 18: Video Layout
Viewer layout Touch area for changing mode User can change display mode by touching specific area of the screen. It changes with following sequence. → → channel display in PIP mode front channel only rear channel only. Preference Setting <Preference setting menu> The user can see following playback and setting items by touching icon on main menu bar. -
Page 19: Configuration Window Setting
Setting window Each item in the preference menu consists of menu item, touch area and control area as shown in the figure below. <Setting window> • Menu item : It is sub menu item of menu item.. • Touch area : It is area for setting each item and applying the changes by touching. For some of setting item which has 3 steps or more setting values, you can increase or decrease value by touching touch area divided up and down. -
Page 20: Playback
Playback In playback window, the user can see 5 directories such as Normal/Event/Parking/Manual/Still Image. And, in each directory, it shows recorded files which are sorted by recent time. To start playback, click the file name on the screen. During the playback, it stops video recording. <Search file window>... -
Page 21: Types Of Saved Files
Recording file structure It is recorded as AVI file for video and JPG file for still image. AVI video file is classified as continuous mode, g-sensor mode, manual mode and parking mode • G-sensor event has the highest priority than other events. •... -
Page 22: Video Playback
Playback video <Description of file playback screen> Likewise system startup, 2 channel front and rear videos are displayed in playback mode. When you have finished playing a file, it will play next file automatically. View image file <Touch area for going previous/next image> Images are divided into front and rear. -
Page 23: Display
Display <Display menu> • Screen Brightness: It supports 5 levels of brightness and higher number means brighter level. • LCD Off: It is for the timeout of LCD display. LCD off is possible only driving mode. • In playback mode, LCD is always on. •... -
Page 24: Audio
Audio <Audio setting menu window> • Mic: It is for MIC on/off. • Sound: It is for Audio OUT on/off. • Volume: It is for the volume of Audio OUT and it supports 5 levels of volume. Video parameter configuration After change setting, all recording process is stop and restart as to changed value. -
Page 25: Quality
<Driving/Parking mode selection> The user can set the video quality for normal driving mode and parking mode separately. And, It includes parameters of video quality and frame rate. The default values are HIGH/30frames for driving mode and HIGH/15 frames for parking mode <Video quality and Frame rate Setting>... -
Page 26: System
System <System setting> • You can update the latest F/W as follows.. 1. Copy .app to SD card. 2. Insert SD card into blackbox and startup blockbox. 3. Update F/W by touching the [F/W update] area. 4. After finishing update, delete the F/W file reboot the system. •... -
Page 27: Sd Card
<Year/Month/Day setting> • Time/Date: It consists of Year/Month/Day and Hour/Minute/Second and the user can set each item seperately. Modified time is stored by clicking save icon • Modified time is applied from new file which is going to be generated after current file. •... -
Page 28: Sensitivity
Sensitivity <Sensitivity setting> • Impact sensitivity: It provides 5 levels of the sensitivity of G-sensor and G-sensor detects the impact of vehicle. The higher value means more sensitive level. To avoid frequent “False Alarm”, please set appropriate “Level of Sensitivity” •... -
Page 29: Concerning Parking Mode
Parking mode Entering Parking mode • If black box can detect the status of ACC - If ACC is detected as off, the mode will change parking after a certain time, else if ACC is detected as on, the mode will change driving mode after a certain time. •... -
Page 30: Streaming Method
Streaming 1. Search a keyword of “Chanun Nova” at the APP Store and download the application to your smart device. Keyword: CHANUN NOVA 2. Chang WIFI state from off to on with connection of WIFI dongle. 3. Check the SSID as Figure 30 (it is located at 26 page of system setting) - Page 31 4. Execute mobile app(Android & iOS) 5. Start search WIFI by touch icon Search WIFI(Android) Search WIFI(iOS) In case of iOS, the WiFi Settings window appears in the System Setting, when you need to log in through WiFi to the application again. 6.
-
Page 32: Live Streaming
1. After success connection, you can change SSID and password Password consists more than 8 characters or numbers LIVE streaming Live streaming will be started by touching Live icon after WIFI connection... -
Page 33: Change Of Layout
Layout Change You can select layout by touching icon Remote Setting You can change the setting of blackbox and playback the video stored in blackbox remotely. The setting procedure is same as LCD menu except playback. -
Page 34: Playlist
Playback list Play list will be shown when you touch Playback icon. Playback Channel selection menu will appear if you touch icon. When you select channel, the file you chosen will be downloaded and store at your smart device and played. -
Page 35: Playback Of Channel 2
Channel2 play If you wish to playback ch2 after playback ch1, it will be playback after selecting ch2 and click icon LED state Status Rec Type Power LED Status LED Recording LED Security LED Normal Rec Always ON Always ON Blinking at 0.5 second interval in order Blinking at 0.2 second Blinking at 0.2 second interval... -
Page 36: Installing The Player
- VGA: higher than 128MB - DirectX 9.0 or higher 1. Download the latest version of Chanun Nova Program. Execute Chanun NOVA_PC_Setup_1.02.01.exe to install the Program. File location: www.camsolution.co.kr > SUPPORT > DOWNLOAD 2. Click the NEXT button on the Setup Window. - Page 37 3. Select the path where the Chanun_Nova Player is installed and click the INSTALL button Chanun which will be basically installed in C:\Program Files\Chanun_Nova\ 4. When the installation is completed, click the Chanun_Nova Player icon on the desktop of your computer to run the viewer. Chanun Chanun When an error occurs while you complete the installation and run the program, download and install the...
-
Page 38: How To Use The Player
Using the Player 1. Separate the SD memory card from the black box, insert it into the SD memory card reader, as shown in the figure, and connect it to a USB port of your computer. • Check with the card for its front and rear sides and insert the card in the arrow direction. •... -
Page 39: Screen Layout
Screen Layout • This product is designed to reproduce images in a high-resolution environment so they may not achieve smooth playback on a low specification computer. • When you have difficulty in realizing a desired reproduction, you need to upgrade your computer or use another computer to view video files. Search folders Google Map Speed... -
Page 40: Searching Files
Searching Files Designate file paths Connect the SD card of the black box to a computer where the PC Player is installed. Execute the Chanun_Nova Player and click the icon, and you will have the window, as shown in the figure, where you can select a storage medium. Select the drive (a removable disk) that contains the SD card and click the OK button. -
Page 41: Information On Time Bar Display
Display of Information on Time Bar A file saved on a selected date is displayed separately by time and minute. Double-clicking the minute region causes the video to start playing. Playback Playback screen The basic playback screen starts in a 2ch mode in which front and rear view images show at the same time, with the name of a file being played at the top left side. When a file containing only the front view image is playing, the bottom screen remains black. -
Page 42: Screen Switch Setting
When you wish to change the layout of the screen of the video being played, you can use either the [ ] (1ch mode) or [ ] (2ch mode) button to view either one window or two windows . Click the button at the top right side to expand a window full-screen. Screen Switch Setting You can obtain the changeover of front and rear view images from left to right or from upside to downside or vice versa. -
Page 43: Screen Capture
Screen Capture You can save the image being played at the moment when you are watching. Click the camera icon [ ] at the bottom of the playback screen, and you can have the screenshot on the window. Still Picture Window Still Picture Storage path Change... -
Page 44: Displaying Gps Status
Display of GPS Information If a recorded file contains GPS information, the Chanun_Nova Player map will display the vehicle’s location and speed. This map information will not be enabled if the GPS information on the recorded file is inaccurate or if your computer is not connected to the Internet. -
Page 45: Troubleshooting
Troubleshooting Symptom Check Points • Check if the product is correctly connected to a power source. The product does not function at all • Check if the genuine cable provided by us is used. • Check with the camera lens for any foreign matter on it. •... -
Page 46: Product Specifications
Specification Front Sony image sensor: lens angle of view : 136°(Diagonal) Camera Rear HD sensor: lens angle of view : 127°(Diagonal) / 30fps recording (Max) Front Full HD (1920 x 1080) Resolution Rear HD (1280 x 720) Display 3.5”TFT LCD (800 x 480) Storage Micro-SD (16GB/32GB/64GB) Recording... - Page 47 Purpose of the Product and Warranty and Scope of Responsibility of Video Recordings • This product is an auxiliary device for safe driving that is intended to record the driver’s view with the purposes of raising his/her awareness about safe driving, preventing accidents, and providing the circumferential information material when an accident takes place.
-
Page 48: Product Warranty
Product Warranty This product will be warranted pursuant to the Consumer Damage Compensation Regulation as follows. Please contact the store of purchase or our Consumer Service Center when the product is found to be defective. Product Name(Model name) Date of Purchase Year Month Serial No. - Page 49 SEMISOLUTION Customer Service Center Zip code: 446-982, Room 2005, 120, Heungdeok Jungang-ro, Giheung-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-627-5300 Fax: +82-31-627-5303 http: www.camsolution.co.kr...
