- Page 1 Working for a safer world OWNER’S MANUAL ELECTRIC STOVES CAUTION: READ INSTRUCTIONS BEFORE OPERATING APPLIANCE. MODELS: 2247-AC-5100, 2247-AC-5200 SERIAL NUMBER ________________________________________ 75253 Rev. A...
-
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Save the owner’s manual / instructions for local Electrical Inspector’s use. CAUTION To eliminate the risk of burns or fire by reaching over heated surface units, cabinet storage space located above or behind the stove should be avoided. If cabinet storage is to be provided, the risk can be reduced by installing a range hood that projects horizontally a minimum of 5 inches beyond the bottom of the cabinets. -
Page 4: Electrical Installation
MINIMUM* (KW) (AMPS) WIRE SIZE (AWG) 2247-AC-5100 2247-AC-5200 15 (PER LEG) Mentioned in title 33 Code of Federal Regulations, Part 183, Subpart I, Section 183.435.b COOKING OPERATION 1. Push knob down to clear safety lock and turn counter clockwise to desired setting. -
Page 5: Ac-5100
If your cookware spins on the cooking surface, it means that a small bow has formed toward the cooktop during heating. Do not use this cookware. Corrected Diameter: The diameter of the vessel should be the same as the diameter of the glowing heat zone. -
Page 6: Ac-5100
Copper with Tin Lining: Excellent for gourmet cooking, wine sauce and egg cookery. Remember that tin lining will wear thin with continued use. It must be retinned to avoid toxic reactions between copper and food. Ceramic Glass/Ceramic: Good for long, slow low-heat cooking with liquids such as simmering. CAUTION Only certain types of glass, glass ceramic, ceramic, earthware or other glazed vessels are suitable for cooktop service without breakage due to sudden change in temperature. -
Page 7: Ac-5100
CABINET INSTALLATION 2247-AC-5100, 2247-AC-5200 1. Locate stove according to the installation diagram below. 2. Cut-out to the dimension shown. 3. Peel off tape and secure the stove to the counter top. Note: Please clean the entire surface surrounding the counter top. Dust particles and loose sediment may cause the stove to improperly attach to counter top surface. -
Page 8: Ac-5100
2247-AC-5100, 2247-AC-5200... -
Page 9: Table Of Contents
PARTS LIST MODELS 2247-AC-5100 ITEM MODEL NO. PART NO. DESCRIPTION 2247-AC-5100 72302 3/4" GROMMET (3) 2247-AC-5100 72520 120V INFINITE SWITCH (2) 2247-AC-5100 73224 3/8" 90 DEG ELBOW 2247-AC-5100 73302 120V LIGHT (3) 2247-AC-5100 73223 3/8" X 3' FLEX CONDUIT 2247-AC-5100... -
Page 10: Ac-5100
REPAIR PARTS Repair parts listed herein may be ordered through Attwood Corporation, Attwood Distributors and Dealers or Dealers Authorized Service Centers. All parts will be shipped at prevailing prices. When ordering repair parts, please give the following information: 1. The Part Number 2. -
Page 11: Ac-5100
Implied Warranties of merchantability and of the fitness of the product for any purpose are warranted for a period of two year on parts and labor, Whale Cook makes no warranties, expressed or implied after that time. -
Page 12: Ac-5100
NOTES...
