HOPEFUL H SERIES User Manual

Wind turbine system

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

HOPEFUL

WIND ENERGY TECHNOLOGY

Wind turbine system

H - series

User' s manual

Table of Contents

Need help?

Do you have a question about the H SERIES and is the answer not in the manual?

Questions and answers

Summary of Contents for HOPEFUL H SERIES

Page 1 HOPEFUL WIND ENERGY TECHNOLOGY Wind turbine system H - series User' s manual...
Page 3 The conditions of your warranty are dependent upon the proper installation of H-series wind turbine system. Furthermore, this will assure you of being kept up-to-date with the latest developments from Hopeful Wind Energy. These include new options, performance tips, updated software to maximize output and user notices. It is important to know that we do not sell or distribute your information to any third party.
Page 5 Warnings Please excuse from specification alternations without notice. ● It is required to comply with the local law, regulations or the permission ● From local government before installing WT. Only under no wind weather should carry out the installation, maintenance And ●...
Page 6: Table Of Contents
Table of Contents Cautions ..................1 Wiring diagram .................10 Parameter for each model...........1 Connecting sketch map.............10 Packing ..................3 Controller parameter ............12 Packing details ..............3 Installation of ground controller box ........12 Transportation ..............3 Connection .................13 Loading location ..............3 Battery configuration specification ........14 H-series Warranty ..............4 Maintenance ................15 WIND TURBINE WARRANTY AGREEMENT....4...
Page 7: Cautions
Cautions Parameter for each model The manual refer to the wind turbine system attached below Yawing is forbidden before the tower erected. Model H8-10K H10-20K H12-30K Rated power(KW) "manual-mode" is only available with technicist, the Rater voltage(V) turbine will loose protection in manual mode. Rotor diameter(M) 10.0 12.0...
Page 8 Parameter for each model Generator composition: Description Description Control system Base plate Hydraulic brake Accumulator Brake disc Yaw motor Generator Hydraulic motor and oil tank Slewing bearing Dump load Yawing brake Ultrasonic wind measuring device...
Page 9: Packing
Packing Loading location Packing details Please find the recommended loading location attached below Description Qty(unit) Packing form marked with black point. Wind turbine(including generator, Plywood case 1）Generator inside controller system, hub and cables) There is a loading U-bar installed under bottom plate of the Controller Plywood case generator, in case of the arm of the forklift would broken the oil...
Page 10: H-Series Warranty
If Hopeful Energy's repair facility determines that the Hopeful Energy wind turbine wind generator determined by problem with the wind generator is not due to a defect in Hopeful Hopeful Energy to be defective in materials and/or workmanship Energy's workmanship or materials, then the party requesting...
Page 11 If a warranty claim is invalid for any reason, the UNDER NO CIRCUMSTANCES WILL HOPEFUL ENERGY Customer will be charged at Hopeful Energy's current rates for OR ITS AFFILIATES OR DEALERS BE LIABLE OR services performed and will be charged for all necessary repairs RESPONSIBLE FOR ANY LOSS OF USE, INTERRUPTION and expenses incurred by Hopeful Energy.
Page 12: Installation
Installation Assembling generator with free standing tower Selecting of the location Forklift and 25T crane are required for the installation. The installation side should be at least 200m away from the Besides, two aloft working personnel are necessary during the following area: house, crowd, overhead conductor, road and installation.
Page 13 Installation 5）Facing the wind turbine as the following picture shown A. Catch a sight of the screw hole A , which is on the top of the hub and is the closest one to the flat surface A. B. Find the chink L on the blade root ,then match the screw hole on the left side of the chink L to the screw hole A on the hub , tightening the other screws.
Page 14 Installation 6）Pull the cable for wind measuring device out of the support ） 7 Lifting the nacelle to the top of the tower with a crane, put bar and connect with the wind measuring device, connect this down the cable inside tower to the ground. device with the support bar, fix the support bar with the 8）Connecting nacelle and tower with bolts, fasten all the bolts outboard of the back cover via a fixed black.
Page 15: Assembling Generator With Hydraulic Tower
Installation ） Assembling generator with hydraulic tower 6 Moving the generator close to tower, taking the cables through out from generator and connecting with steel wire, Forklift and crane are required for the installation pulling the steel wire go out of tower. Taking off the steel wire, 1）Assembling the tower base and putting into the foundation pull the cables out of thread hole for standby.
Page 16: Wiring Diagram
Wiring diagram Connecting sketch map OFF GRID（Picture as below） Wind turbine Electrical appliance Please make sure that the output voltage, voltage of battery and the input Controller voltage of battery should be same. Do not misconnect the end of battery, which would burn the generator, battery and inverter out.
Page 17 Wiring diagram ON GRID（Picture as below） Wind turbine Every model of E-series could be a p p l i e d f o r o n - g r i d s y s t e m w i t h t h e permission of local government, and on-gird inverter and on-grid controller should be Electrical appliance...
Page 18: Controller Parameter
Wiring diagram Controller parameter Installation of ground controller box The controller is wall built-up type. Temp. Between -40°—60°, non-corrosiveness Environmental and combustible gas, not much of electrical conditions conductivity dust Operation According to the standard JIS B 3502、 height IEC61131-2(below 2000m) Vibration impact resistance according to standard strength...
Page 19: Connection
Wiring diagram Connection On-grid system Make sure the rated DC voltage of the output of generator, battery Line bank and input of the inverter is exactly the same. Pay attention to the positive and negative connection , any wrong connection would cause damage of the generator, battery or inverter.
Page 20: Battery Configuration Specification
Wiring diagram Battery configuration specification Battery bank should be put in a building where is broad and The means of linking battery in parallel: connect the anode ventilated with stable temperature and dry air. According to the of one battery to the anode of the other, and the cathode of one output voltage of the battery to decide the number of battery and battery to the cathode of the other.
Page 21: Maintenance
Maintenance Working environment of the wind turbine system may very bad, the ssytem always working under the complex weather, in order to make sure the good performance of the system, regular checking and maintenance are required. Laying down the tower would be recommend before storm. Maintenance schedule After storm Every half year Every year...
Page 22: Frequently Asked Questions
If you live in a lightning prone check the cable of the generator. area Hopeful Wind Energy recommends an additional lightning 3) Why cannot the blades turn at a normal wind speed or turn arrestor at the base of the tower.
Page 23: Disconnection And Disassembling Wind Turbine
Disconnection and disassembling wind turbine Notes Free standing tower Hydraulic oil grade: ℃ ：L-HM46 Environmental temp.: -20℃~80 1 Choosing windless weather to do the disconnection. 2) Switching the controller into "power off" mode. Environmental temp.: < -20℃：L-HS32 3) Turning off the power switch of controller. Torque for fastening expansion sleeve of the hub：230NM 4) Disconnecting grid with controller.
Page 28 HOPEFUL WIND ENERGY TECHNOLOGY CO., LTD Address: Building C,No.18 7th Keji Road,National Hi-Tech Zone, Jinding,Zhuhai,China 519085 Tel: +86-756-3819866/3819868 Fax: +86-756-3882362 Post code: 519085 E-mail: info@hopefulenergy.com Website: www.hopefulenergy.com...
