- Page 1 VERA L24 Operating Manual...
- Page 2 VERA L24 supports the low-mid performance of VERA10 arrays between 60 to 300 Hz. Equipped with two 12" loudspeakers, the hybrid enclosure construction combines the advantages of bass reflex and horn design, so that a single VERA L24 can give three or four VERA10 elements a clear low-mid boost and plenty of punch.
- Page 3 TW AUDiO also shall not assume liability for any secondary damage (property damage and/or personal injury) nor for the failure to comply with this operating manual. TW AUDiO reserves the right to make changes that take into account the latest engi- neering advancements.
-
Page 4: Table Of Contents
Operating Manual VERA L24 Content Safety | Intended use .....................1 Overview ........................3 Components ........................3 Technical data ........................4 Data sheet .......................... 4 Wiring diagram ........................4 Setting up ........................5 Setup ..........................5 Making cable connections ....................5 Operation ..........................6 Transport and storage ....................7... -
Page 5: Safety | Intended Use
Note the operating modes described in this operating manual. Other uses are not permissible. TW AUDiO GmbH shall not be held liable for any damage that ensues from unintended use. Loudspeakers generate an electromagnetic field. Persons with pacemakers are not per- mitted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields can cause pacemakers to malfunction. - Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
15 mm multiplex enclosure – polyurea surface finish Milled recess for rubber feet for safely stacking loudspeakers Ergonomic carrying handles (left, right and rear) VERA L24 rigging plate, "rear" Locking pin 8x20 VERA L24 rigging plate, "front" 12" cone drivers... -
Page 8: Technical Data
Operating Manual VERA L24 3. Technical data 3.1 Data sheet 2x 12" Components 63 - 400Hz Frequency response Power handling, program/ 1300 / 2600 W peak 8Ω Impedance 135 dB Max. SPL/1 m 550 x 500 x 560 mm [21,65 x 19,69 x 22,05 in] Dimensions (h x w x d) 33.6 kg [74,08 lbs]... -
Page 9: Setting Up
The pin connections of the VERA L24 loudspeaker can be found in section 3.2 “Wiring diagram” on page 4. The two VERA L24 connection sockets on the back of VERA L24 can be used to link multiple loudspeakers to a single amplifier output. Note that parallel connection reduces the total impedance (Ω) seen by the amplifier. -
Page 10: Operation
Operating Manual VERA L24 4.3 Operation TW AUDiO recommends operating the VERA L24 loudspeaker on a DSP controller. TW AUDiO only recommends using presets developed by TW AUDiO. The TW AUDiO system racks are ideal for this purpose. Ensure that the right preset was selected before connecting the loudspeaker with the amplifier. -
Page 11: Transport And Storage
Operating Manual VERA L24 5. Transport and storage Because the VERA L24 loudspeaker weighs far more than 20 kg [44,09 lbs], two people are needed to move and transport one. NOTE To enable a single person to transport multiple VERA L24 loudspeakers, TW AUDiO recommends using the VERA DL24 transport cart. -
Page 12: Ce Conformity Declaration
Operating Manual VERA L24 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. -
Page 13: Disposal
TW AUDiO products that bear the trash can symbol shown here are only permitted to be disposed of by TW AUDiO. The loudspeaker owner is legally responsible for the disposal of used devices that do not bear this symbol. - Page 14 TW AUDiO GmbH Osterholzallee 140-2 71636 Ludwigsburg Germany P: + 49 (0) 71 41-48 89 89 0 F: + 49 (0) 71 41-48 89 89 99 E: info@twaudio.de W: www.twaudio.de...
