Summary of Contents for Therma-tek TFCO-GM-1
- Page 1 THERMA-TEK RANGE CORPORATION “QUALITY AND STRENGTH” FULL-SIZE GAS CONVECTION OVEN SERVICE MANUAL Model TFCO-GM-1 covered in this manual is shown with optional casters. ________________ _____________________...
- Page 2 INTRODUCTION The Full-Size Gas Convection Oven Parts / Service Manual contains Installation and Operation Recommendations. It also includes Troubleshooting and Technical Data such as Orifice Hood Sizing and Gas Pressure Requirements. The material presented should be used in conjunction with the Owner’s Manual, Professional Training, Service Experience, and Industry Standard Practices.
- Page 3 MODEL NUMBER IDENTIFICATION TFCO-GM-1 (N T (Therma) F (Full-size) C (Convection) O (Oven) G (Gas) M (Manual control) – 1 (Single deck) The Final Character N or L (NATURAL or LP Gas). STANDARD FEATURES 60,000 BTU’s /Hr. Natural Gas. 54,000 BTU’s / Hr. Propane Gas.
- Page 4 WARRANTY SERIAL NUMBER THERMA-TEK SERIAL NUMBER & DATE CODE Date of manufacture is a date code and is part of the serial number. Example: 09J00001A (a) Year Code: Use the last two digits of the year. 07 = 2007 08 = 2008...
- Page 5 GAS REQUIREMENTS MODEL DESCRIPTION TOTAL GAS CONSUMPTION Single deck, manual control, natural gas 60,000 BTU’s / Hr. TFCO-GM-1N 17.59 kW TFCO-GM-1L Single deck, manual control, propane gas 54,000 BTU’s / Hr. 15.82 kW (Double decking ovens doubles gas consumption.) Operating Manifold Gas Pressure Manifold Connection Burner Orifice Drill Size Natural Gas...
