- Page 1 ASSEMBLY, USE Meteor AND INSTRUCTION MANUAL GG501701 Black EDITION READ THE OPERATING INSTRUCTIONS BEFORE USING THE APPLIANCE. FOR OUTDOOR USE ONLY.
-
Page 2: Table Of Contents
Contents Warnings..............3 Technical data ............4 Gas category ............4 Explotion drawing ............ 5 Parts list ..............6 Hardware ..............7 Assembly instructions ..........8 Gas leak test ............16 Connecting gas ............17 Before using the grill..........18 Grilling tips ............19 Lighting instructions ..........20 Warnings ...............21 Maintenance ............22 Cleaning ...............22... -
Page 3: Warnings
WARNINGS Failure to follow the instructions provided can imply a risk of serious injury to personnel and fixed installations. Some grill parts can be sharp, we recommend wearing gloves when assembling and lifting. Sharp edges can cause injury. The grill is intended for outdoor use only in well-ventilated areas. Never grill in enclosed spaces or under a roof, due to the danger of the lack of oxygen. -
Page 4: Technical Data
Technical data — Meteor 4B L: 130 cm Total effect: 12,96 kW Total gas consumption: 943 g/h. Hose and regulator (not included): Must be approved according to EN standard. Gas bottle (not included): Use standard bottle approved for use in the Nordic Region, 10/11 kg recommended. -
Page 5: Explotion Drawing
Exploded drawing... -
Page 6: Parts List
Parts list CODE PART Meteor 4 Burner Gas BBQ Hood (Pre-Assembled to Body) HOOD Hood Handle Warming Rack Barbecue Body Burner Control Panel Knob Flame Tamer BODY Cooking Grill Drip Tray Left Bracket Drip Tray Right Bracket Drip Tray... -
Page 7: Hardware
Hardware The following screws and nuts are supplied with the grill and must be fitted. -
Page 8: Assembly Instructions
Assembly instructions Please follow these instructions step by step. We recommend two people to assemble the grill to avoid heavy lifting. TOOLS FOR ASSEMBLING (NOT INCLUDED) Ruler Medium size flat blade or Adjustable spanner or Philips/cross-point screwdriver metric spanner set Exercise caution when using electric tools –... - Page 9 Assembly instructions Rear view Front view Attach the Legs (C4,C5) to the Panels (C6,C7) using ST4.0x10 Screws (D1x8pcs) as shown. Attach the front panel assembly and the Legs (C4,C5) to t he Wire Base ( C8) by inserting the M6x65 Bolts (D6x4pcs) through the legs, wire base, Ø6 W ashers (D7x4pcs) and secure with M6 Nuts (D8x4pcs).
- Page 10 Unscrew the Locknuts (D9) from both ends of the Axle (C11). Slide the axle through the corresponding holes in the left legs. Slide the Wheels (C9) over each end of t he axle. S ecure the wheels i nto place with the l ocknuts. Place the Wheel Hubcaps (C10) onto the outside of the wheels.
- Page 11 Attach the Left Side Shelf Panel (C2) onto one Side Shelf (C1) using M6x15 Bolts (D5x2pcs) and M6 Nuts (D8x2pcs). Attach the left side shelf assembly to the barbecue body using a ST4.0x10 Screw (D1) and M6x15 Bolts (D5x4pcs) as shown.
- Page 12 Attach the Right Side Shelf Panel (C3) onto the other Side Shelf ( C1) using M6x15 Bolts (D5x2pcs) and M6 Nuts (D8x2pcs). Attach the right side shelf assembly to the barbecue body using a ST4.0x10 Screw (D1) and M6x15 Bolts (D5x4pcs) as shown.
- Page 13 Attach the Drip Tray Right B racket (B8) to t he barbecue body using M5x15 Bolts (D2x2pcs), Ø5 Washers (D3x2pcs) and M5 Nuts (D4x2pcs) as shown. Repeat the above process for the Drip Tray Left Bracket (B7). NOTE: Ensure t hat the big tabs of the brackets which stop t he drip tray are located at the front of the barbecue.
- Page 14 Carefully lay the Flame Tamer (B5) into the barbecue body ensuring it lies level within the body. Lay the Cooking Grill (B6) into place. Attach the Warming Rack (A3) to barbecue body as shown.
- Page 15 ASSEMBLY IS NOW COMPLETE. ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE GRILL. READ CAREFULLY LEAK TESTING ON PAGE 16.
-
Page 16: Gas Leak Test
IMPORTANT! GAS LEAK TEST ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE GRILL. Leak test annually, and whenever the gas bottle is removed or replaced. Always perform a leak test in a well-ventilated area. Make a mixed solution (½... -
Page 17: Connecting Gas
Connecting the gas ALWAYS perform a gas leak test before using the grill. Hose Gas bottle Check the gas hose regularly Connect the gas hose to the gas for cracks, damage and decay. rail inlet on the left hand side of the Never use a damaged gas hose. -
Page 18: Before Using The Grill
Before using the grill LOCATION Ensure that the grill is placed at least 150cm in all directions from house walls, trees, plants and other flammable materials or liquids when in use. Do not place the grill under a roof or overhang. -
Page 19: Grilling Tips
Grilling tips A CLEAN GRILL WORKS BETTER, causes less smoke and prevents fat catching fire. Burn off the grill after use by opening the lid and burning all the burners at full power for 10 minutes. Allow the grill to cool, and then brush off ash from flame guards and grates. -
Page 20: Lighting Instructions
Lighting instructions Meteor 4B Open the barbecue hood or lid before lighting. Never MANUAL IGNITION light your barbecue with the hood or lid closed. If the grill will not light using the Ensure all knobs are in the OFF position. Open the normal lighter, use the following gas control valve on the gas bottle or regulator. -
Page 21: Warnings
WARNING! Always keep an eye on the grill when in use. Never allow children or others Disconnect the gas bottle when the whorequire supervision near the grill when grill is in use or before moving it. in use. If storing the grill in a garage or This grill is only intended for outdoor basement below ground level, do not store use and must not be used under a roof. -
Page 22: Maintenance
Maintenance and cleaning MAINTENANCE CLEANING Check that the burners are Use clean water only. A mild washing up burning correctly regularly. liquid can be added for general cleaning. Do not use flammable cleaning agents. Remove the grill grate and flame guards. -
Page 23: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Empty gas bottle Replace gas bottle Damaged regulator Check/replace the regulator Burner is blocked Clean the burner Gas supply is blocked Clean gas ventury or hose Burner will not light when using the ignition knob Electrode is broken or dirty Clean the electrode Ignition knob is broken... -
Page 24: Consumer Contact
Spare parts, consumer contact and warranty claims. This product is covered by a warranty in accordance with consumer legislation. It has undergone strict quality controls and testing at the factory. If there are any parts missing or the product has been damaged, please contact your dealer or the consumer contact below for help.
