Summary of Contents for Netzerotools HDV600
-
Page 1: User Guide
User Guide High Definition VideoScope Model HDV600 Extech HDV600 Borescope Video Scope Inspection Camera Extech HDV610 Borescope VideoScope Inspection Camera Kit Extech HDV620 Borescope VideoScope Inspection Camera Kit Extech HDV640 Borescope VideoScope Inspection Camera Kit Extech HDV640W Borescope VideoScope Inspection Camera Kit... - Page 2 Introduction Congratulations on your purchase of this Extech HDV600 series Video Borescope. This instrument is designed for use as a remote inspection device. It can be used to peer into tight spots, record and playback real-time video and images. Typical applications include HVAC inspection, automotive inspection, cable routing, and automotive/boat/aircraft inspection.
-
Page 3: Probe Accessories
6. AC Adaptor and extension cable sockets 7. Carrying strap Wireless Transmitter Probe Connector Light Intensity buttons Power button AC Adaptor and extension cable sockets Carrying strap Probe accessories Anti-snag tip Magnet 45° Mirror Probe Camera Shaft Monitor connector HDV600-EU-EN-V2.7 10/12 netzerotools.com... -
Page 4: Menu Description
Set the menu display to any one of 21 languages. VIDEO FORMAT: Set the video output to NTSC or PAL format. AUTO POWER OFF: Set the APO to 5, 10, 15, 30 minutes or DISABLE. INPUT SOURCE: Set Direct or Wireless. HDV600-EU-EN-V2.7 10/12 netzerotools.com... -
Page 5: Operation
Press the button to rotate the display 90 degrees. Installing probe accessories Three accessories (mirror, anti-snag tip and magnet) are supplied with each probe. Attach the accessory by unscrewing the probe ring and screwing on the attachment. HDV600-EU-EN-V2.7 10/12 netzerotools.com... -
Page 6: Articulating Probe
Turn the probe outer knob to adjust the camera tip to the viewing angle needed. Turn the upper knob to increase or decrease the outer knob tension In this mode, light intensity is controlled by the buttons on the monitor, not by the buttons on the transmitter. HDV600-EU-EN-V2.7 10/12 netzerotools.com... -
Page 7: Wireless Transmitter
Press and hold the Power button for 4 seconds to turn the monitor on, then select “DIRECT” under the INPUT SOURCE selection in the MENU screen. In the direct mode, light intensity is controled by the buttons on the monitor, not by the buttons on the transmitter. HDV600-EU-EN-V2.7 10/12 netzerotools.com... -
Page 8: Video Output
Insert the video cable into the VIDEO OUT socket on the bottom of the monitor. Connect the other end of the cable into the VIDEO IN jack of a TV or other monitor. The unit will output a high quality video image. HDV600-EU-EN-V2.7 10/12 netzerotools.com... - Page 9 You can hand over your used batteries / accumulators at collection points in your community or wherever batteries / accumulators are sold! Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the end of its lifecycle HDV600-EU-EN-V2.7 10/12 netzerotools.com...
-
Page 10: Specifications
100 to 240V input / 9VDC output Unobstructed Effective Range Operating/Storage Temperature -10 to 60°C(14 to 140°F) / -40 to 80°C(-40 to 176°F) Dimensions (W D H) 7.5’ x 2.75 x 2.5” (19 x 7 x 6.35cm) Weight (approx) 0.95lb (431g) HDV600-EU-EN-V2.7 10/12 netzerotools.com... - Page 11 640x480 HDV-5CAM-3R Long depth of field Semi-Rigid 5.5mm 6 cm to ∞ 640x480 HDV-5CAM-3RM Macro lens Semi-Rigid 5.5mm 2 to 6cm 640x480 HDV-25CAM-10G Fiberglass 25mm 6 cm to ∞ 640x480 HDV-25CAM-30G Fiberglass 25mm 6 cm to ∞ HDV600-EU-EN-V2.7 10/12 netzerotools.com...
