ISC UC-5770W User Manual

Wireless transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1.
Packaging Contents .................................................................................................................................................................. 4
2.
System Requirements .............................................................................................................................................................. 4
U-Connector/UC-5770W
User Guide
UC-5770W
V1.0
Contents
1 of 44

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC-5770W and is the answer not in the manual?

Questions and answers

Summary of Contents for ISC UC-5770W

  • Page 1 User Guide UC-5770W V1.0 Contents Packaging Contents .................................. 4 System Requirements ................................4 U-Connector/UC-5770W 1 of 44...

  • Page 2: Table Of Contents

    6.2 S/PDIF Pass Through and 5.1CH Audio ......................27 6.3 Selecting Audio Device on WINDOWS XP ......................27 6.4 Selecting Audio Device on WINDOWS 7 ......................29 6.5 Activation of S/PDIF 5.1CH Audio ......................... 30 Activation Steps .............................. 30 6.5.1 U-Connector/UC-5770W 2 of 44...
  • Page 3 7.5 No Screen Output in case of using VGA port ....................38 7.6 No Screen Output on the Monitor ........................38 7.7 Checking Wireless Manager Program Version ....................39 7.8 Selecting Wireless Manager Channel........................39 7.9 Tips for Installation ............................... 40 UC-5770 Specifications ................................ 41 U-Connector/UC-5770W 3 of 44...

  • Page 4: Packaging Contents

    Intel dual core CPU or higher  1GB memory or higher  100 MB of free hard disc space or more  USB 2.0 PORT or higher  Microsoft Windows XP SP2 or higher  Microsoft Windows 7 32/64  U-Connector/UC-5770W 4 of 44...

  • Page 5: Rear Panel Of Hdmi Receiver

     program. When you install it, pls. do not connect to the USB receiver on the computer. -. USA : http://iscom.ipdisk.co.kr:80/publish/HDD1/Oversea/UC-5770W/Driver/USA.zip -. Europe, Asia and others : http://iscom.ipdisk.co.kr:80/publish/HDD1/Oversea/UC-5770W/Driver/EU.zip For your reference, according to your region, pls. select and download it.
  • Page 6 Install The installation Autoplay menu is displayed. Click  Install wireless USB driver. Click Next.  U-Connector/UC-5770W 6 of 44...
  • Page 7 Click I accept the terms of this License Agreement. Click Next.   Select installation folder, then click next, then Install.  When the installation is finished, click Finish to complete the wireless manager S/W installation. U-Connector/UC-5770W 7 of 44...
  • Page 8 U-Connector/UC-5770W 8 of 44...

  • Page 9: Audio Setting For Hdmi Port

    Audio Setting for HDMI Port When the computer is rebooted after the program installation is completed, click My  Computer -> C :\Program Files \ SGFX\AUDIOBYSPDIF.reg to change the registry value. You can hear audio through HDMI cable. U-Connector/UC-5770W 9 of 44...

  • Page 10: Plug In Receiver

    Plug in Receiver Plug the HDMI/RGB cable into the HDTV/Projector as below.  * Select a HDMI port that supports full HD video/audio. Try different ports in case of a problem with audio or video. U-Connector/UC-5770W 10 of 44...
  • Page 11 HDTV and projector remote control. Example)  Once the power is on, red power lamp on the right side turns on, and green lamp on the left side turns on to show wireless connection. U-Connector/UC-5770W 11 of 44...

  • Page 12: Plug In Usb Transmitter

     Click the blue icon for wireless connection. You can see channels that are currently being used on the communication tap page as below. In this case, you may consider that transmitter device recognition is completed. U-Connector/UC-5770W 12 of 44...

  • Page 13: Auto Connection And Disconnection

    ‘Set as default’ from the menu for auto connection mode, which will be displayed next to the monitor symbol. For disconnection, uncheck ‘Set as default’ and select ‘disconnect’. U-Connector/UC-5770W 13 of 44...

  • Page 14: C-Media Audio Driver Installation (On Windows Xp)

    C-Media Audio Driver Installation (on Windows XP) Connect transmitter and receiver with the wireless USB manager.  NOTE: C-Media audio driver can be installed only when transmitter and receiver are connected. U-Connector/UC-5770W 14 of 44...
  • Page 15 Insert the drive CD into the computer CD-ROM. Put the mouse on the ‘My Computer’ icon on the  desktop, right click and choose “manage”. Computer management -> Device Manager -> Select ‘sound, video and game controller ->  select USB audio device. U-Connector/UC-5770W 15 of 44...
  • Page 16 Go to Driver menu tap of USB audio device registration information, and select Update Driver.  As the hardware update wizard starts, select ‘install from a list or specific location’ and click next.  Select ‘don’t search, I will choose the drive to install’, and click next.  U-Connector/UC-5770W 16 of 44...
  • Page 17 Click ‘Have Disk’, and select ‘Browse’.  Select My Computer -> CD-Rom -> utility -> USB Sound Program -> USB-108-110131-5.12.8.2151(XP-ER-01) -> Driver ->USB -> CM108. INF and click confirm. U-Connector/UC-5770W 17 of 44...
  • Page 18 When ‘USB PnP Sound Device’ is displayed, select it and click next to install the device.  When following window pops up during the installation, select ‘Continue anyway’ to proceed  with the installation. U-Connector/UC-5770W 18 of 44...
  • Page 19 You can see the driver provider has changed from Microsoft to C-Media Inc. U-Connector/UC-5770W 19 of 44...

  • Page 20: C-Media Audio Driver Installation (On Windows 7)

    C-Media Audio Driver Installation (on Windows 7) Connect transmitter and receiver with the wireless USB manager  NOTE: C-Media audio driver can be installed only when transmitter and receiver are connected.  Insert the drive CD into the CD-Rom of the computer. U-Connector/UC-5770W 20 of 44...
  • Page 21 C-Media driver. NOTE: It is recommended to install C-media driver for the sound driver. In case of  using S/PDIF pass through function and 5.1ch, refer to the “ S/PDIF 5.1CH Activation” page. U-Connector/UC-5770W 21 of 44...

  • Page 22: Adjusting Display Mode (Adjusting Video Settings)

     Duplicate Mode: It is used to display the identical content on the additional screen as is shown on the main PC/laptop screen. (Clone mode, Mirror mode) U-Connector/UC-5770W 22 of 44...

  • Page 23: Setting Display Mode On Windows Xp

    NOTE: Basic setting is extended mode. Duplicate Mode  It is to duplicate the main monitor and show the identical content. Extended Mode  External monitor is an extended space of the main PC/laptop screen. (Dual mode) Extend to  U-Connector/UC-5770W 23 of 44...
  • Page 24 Extend to: It is used to extend the display to the right of, to the left of, above and below the main monitor, and set the direction of the mouse. U-Connector/UC-5770W 24 of 44...

  • Page 25: Setting Display Mode On Windows 7

    NOTE: Above picture is an example. Extended monitors have different resolutions. Setting Display Mode on Windows 7 To switch between duplicate mode and extended mode on Windows 7, press Windows key  + P) together with the P ( U-Connector/UC-5770W 25 of 44...
  • Page 26 To change the mode in display properties, right click on the desktop and select screen resolution.  Click multiple display and change to the display mode that you want.  U-Connector/UC-5770W 26 of 44...

  • Page 27: Adjusting Audio Settings

    Device -> Audio. Select not USB PnP Sound Device but the original audio device of the computer, and click apply and confirm. If you change the audio device during the video playing, replay the program and apply the change of the device. Properties Click Option ->  U-Connector/UC-5770W 27 of 44...
  • Page 28 OK. NOTE: Above picture is an example. In above picture, Realtek HD Audio output is the default audio device of the user. However, please note that it may be different according to your computers’ sound device. U-Connector/UC-5770W 28 of 44...

  • Page 29: Selecting Audio Device On Windows 7

    5.1ch through a digital AV receiver, select “USB PnP Sound Device” of Digital Output. In this case, you will not be able to listen to audio through normal TV. NOTE: Above picture is an example. U-Connector/UC-5770W 29 of 44...

  • Page 30: Activation Of S/Pdif 5.1Ch Audio

    Install AC3 Filter Driver in the Utility directory of the CD.  Select language and click OK.  Next -> Select installation folder and click Next NOTE: Download the latest version at http://ac3filter.net/wiki/Download_AC3Filter  Select components to install, and click Next, U-Connector/UC-5770W 30 of 44...
  • Page 31  Select Start Menu folder, and click Next -> install  Execute AC3 Filter Config after the installation, and select settings for each section.  AC3 Filter language selection. Select System -> Language -> Korean, to finish the language setting. U-Connector/UC-5770W 31 of 44...
  • Page 32  Main Setting * Select AS IS(no change) in Output format U-Connector/UC-5770W 32 of 44...
  • Page 33 * Select AS IS(no change) in Rate * Select PCM 16bit in Format * Check Use S/PDIF  SPDIF Setting *Select AC3 and DTS in S/PDIF Pass through *Select Auto in SPDIF/ DTS mode U-Connector/UC-5770W 33 of 44...

  • Page 34: Helpful Tips

    Troubleshooting for video playback  Black screen in full screen mode while watching an internet video, or using Adobe flash player or YouTube. *Right click on the video screen, and click setting. Uncheck Enable hardware acceleration, and play again. U-Connector/UC-5770W 34 of 44...
  • Page 35 *Right click My Computer in the desktop, click Computer Management. Click Computer management -> Device manager, and see Sound, video and game controller. If there is not USB PnP Sound Device, reset the power of the receiver. U-Connector/UC-5770W 35 of 44...

  • Page 36: Resolution Of Hdtv And Projector

    In this case, set the display to duplicate mode in order to activate the first monitor, and change back to extended mode. It can happen due to a conflict between video driver and OS. The first monitor is turned off. U-Connector/UC-5770W 36 of 44...
  • Page 37 Back to the normal after changing from duplicate mode to extended mode U-Connector/UC-5770W 37 of 44...

  • Page 38: Wireless Connection Is Not Smooth

    If 7.5 is not applicable, right click the My Computer icon in the desktop, and select Manage. Click Computer Management -> Device Manager, and see USB and Network Display Devices if there is SMSC UFX6000 Device item. If not, reset the power of the receiver. U-Connector/UC-5770W 38 of 44...

  • Page 39: Checking Wireless Manager Program Version

    Selecting Wireless Manager Channel Automatic mode is recommended for channel selection. In Korea, 8 channels are available, and channel 15 may have better reception if there is no channel interference. U-Connector/UC-5770W 39 of 44...

  • Page 40: Tips For Installation

    There should be no obstacles between the antennas to receive optimum images. The proper distance between the antennas for moving pictures is up to 4-5m and 7-10m for still images. U-Connector/UC-5770W 40 of 44...

  • Page 41: Uc-5770 Specifications

    8. UC-5770 Specifications Wireless U-Connector receiver UC-5770W Model Name UC-5770W Wireless Technology UWB(Ultra Wide Band)/IEEE 802.15.3a Data rate 53.3~480Mbps 1,3,6(3.1GHz~8.9GHz) Band Group(BG) (some of BGs are available based on country regulation) Working distance Up to 10m(30ft) Antenna Dipole Wireless connection USB to HDMI (HDMI 1.3 Audio/video)
  • Page 42 Wireless U-Connector receiver, Wireless USB Adaptor, AC Package contents power adaptor, installation CD, Quick installation guide Environment RoHS Compliant Microsoft Windows XP with SP2 Operating System Support Microsoft Vista 32/64 Microsoft Windows 7 Warranty One-year limited warranty U-Connector/UC-5770W 42 of 44...
  • Page 43 Wireless USB Adaptor UC-5770W Dongle Model Name UC-5770W Dongle Wireless Technology UWB(Ultra Wide Band)/IEEE 802.15.3a Data rate 53.3~480Mbps 1,3,6(3.1GHz~8.9GHz) Band Group(BG) (some of BGs are available based on country regulation) PC interface USB 2.0 Dimension(mm) 20(W) x 9(D) x 47(H)

  • Page 44: U-Connector/Uc-5770W

    U-Connector/UC-5770W 44 of 44...
