Summary of Contents for Rotorlight Anova PRO
- Page 2 Page 2...
-
Page 3: Table Of Contents
Contents Chapter Title Page TLCI & CRI About Anova Pro Whats in the Box Hardware Notes Anova Pro Basic Operation Advanced Operation Component Weights & Dimensions Technical Specificatons F-Stop Tables Troubleshooting Warranty Information Limitation of Liability Credits Rotolight Quality Assurance... -
Page 4: Tlci & Cri
ANOVA PRO POLAR PATTERN & CRI TEST R1 0 20 40 60 80 100 120 100 R15 R2 Ra R1 R14 R3 100 R1 R2 0 20 40 60 80 100 100 120 R15 R2 R3 Ra R4 R1 80... -
Page 5: About Anova Pro
Powered by V-Lock or mains power, ANOVA PRO™ delivers a powerful output (up to 6545 Lux at 3 feet), whilst using 94% less energy than a standard tungsten bulb. Anova Pro delivers unparalleled versatility, superior colour rendering and gorgeous soft light output and is ideal for cinematographers, videographers and photographers alike. -
Page 6: Hardware Notes
Page 6 Hardware Notes Rotary Encoder Knobs / Switches Rotate to Increase (+) or Decrease (-) displayed value. Click to select. Press, hold and rotate for ‘Fast’ data entry. Click both switches together to enter MENU mode. The Left Rotary knob controls Brightness (BRI) and the right knob controls colour (COL). - Page 7 FLSH (Flash) function or various trigger functions in the CineSFX menu. The ANOVA pro can trigger within 1/2500 of a second, and has the capability of generating a flash pulse at 150% of its nominal power (approximately 10,000lux at 3ft, and has a flash guide number of 24 at ISO100 at 9 feet).
- Page 8 Page 8 Accessory Mounting Spigots The three spigots on the front face of ANOVA are used to mount the ‘Gel Frame Holder’ (lower position) using three ‘Ball Lock Pins’ , and the upper mounting position is used to mount optional accessories for the ANOVA, e.g. Honeycomb Louver, SoftBox, Focussing Fresnel Filter (Available separately).
-
Page 9: Anova Pro Basic Operation
To Power ANOVA PRO Down , click the power switch back to mid (OFF) position. NB – ANOVA PRO stores all the user settings in non-volatile RAM so it will remember your last used settings. -
Page 10: Advanced Operation
Flash with Modelling Light ANOVA PRO is the first LED panel to be able to simultaneously act a both a modelling light and flashlight. It has a flash guide number of 24 at 100 ISO at 9 feet. It responds to flash triggers via the 3.5mm jack Flash Sync and Trigger port on the rear panel. - Page 11 The fade can be from 1 to 12 seconds long. Please note, the FADE will be a fade to zero from the current brightness level the ANOVA PRO is set to (ie if brightness is currently 80%, then fade will be 80%-0% over custom time duration).
- Page 12 SFX mode to represent the ‘peak output’ level of each effect, enabling accurate metering (ie if ANOVA PRO is set to 75% brightness and 5600 Kelvin, then the lightning effect peak brightness level shall be 75% brightness at 5600 Kelvin).
- Page 13 Page 13 ‘STRB’ Strobe The Strobe effect produces a regular flashing light, you can control the speed Click the right switch to activate the strobe effect Rotate the right knob to adjust the strobe speed (It will display XX hz , where= ‘XX’ = number of strobe cycles per second) The strobe range is from 1hz up to 4hz.
- Page 14 VFX artists like to use multiple lights with slightly different settings/gels to achieve a fire with ‘dancing shadows’ . NB Before activating the Fire effect you can set a brightness level and then meter ‘ANOVA PRO’s output which will be your peak exposure during the Fire effect. For best results preset the COL (colour temperature) to 3150kelvin.
- Page 15 Page 15 ‘Weld’ This effect simulates the light from an electric arc welding torch. To enter the effect press the right switch. The right rotary control varies the speed of the effect. The right switch starts / stops the effect, or you can also start/stop the effect via the external trigger port .
- Page 16 Page 16 ‘ROTO’ (Rotary Special Effects) The submenu set of ROTO SFX are designed to offer VFX Designers something uniquely different even experimental. Because ANOVA PROs can address each set of LEDs individually, we have made a set of SFX tools that offer some unique spinning lighting effects for VFX designers, of particular note is the spooky shadowing that is created by many of the ROTO FX, which lend themselves well for Drama/Horror productions.
- Page 17 Voltage whilst reducing the output by progressive steps of 10% until voltage stabilises to eliminate flicker. ANOVA PRO will operate from 6V DC up to 17.5V DC and draws up to 48 watts at full power. Only connect external power sources with the correct polarity and voltage to avoid serious damage to ANOVA PRO.
- Page 18 Page 18 Filter Information ANOVA PRO’s Filters have a diameter of 304mm and a 40mm hole in the centre, so it is easy to cut your own. A filter holder is included with ANOVA PRO. ANOVA PRO ships with a standard filter pack consisting of :-...
- Page 19 Each channel is set separately . Additionally you can set DMX Master Mode to –on or –off. Now ANOVA Pro behaves as a 2 channel master DMX controller and can be used to control other ANOVAs or 3rd party lights via wired DMX cables on the selected -BRI and -COL DMX channels.
-
Page 20: Component Weights
Page 20 Component Weights & Dimensions CRI (Colour Rendering Index) CRI=> 96 Beam Angle Flood -110 degrees or 50 degrees Variable Colour Temperature Range 3150K to 6300K Lighting System Bi Colour LED Equivalent Output 4100 Watt Tungsten Bulb Equivalent Power Consumption 48 Watts at full power Operating Temperature -15degrees to +40degrees Celcius... -
Page 21: Dimensions
Page 21 Technical Specifications: ROTOLIGHT ANOVA PRO ROTOLIGHT ANOVA PRO ROTOLIGHT ANOVA PRO BI-COLOUR ‘STANDARD’ BI-COLOUR ‘ULTRAWIDE’ 5600K ‘FIXED COLOUR’ MODEL SKU RL-ANVPRO-BI-S RL-ANVPRO-BI-W RL-ANVPRO-56K-S ‘Ultrawide’ 110 Degree’ ‘Standard’ 50 Degree’ BEAM ANGLE ‘Standard’ 50 Degree’ Fixed 5600K (+/- 100K) - Correction... -
Page 22: Stop Tables
Page 22 Guide Number + F-Stop Tables... -
Page 23: Troubleshooting
Page 23 Troubleshooting I have attached a battery but the unit does not power up ? Check that the power switch is set to ‘BATT’ and not ‘OFF’ or ‘DC IN’ . I have attached the AC to DC Adapter but the unit does not power up ? Check that the power switch is set to ‘DC IN’... -
Page 24: Limitation Of Liability
Quality Assurance testing. Rotolight ANOVA PRO is a Registered design of Rotolight Ltd. Rotolight ™, ANOVA™, AccuColour™, True Aperture Dimming ™, Designer Fade ™ and CineSFX™ are registered trademarks of Rotolight Ltd. Other brand name and products depicted herein are for illustration purposes only and are trademarks of their respective holders. - Page 25 “What a fantastic piece of kit! I have to say I’ve fallen in love with these lights! I found the Rotolight ANOVA PRO Bi-Colour to be extremely useful on the floor as a flexible fill alternative to Chimera with Arri 300/500’s… Coronation Street is purposely lit to look warm, turnaround is very quick between scenes and the ANOVA’s play their part superbly as a fill source.
- Page 26 Page 27...
- Page 27 Page 28 ACCURATE COLOUR DUAL CONTROLS FOR CONTROLLABLE VIA CINEMATIC FLASH SYNC TEMPERATURE DISPLAY COLOUR / BRIGHTNESS DMX * WIFI SPECIAL FX AND TRIGGER * Wifi Models Available late 2016...
