INSTRUCTION MANUAL
HD-3500 Series
SERIAL DIGITAL VIDEO, DATA, AND AUDIO,
FIBER OPTIC TRANSPORT & DISTRIBUTION
SYSTEM FOR HDTV & SDTV
MultiDyne
Video at Light Speed
10 Newton Place
Hauppauge, NY 11877 USA
1-877-685-8439 • 1-516-671-7278• FAX (516)-671-3362
sales@multidyne.com
www.multidyne.com
REV G, March 17, 2017
Advertisement
Table of Contents
Related Manuals for MultiDyne HD-3500 series
Summary of Contents for MultiDyne HD-3500 series
- Page 1 INSTRUCTION MANUAL HD-3500 Series SERIAL DIGITAL VIDEO, DATA, AND AUDIO, FIBER OPTIC TRANSPORT & DISTRIBUTION SYSTEM FOR HDTV & SDTV MultiDyne Video at Light Speed 10 Newton Place Hauppauge, NY 11877 USA 1-877-685-8439 • 1-516-671-7278• FAX (516)-671-3362 sales@multidyne.com www.multidyne.com REV G, March 17, 2017...
- Page 2 MULTIDYNE and HD-3500 are registered trademarks of MULTIDYNE Electronics, Inc. Copyright 2009 MULTIDYNE Electronics, Inc., Hauppauge, New York. Printed in the United States of America. All Rights Reserved. Contents of this publication may not be reproduced in any form without t he written permission of MULTIDYNE Electronics, Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................1 FEATURES AND OPERATION ....................1 TRANSMITTER, HD-3500-FTX ................... 2 RECEIVER, HD-3500-FRX ....................6 POWER REQUIREMENTS ....................10 INSTALLATION ......................... 10 APPENDIX A. PIN-OUT SPECIFICATION ................11 APPENDIX B. BLOCK DIAGRAMS ..................12 APPENDIX C. TECHNICAL SPECIFICATIONS ..............14 APPENDIX D. -
Page 4: Introduction
Instruction Manual, HD-3500 Series INTRODUCTION 1 INTRODUCTION HD3500 Series of stand-alone SMPTE 3G video High Definition Serial Digital Interface (HD-SDI) with audio and data transport systems extends the range limits of electrical interfaces, and combines audio and data along with the HD-SDI signal in a single optical fiber link. -
Page 5: Transmitter, Hd-3500-Ftx
Instruction Manual, HD-3500 Series FEATURES and OPERATION 2 TRANSMITTER, HD-3500-FTX The transmitter module front and back is shown in figure 1. In the back and from left to right it includes a DB44 connector for all audio and data IO; two serial digital video SMPTE 75 Ohm input BNC connectors, one for input and one for reclocked SDI / HD-SDI output loop;... - Page 6 Instruction Manual, HD-3500 Series FEATURES and OPERATION 3 need to transport these signals, the auto mute feature can be disabled changing the jumper J10 from the 1-2 to the 2-3 position, see figure 2 with default setting. Non-SMPTE standard signals should automatically put the reclocker into bypass mode; however, in some instances, if the signal has components close to the SMPTE frequencies, there may be glitches on the operation.
- Page 7 Instruction Manual, HD-3500 Series FEATURES and OPERATION 4 Sw 1 Function Setting (Default values in Bold) Position on=RS232 Data 1 Type off=RS422 Data 2 Type on=RS232 off=RS422 Data 3 Type on=RS232 off=RS422 Analog Sampling on=48KHz off=96KHz off = 110 Ohms AES3 Bal. Input...
- Page 8 Instruction Manual, HD-3500 Series FEATURES and OPERATION 5 Gigabit Ethernet and Sync Option Figure 3. Front and Back of HD-3500-GE-TX Reference Transport The Gigabit Ethernet & Sync option, HD-3500-GE-TX, will output a reference genlock signal supplied by the HD-3500-GE-RX unit. Only the sync portion of the reference signal is transported across the fiber link, all video and color information is stripped from the signal.
-
Page 9: Receiver, Hd-3500-Frx
Instruction Manual, HD-3500 Series FEATURES and OPERATION 6 RECEIVER, HD-3500-FRX The receiver module front and back is shown in figure 3. In the back and from left to right it includes: a DB44 connector for all audio and data IO, two SMPTE serial digital video 75 Ohm output BNC connectors for two reclocked SDI / HD-SDI outputs, a single fiber output ST or SC connector, and a DC Jack power connector. - Page 10 Instruction Manual, HD-3500 Series FEATURES and OPERATION 7 Non-SMPTE transport via the SMPTE interface This unit should work normally by default with SMPTE video signals at the rates indicated previously; however, other signals may need special settings. The reclocker will mute the output when noise or a not supported SMPTE rate is detected.
- Page 11 Instruction Manual, HD-3500 Series FEATURES and OPERATION 8 Sw 3 Function Setting (Default values in Bold) Position An. Audio 1 FS on-on= 28dBu FS on-off = 16dBu FS off-on = 10dBu FS off-off = 4dBu FS An. Audio 2 FS on-on= 28dBu FS on-off = 16dBu FS off-on = 10dBu FS off-off = 4dBu FS Table 6.
- Page 12 Instruction Manual, HD-3500 Series FEATURES and OPERATION 9 Gigabit Ethernet and Sync Option Figure 5. Front and Back of HD-3500-GE-RX Reference Transport The Gigabit Ethernet & Sync option, HD-3500-GE-RX, will send a reference genlock signal to the HD-3500-GE-TX unit. Two BNC’s are provided, one for the input and the other as a loop-thru output.
-
Page 13: Power Requirements
FEATURES and OPERATION 10 POWER REQUIREMENTS The HD-3500 Series operates from 110 or 220 VAC with the included wall-mount 12V power supply or other source in a range from 9 to 24 VDC and at least 25W of power. It uses a coaxial type connector (sleeve ground) on the rear panel labeled POWER. -
Page 14: Appendix A. Pin-Out Specification
Instruction Manual, HD-3500 Series APPENDIX A. Pin-Out specification 11 APPENDIX A. Pin-Out specification DB 44 TX-3500-FTX HD-3500-FRX Pin # Name Description Name Description A1L+ Analog Audio Ch1 Left In + A1L+ Analog Audio Ch1 Left Out + A2L- Analog Audio Ch2 Left In -... -
Page 15: Appendix B. Block Diagrams
Instruction Manual, HD-3500 Series APPENDIX B. Block Diagrams 12 APPENDIX B. Block Diagrams REV G, March 17, 2017... - Page 16 Instruction Manual, HD-3500 Series APPENDIX B. Block Diagrams 13 REV G, March 17, 2017...
-
Page 17: Appendix C. Technical Specifications
Instruction Manual, HD-3500 Series APPENDIX C. Technical Specifications 14 APPENDIX C. Technical Specifications General Power: ...................... 9-24V / 25W Max Range with default Single Mode optics ..........up to 40Km Fiber Connector Type ................ST or SC Standards Supported ................SMPTE 259M-C... - Page 18 Instruction Manual, HD-3500 Series APPENDIX C. Technical Specifications 15 Reference Genlock Output (-GE option only): Number of Outputs ..................1 Type ......................NTSC/PAL HD Tri-Level Impedance ....................75 Ohms Ethernet(-GE option only): Number of Ports ..................1 Data Rate ....................10/100/1000 Base-T...
-
Page 19: Appendix D. Optional Diving Board
Instruction Manual, HD-3500 Series APPENDIX D. Optional Diving Board 16 APPENDIX D. Optional Diving Board Terminal Block Pins Non-labeled gray pins are ground GPI: General Purpose Input GPO: General Purpose Output Vn+/- : Test Voltage (Not Connect) TALLLY OUT/IN DIn+/- : RS232/RS422 Input DOn+/- : RS232/RS422 Output Use always DO- / DI–...
