Summary of Contents for HomeGoods DINING CHAIR
- Page 1 Assembly Instructions Caution : You must read this before you proceed DINING CHAIR Part List Label Picture Description Leg (A) Leg (B) Top Rest Cushion Seat Corner Block Page 1 of 7...
- Page 2 Hardware Label Picture Description JCBC M6 x 25mm + S/W ① M6 + F/W M6 x 13mm JCBC M6 x 55mm + S/W ② M6 + F/W M6 x 13mm JCBC W Screw ③ M7 x 40mm ④ FH Screw #8 x 25mm ⑤...
- Page 3 Assembly Steps Overview Top Rest (C) Cushion Seat (D) Leg (B) Leg (A) This Dinning Chair has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Dinning Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 4 Step 2 Place the Side Frame (A) and (B) onto the Seat Cushion (D) as shown. Then fix the Side Frame with JCBB Bolt ② + Spring Washer + Flat Washer using Allen Key ⑤. DO NOT FULLY TIGHTEN THE BOLT. Step 3 Place the Top Rest (C) on the back frame as shown above.
- Page 5 Step 4 Fix the Leg with JCBC W Bolt ③ using Allen Key ⑤ at center of leg. DO NOT FULLY TIGHTEN BOLT. Step 5 Place the Corner Block (E) at the center leg as shown. Then, fix the Corner Block (E) with Screws ④ using Screwdriver (not provided).
- Page 6 30-50mm ③ Test again Place the dining chair on a Level Surface to check if it wobbles. Loosen the bolts and lift the dining chair some 30cm to 50cm high from the ground, keep your feet and toes well away from the drop zone, and drop the dining chair freely and vertically with the four legs, hitting the ground at the same time.
- Page 7 Care & Maintenance Page 7 of 7...
