- Page 1 CITI RANGE - ASSEMBLY INSTRUCTION MANUAL PRODUCT DESCRIPTION: CORNER WORKSTATION - SINGLE - 1 PERSON (1500 x 1500 x 750) CODE/S: CTWS1515...
- Page 2 CITI RANGE - ASSEMBLY INSTRUCTION MANUAL IMPORTANT Please read all instructions before beginning job. These instructions are provided to avoid problems that may occur from improper assembly. The manufacturer and/or distributor are not responsible for failure resulting from improper assembly or installation. Moreover, all warranties are void for failure to follow these assembly instructions.
- Page 3 CITI RANGE - ASSEMBLY INSTRUCTION MANUAL WORK TOP END LEG WORK TOP BRACKET (OPTIONAL COMPONENT) TELESCOPIC BEAM c END-END BEAM BEAM CONNECTOR...
-
Page 4: Included Parts
INCLUDED PARTS Single End Leg Beam Connector Beam Connector Top Bracket End to End Beam Telescopic Beam (Optional Component) 1500W Top - 1362mm Work Top 1500 x 1500 x 750 M6 x 35mm M6 x 75mm M6 x 25mm M6 x 15mm 6G x 20mm (Optional Component) x 12... -
Page 5: Tools Required
TOOLS REQUIRED Power Drill Spirit Level 5mm Hex Drill Head Bit Philips Drill Head Bit - Tape Measure... - Page 6 INSTRUCTIONS FAMILIARISE YOURSELF WITH ALL THE COMPONENTS. IT IS RECOMMENDED TO TAKE EACH COMPONENT OUT AND LAY IT OUT (WITH PACKAGING) AS SHOWN IN THE DIAGRAM BELOW. THIS WILL MAKE IT EASIER TO CONSTRUCT THE WORKSTATION. NOTE: IT IS RECOMMENDED TO CONSTRUCT THE WORKSTATION IN THE AREA IN WHICH IT IS TO BE USED. END-END BEAM BEAM CONNECTOR END LEG...
- Page 7 INSTRUCTIONS FIX BEAM CONNECTORS TO BEAM IN 6 LOCATIONS THIS STEP IS IMPORTANT TO DETERMINE THE LOCATION ENSURE THE BEAM IS UP THE RIGHT WAY WITH THE OF THE RETURN SECTION OF THE WORKTOP (LEFT OR SMALLER HOLES AT THE TOP RIGHT) TOP OF BEAM HAS SMALLER HOLES LAY OUT THE BEAMS WITH THE CONNECTORS ATTACHED...
- Page 8 INSTRUCTIONS UNSCREW THE BOLTS (8 IN TOTAL) ON EITHER SIDE OF FIX END-END BEAMS TO END LEGS - (4 LOCATIONS) THE TELESCOPIC BEAM. DO NOT UNSCREW THEM ALL THE WAY OUT; NOTE: THE BEAM CONNECTOR LOOSEN THEM ENOUGH TO MOVE THE BEAM ALONG THE MUST SIT LEVEL WITH THE TOP MIDDLE COMPONENT.
- Page 9 INSTRUCTIONS FIX TOP BRACKETS TO END LEG (WITH TELESCOPIC BEAMS NOTE: THIS STEP IS OPTIONAL - FOR THE MAIN DESK FRAME ATTACHED) IN 2 LOCATIONS . FIX TOP BRACKET TO END LEGS IN 4 LOCATIONS ENSURE ENSURE THE BRACKET SITS LEVEL WITH THE LEG THE BRACKET SITS LEVEL WITH THE LEG END LEG END LEG...
- Page 10 INSTRUCTIONS FLIP THE FRAME AND PLACE ONTO THE WORKTOP (AS NOTE: THIS STEP IS TO BE UNDERTAKEN IF YOU HAVE NOT SHOWN BELOW) COMPLETED STEP 6. THE WORKTOP SHOULD BE POSITIONED TO HAVE A 5MM FIX THE WORKTOP THROUGH END-END BEAMS & OVERHANG ON EACH SIDE.
-
Page 11: Detail View
INSTRUCTIONS WHILE THE FRAME IS STILL FACE DOWN, FIX THE FLIP THE DESK TO BE RIGHT SIDE UP. WORKTOP THROUGH THE WORKTOP BRACKETS ON THE RETURN LEG. IT IS IMPORTANT THAT THE WORKTOP SIT LEVEL. (2 LOCATIONS) PLACE THE LEVEL IN THE MIDDLE OF THE WORKTOP (AS SHOWN BELOW) IF ADJUSTMENT IS NEEDED WIND THE FEET ACCORDINGLY. -
Page 12: Care Instructions
INSTRUCTIONS COMPLETE WORKSTATION CARE INSTRUCTIONS • AVOID USING ABRASIVE CLEANERS. WORKTOPS AND FRAMES CAN BE CLEANED WITH A DAMP, SOFT CLOTH, THEN DRY THE SURFACE • COMPLETELY. IF MARKS OR SCUFFS ON WORKTOP OR FRAME OCCUR; WARM WATER WITH SOAP ON A DAMP CLOTH •...
