  • Page 1 1/10 scale 2wd...

  • Page 2: Table Of Contents

    INTRODUCTION SafETy Serpent developed the Serpent F110 SF3 model car for demanding racers in the highly competitive electric Read and take note of the ‘Read this First section’ before proceeding to assemble the car-kit. This car-kit is 1/10th scale F1 class, which like all our previous cars, has been designed to win straight from the box.
  • Page 3 hOW TO USE ThE maNUal lINES DESCRIpTION ICONS DESCRIpTION Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in Each step contains a variety of symbols described below. which the parts should be assembled. The lines are described below. Step number;...

  • Page 4: Front Assembly

    fRONT aSSEmbly STEp 1 bag 1 As default adjustement of the front ride height should be assembled 2x 3x6x1 ride height spacers. The kit includes 4x 3x6x0.5mm ride height spacers for fine tuning. 3x6x1 3x6x1 M3x8 M3x8 M3x8 3x6x1 3x6x0.5...
  • Page 5 STEp 2 STEp 3 M3x6 M3x6 M2.5x6 M3x6 M2.5x6 FRONT WHEELBASE LONGER SHORTER FRONT REAR M2.5x6 M3x6 M3x6...
  • Page 6 STEp 5 STEp 4 M3x8 CASTER INSERTS CHART M3x5 M3x8 + CASTER - CASTER M3x5 FRONT REAR 5X8X2.5 Flanged SERVOSAVER ACKERMANN INSERTS 5X8X2.5 - ACKERMANN + ACKERMANN Flanged FORWARD REARWARD M3x5 M3x6 M3x6 M3x5 M3x6 M3x8 5X8X2.5 Flanged...
  • Page 7 STEp 6 STEp 7 bag 2 FRONT CAMBER 4 mm...
  • Page 8 STEp 8 STEp 9 Right steering block assembly R2.3 3x5x2 Nylock Nut M3 M3x8 ACKERMANN POSITION 3x5x2 KING PIN INSERTS CHART King pin angle adjustable from 0 to 4 degrees. 0º 1º 2º 3º 4º R2.3 3x5x2 3x5x2 R2.3 M3x8 Nylock Nut M3...
  • Page 9 STEp 10 STEp 11 STEERING TRACKROD LENGTH 16 mm...

  • Page 10: Rear Assembly

    REaR aSSEmbly STEp 12 STEp 13 STEp 14 bag 3 Nylock Nut M3 M3x6 M3x6 M3x8 M3x6 M3x6 M3x8 Nylock Nut M3 M3x6 M3x6...
  • Page 11 STEp 15 STEp 16 bag 4 M2.2x6 Nylock Nut M3 M3x16 REAR WING TOP FLAP ADJUSTMENT REAR WING TOP FLAP M2.2x6 ADJUSTMENT M2.2x6 Nylock Nut M3 M3x16...

  • Page 12: Central Assembly

    CENTRal aSSEmbly STEp 17 bag 5 M2x6 M2x6 Note correct M2x6 pivot ball type. M2x6 M3x5 M3x5 M3x5 M3x5 M2x6 M3x5...
  • Page 13 STEp 18 STEp 19 STEp 20 Note correct pivot ball type. M3x6 M2.5x6 3x5x4 M2.5x6 M3x6 3x5x0.3 M3x8 M3x6 2.5x22 M3x3 M3x10 M3x8 M3x6 2.5x22 M3x3 M3x8 M3x10 M2.5x6 3x5x4 3x5x0.3 M3x6 M3x8 M3x6...
  • Page 14 STEp 21 STEp 22 Apply the silicone oil on the inner tube. Use the silicone oil supplied in the kit. For the correct M3x6 cst value please check the default setupsheet. 3x6x0.5 M3x10 M3x6 M3x8 Nylock Nut M3 3x5x4 M3x10 3x5x4 3x6x0.5 M3x6...

  • Page 15: Ball Diff Assembly

    ball DIff aSSEmbly STEp 23 bag 6 1/4x3/8 1/4x3/8 1/4x3/8 Nylock Nut M4 Flanged Note correct shims orientation. Nylock Nut 1/4x3/8 M4 Flanged...
  • Page 16 STEp 24 M3X8 6.5x8x0.25 1/4x3/8 Flanged 6.5x8x0.25 1/4x3/8 Flanged REAR RIDE HEIGHT The rear ride height is adjustable in steps of 0.5mm increments using different rear axle bearing adapters. INSERTS CHARTS The ride height decreases if the axle is placed higher. 0\05 0\10 0\15 0\20 0\25...

  • Page 17: Electronics Assembly

    ElECTRONICS aSSEmbly STEp 25 bag 7 REaRWaRD SERVO CONfIgURaTION DEfaUlT fORWaRD SERVO CONfIgURaTION OpTIONal 25.1 25.1 M3X5 M3X5 M3X6 M3X6 25.2 25.2 3x6x1 3x6x1 3x6x1 3x6x1 3x6x1 3x6x1 3x6x1 3x6x1 3x5x2 3x5x2 M3X6 3x5x2 M3X6 Flanged 3x5x2 3x5x2 Flanged 3x5x2 M3X6 M3X6 Flanged...
  • Page 18 STEp 26 REaRWaRD SERVO CONfIgURaTION DEfaUlT fORWaRD SERVO CONfIgURaTION OpTIONal M3x6 M3x6 M3x6 M3x6 M3x6 M3x6...
  • Page 19 STEp 27 REaRWaRD SERVO CONfIgURaTION DEfaUlT fORWaRD SERVO CONfIgURaTION OpTIONal 27.1 27.1 STEERING LINK LENGTH STEERING LINK LENGTH 6 mm 14 mm 27.2 27.2...
  • Page 20 STEp 28 REaRWaRD baTTERy CONfIgURaTION DEfaUlT fORWaRD baTTERy CONfIgURaTION OpTIONal This configuration Use glass-tape to fix the battery to only can be used the chassis and battery holders. with the servo in the forward position. Use glass-tape to fix the battery to the chassis and battery holders.
  • Page 21 STEp 29 M3x12 M3x12 3x5x2 M3x10 3x5x2 M3x12 M3x10...

  • Page 22: Shock Assembly

    ShOCk aSSEmbly STEp 30 STEp 31 ShOCk bag 30.1 31.1 SHOCK CARTRIDGE Use some silicone oil Use some silicone oil during the assembly. during the assembly. Make sure that the circlip sits secure in its notch. 31.2 30.2 For the correct piston holes please check the default setupsheet.
  • Page 23 STEp 32 STEp 33 STEp 34 Close the shock slowly. 32.1 Important: do not crossthread! Oil will overflow through the built-in bleed channel. M3X10 Tighten carefully until the bottom half sits against the shock body. 32.2 Insert the o-ring inside the spring 1) Fill the shock body with collar.
  • Page 24 STEp 35...

  • Page 25: Final Assembly

    fINal aSSEmbly STEp 36 bag 8 36.1 36.2 Nylock The weights are used to compensate the Nut M3 weight of the ESC and equilibrate the chassis weight. Them must be assembled Nylock on the oppiste side of the ESC. Nut M3 3x5x3 3x5x3 3x5x3...
  • Page 26 STEp 37 Use double sided tape to mount the ESC and RX to the chassis. M3x5 M3x5...
  • Page 27 STEp 38 STEp 39 Pinion is not included in the kit. Assemble the proper pinion for your set-up. M3x3 M3x10 M3x3 M3x10...
  • Page 28 STEp 40 bag 8 fRONT WINg aSSEmbly DEfaUlT fRONT WINg bIg flapS aSSEmbly OpTIONal The front big flaps create a big amount of downforce. It is recommended to don’t assemble them as default and use them when more steering is needed. Also it is possible to cut them to adjust the amount of downforce created.
  • Page 29 STEp 41 M3x10 M3x10 M4x10 M3x10 M3x10 M4x10...
  • Page 30 STEp 42 Nylock Nut M4 Flanged The front wheelnuts should not be tightened too much to ensure the wheels turn free. Body, wheels and tyres Nylock are NOT included Nut M4 5x10x4 5x10x4 Nylock Nut M4 Flanged The front wheelnuts should not be tightened too much to ensure the wheels turn free.

  • Page 31: Exploded Views

    EXplODED VIEWS INDEX fRONT EXplODED VIEW ball DIff EXplODED VIEW REaR EXplODED VIEW ShOCk EXplODED VIEW CENTER EXplODED VIEW fINal EXplODED VIEW TEam SERpENT NETWORk...

  • Page 32: Front Exploded View

    fRONT EXplODED VIEW 110124 110124 411337 110157 411163 110157 411338 411206 401025 411336 411023 401043 401058 411163 411206 411347 401043 411323 1312 411321 110108 401025 401025 110108 411042 401043 411380 110402 411042 401025 411322 411356 411220 opt 411337 110128 411218 opt 110108 411219 1312...
  • Page 33 ball DIff EXplODED VIEW 411318 opt 411309 411186 411075 411107 opt 411069 411186 411075 411290 411075 411251 110444 120024 opt 120025 opt 120026 opt 120027 opt 120028 opt 120029 opt 120030 opt 120031 120032 opt 120033 opt 120034 opt 120035 opt 411166 120036 opt 120037 opt...

  • Page 34: Rear Exploded View

    REaR EXplODED VIEW 110156 411187 110122 110415 411343 110104 110122 110402 411061 411292 opt 110411 401025 411312 opt 110130 401025 110411 411354 opt 411207 411355 opt 411289 110108 411369 110428 411370 opt 110108 411372 110154 411339 411074 110402 411259 110124 411072 110108 110154...
  • Page 35 ShOCk EXplODED VIEW 411120 Shock-absorber-set 411207 411020 411165 411045 411141 411044 411097 411140 411162 411057 411041 411366 opt 411046 411367 411203 411047 411368 opt 411214 opt 411162 411215 opt 411019 411216 opt 411217 opt 110154 411207 411120 Shock-absorber-set 411215 Center spring 14lbs S120L 411366 Center spring 6.5lbs 411216 Center spring 16lbs S120L 411368 Center spring 10 lbs...
  • Page 36 CENTER EXplODED VIEW 411120 401025 401043 110109 411346 500360 110449 500165 opt 411346 110449 411350 110172 110183 401043 411291 110172 401043 411206 401025 401430 411308 110128 411206 804322 110122 110166 110122 110122 500165 Battery plate nut (4) SRX2...
  • Page 37 fINal EXplODED VIEW 110405 411040 401433 401433 411070 1606 110402 110403 1315 110122 411381 110122 411381 110402 110436 1315 110116 110436 411302 411298 411352 401687 411301 411352 110129 411352 110190 110109 411352 110127 110405 110157 411352 411353 opt 110102 1315 411293 opt 411294 opt 110190...

  • Page 38: Team Serpent Network
