Rear View - JOYTECH AV CONTROL CENTER User Manual

ENGLISH
WELCOME
Thank you for purchasing the JOYTECH™ AV Control Center. Before connecting the AV Control Center,
please familiarize yourself thoroughly with this User Guide so that you fully understand the set-up
procedure and functions of the product.
CONTENTS
CHECK THAT YOU HAVE THE FOLLOWING ITEMS:
1) User Guide
2) AV Control Center
3) Remote Controller
4) SCART to SCART cable
5) S-Video to S-Video cable
6) 3 x Phono to 3 x Phono cable
7) AC Power Adapter
AV CONTROL CENTER LAYOUT
FRONT VIEW
Power / Standby Button Input Indicators (1-4) Channel Selector Button
IR Remote Receiver

REAR VIEW

AC 9V IN
Input 1 Input 2 Input 3 Input 4 Output
