User's Manual
LCD KVM Console Rack Drawer
Features and functions may be added or changed
after the manual was written. Please visit our
website to download the latest version of manual
for reference.
RoHS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SED-KLVGA-0117 and is the answer not in the manual?

Questions and answers

Summary of Contents for SERVER EDGE SED-KLVGA-0117

  • Page 1 User's Manual LCD KVM Console Rack Drawer ◘ ◘ Features and functions may be added or changed after the manual was written. Please visit our website to download the latest version of manual for reference. RoHS...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION................FEATURES..................PRODUCT TYPE................PRODUCT DESIGN..............Front View................Rear View................Dimensions................. PACKAGE CONTENTS..............KVM Cable................KVM Power Cable............... OPERATIONS................8-14 KVM Operation..............Before Use................During Use................After Use................Hot Plugging............... Power On/Off and Reboot........... Assembling & Disassembling..........Standard Rack Installation..........
  • Page 3: Introduction

    INTRODUCTION The Serveredge LCD VGA KVM Console Rack Drawer integrates a multi-port KVM switch with a LCD console while taking up only 1RU height in your server rack. This Serveredge LCD VGA KVM Console Rack Drawer can control up to 1/8/16 PCs with direct connections and it can control up to 256 PCs using a 2 level cascade connection.
  • Page 4: Product Type

    PRODUCT TYPE Model No. IP Access Solution SED-KLVGA-0117 17" LCD KVM Console Rack Drawer - Single Port USB/PS2/VGA SED-KLVGA-0119 19" LCD KVM Console Rack Drawer - Single Port USB/PS2/VGA SED-KLVGA-0817 17" LCD KVM Console Rack Drawer - 8 Port KVM USB/PS2/VGA SED-KLVGA-0819 19"...
  • Page 5: Rear View

    Rear View SED-KLVGA-0117 / SED-KLVGA-0119 (with IP module) SED-KLVGA-0817 / SED-KLVGA-0819 (with IP module) SED-KLVGA-1617 / SED-KLVGA-1619 (with IP module) 1 2 3 4 1. Restoring IP Module to Default • Plug a needle or a ballpoint pen into the hole to restore the IP module to default setting.
  • Page 6: Dimensions

    Dimensions 17 inch model 19 inch model www.serveredge.com.au...
  • Page 7: Package Contents

    PACKAGE CONTENTS Packaging Includes ITEM Q’TY LCD KVM Console Rack Drawer KVM Cable with VGA, USB and PS/2 connectors AC Power Cable User Manual Quick Install Guide KVM Cable Cable Type Application Type KVM Port PC or Server Port USB and PS/2 Cable VGA port (For KVM VGA, Keyboard, Mouse Keyboard, mouse...
  • Page 8: Kvm Power Cable

    KVM Power Cable Cable Type Note Voltage Range Machine Type AC Power Cable 3 Plugs of National 100~240V Standard AC Power Cable www.serveredge.com.au...
  • Page 9: Operations

    OPERATIONS KVM Operation Before Use • Make sure all the devices are safely grounded. • Make sure the KVM cable and power cable are connected correctly. During Use • Pull the KVM completely out of the cabinet, the rail guides will automatically lock and the power will turn on. •...
  • Page 10: After Use

    After Use • Press the LCD power key to turn the LCD off. • Close the LCD panel and lock the front panel. • Release guide locks. • Push the KVM completely back into the cabinet to power it off. Hot Plugging The KVM control platform supports hot plugging.
  • Page 11: Assembling & Disassembling

    Assembling & Disassembling The device can be assembled and disassembled as following. www.serveredge.com.au...
  • Page 12: Standard Rack Installation

    Standard Rack Installation Screw the front flange to the rack first. Slide the bars with the rear flange towards the rack until the flanges make contact with the rack, then screw the rear flanges to the rack. Slide the switch onto the support flanges. Use the screws supplied with this package to loosely attach the front of the switch to the front of the rack.
  • Page 13 3. Slide the rear attachment sliding brackets along the slide bars until they contact the rear of the switch. 4. Use the screws supplied in the box to attach the bars to the rear of the switch. www.serveredge.com.au...
  • Page 14: Single Stage Installation

    Single Stage Installation To set up your installation, do the following: Plug in the KVM port side of the cable into one of the ports located on the LCD KVM console rear panel. At the PC or Server Port side of the cable, plug the keyboard, mouse (only plug either USB or PS/2, not both), video cables into their respective ports on the computer.
  • Page 15: Cascade Installation

    Cascade Installation To set up cascade installation, do the following: Set up single installation as mentioned in SINGLE STAGE INSTALLATION. Connect one end of HDB15 cable to IN port of upper KVM, and the other end to OUT port of lower KVM. This completes the cascade installation, and you can turn on the power to the computers.
  • Page 16: Osd Operation

    OSD OPERATIONS OSD Overview The On Screen Display (OSD) is used to handle all computer control and switching procedures. All procedures start from the OSD main menu. To pop up the main menu, tap [Ctrl] twice. If OSD menu is set as “console locked”, you must input password each time the main menu appears. If no password has been set, just press [Enter] to show main menu.
  • Page 17: Osd Main Screen Headings

    OSD Main Screen Headings Heading Explanation This column lists the port numbers for all the CPU ports on the installation. The simplest method to access a particular computer is to move the highlight bar to it, then press [Enter]. If a port has been selected for Quick View scanning, an arrowhead symbol displays in this column to indicate so.
  • Page 18 F3 LIST The LIST function lets you broaden or narrow the scope of which ports the OSD displays on the main screen. Many of the OSD functions only operate on the computers that have been selected for listing on the main screen with this function.
  • Page 19 SCAN DURATION: Duration for scanning one port。 Options are 3 seconds, 5 seconds, 10 seconds, 15 seconds, 20 seconds, 30 seconds, 40 seconds, 60 seconds. Move the highlight bar to an option and press [Enter] to select it. OSD ACTIVATING HOTKEY: Select OSD activating hotkey。 •...
  • Page 20: Safety Guide

    SAFETY GUIDE • Please follow the directions below when installing, using and maintaining in order to keep the device in working order • When installing and operating the device, please make sure to have the proper power supply first, and then resume operations after it is initialized.
