Summary of Contents for Climate Control CCS-22HR4GP
-
Page 3: Operation And Maintenance-Notices For Operation
Operation and maintenance-Notices for operation Please read the following carefully before operating. WARNING When having a burning smell Don't operate the air conditioner Never cut off or damage power or smoke, please turn off the power with wet hands. cables and control wires. If the power cable and signal control wire were supply and contact with the service damaged, change them by professional... -
Page 4: Notices For Operation
Notices for operation Earth:The ground Be sure to pull out the power Select the most appropriate tem- perature. be connected! plug when not using the air co- nditioner for a long time. Keep room coo- er than outside about If not, please ask the qualified person- nel to install. - Page 5 Notices for operation To adjust the airflow and direction appropriately. The power cords of this air conditioner adopt X-type connection, please don't cut off or damage At operating the louvers of air conditioner could be the power cords and control cords. If they are adjusted by pressing the SWING button on wireless damaged, please ask the qualified personnel to remote control to change the airflow direction.
-
Page 6: Notices For Use
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function If the unit is running in COOL mode and in low termperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0 ,... -
Page 7: Names And Functions Of Each Part
Names and functions of each part Indoor unit Air in Air out Power cords Wireless remote control Manual switch Display board Front panel Filter Guide louver COOL Set TEMP. RUN Heat Window indicator receiver Wall pipe Outdoor unit Bind tape Window receiver Air in Connection wire... -
Page 8: Operation Of Wireless Remote Control
Operation of wireless remote control Name and function of wireless remote control Note: Be sure that there are no obstructions between receiver and remote controoler; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot. -
Page 9: Names And Functions Of Wireless Remote Control
Operation of wireless remote control Names and functions of wireless remote control This wireless remote control is universal, and it could be used for many units, some buttons of this control which are not available to this unit will not be described below. TURBO Wireless remote control TURBO button... -
Page 10: Guide For Operation- General Operation
Operation of wireless remote control Guide for operation- general operation 1. After powered on, press ON/OFF button, the unit will start to run.(Note: When it is powered on, the guide louver of main unit will close automatically.) 2. Press MODE button, select desired running mode, or press COOL or HEAT mode to enter into the corresponding operation directly. -
Page 11: Changing Batteries And Notices
Operation of wireless remote control About the Super Strong function When the Super Strong function is turned on, the whole unit runs at the high fan speed, and runs at the Quick COOL or Quick HEAT operation, to make the ambient temperature swiftly approach to the setting temperature. -
Page 12: Clean And Care
Clean and care Caution Turn power off and pull out the power plug before cleaning air conditioner, or it may cause electric shock. Never sprinkle water on the indoor unit and the outdoor unit for cleaning because it can cause an electric shock. Volatile liquid (e.g. -
Page 13: Check Before Use
Clean and care Check before use Be sure that nothing obstructs the air outlet and intake vents. Check that whether ground wire is properly connected or not. Check that whether the batteries of air conditioner are changed or not. Check that whether the installation stand of the outdoor unit is damaged or not. -
Page 14: Troubleshooting
Troubleshooting CAUTION Don't attempt to repair the air conditioner by yourself, it can cause an electric shock or fire. Please check the following items before asking for repair, it can save your time and money. Phenomenon Troubleshooting Not operate immediately when the air Once the air conditioner is stopped, it will conditioner is restarted. - Page 15 Troubleshooting Phenomenon Troubleshooting The unit can not run Has the power been shut down? Is the circuit protection device tripped off or not? Is voltage higher or lower? (Tested by professionals) Is the Timer correctly used? Break off Cooling(Heating) efficiency is not good. Is Temp.
- Page 16 Troubleshooting Phenomenon Troubleshooting In HEAT mode, when the temperature of indoor Indoor unit cannot deliver air heat exchanger is very low, that will stop deliver air in order to prevent blowing cool air. In HEAT mode, when the outdoor temperature is low or high humidity, there are much frost be formed on the outdoor heat exchanger, that the unit will automatically defrost, indoor...
-
Page 17: Installation Service- Notices For Installation
Installation service- Notices for installation Important Notices The unit installation work must be done by qualified personnel according to the local rules and this manual. Before installating, please contact with local authorized maintenance center, if unit is not installed by the authorized maintenance center, the malfunction may not solved, due to discommodious contacts. -
Page 18: Notices For Installation
Notices for installation Safety Requirements For Electric Appliances The power supply should be used the rated voltage and AC exclusive circuit, the power cable diameter should be satisfied. Voltage applying range: the normal running range is rated voltage 90%-110%. Don't drag the power cable emphatically. It should be reliably earthed, and it should be connected to the special earth device, the installation work should be operated by the professional. -
Page 19: Installation Dimension Diagram
Installation dimension diagram Installation dimension diagram Space to the ceiling Above Space to the wall Above Above Space to the wall Above Above Air outlet side Space to the floor Space to the obstruction Air inlet side Above Space to the wall Above Space to the wall Air outlet side... -
Page 20: Install Indoor Unit
Install indoor unit Install the rear panel 1. Always mount the rear panel horizontally. As the water drainage pipe at the left, when adjusting the rear panel, this side should not be too high; the right side should be slightly high. Fix the rear panel on the selected Wall Mark on the middle of it... -
Page 21: Install The Indoor Unit
Install indoor unit NOTE: When connecting the electric wire if the wire length is not enough, please contact with the authorized service shop to buy a exclusive electric wire that is long enough and the joint on the wire are not allowed. The electric wiring must be correctly connected, wrong connection may cause spare parts malfunction. -
Page 22: Install Outdoor Unit
Install outdoor unit E E l l e e c c t t r r i i c c w w i i r r i i n n g g Disassemble the handle on the outdoor unit right side plate. (1pc screw) Take off wire clamp. -
Page 23: Check After Installation And Test Operation
Check after installation and test operation Check after installation Items to be checked Possible malfunction Has it been fixed firmly? The unit may drop, shake or emit noise. It may cause insufficient cooling(heating) Have you done the refrigerant leakage test? capacity. -
Page 24: Cleaning And Maintenance
Installation and Maintenance of Healthy Filter Installation Instructions 1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a) Fig. - Page 25 ..............Important Note: For repair of equipment under this Warranty it is recommended that the owner contact their Climate Control Dealer / and or their licensed Installer. If the owner requests Advanced Group Australia P/L to perform or arrange the service call, the owner will be liable for all associated costs if the problem is not covered by the provisions of this Warranty.
